基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1350 × 1350 × 760 mm | |
|---|---|---|
| tabletop thickness | 20 mm | |
| gold apron trim height | 80 mm | |
| gold connection ring height | 25 mm | |
| pedestal bottom diameter | 550 mm | |
| pedestal top connection diameter | 180 mm | |
| undertable knee clearance height | 660 mm | |
| floor contact base ring width | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| net weight | 95 kg | |
|---|---|---|
| distributed tabletop static load | 150 kg | |
| seating capacity | 6 people | |
| surface scratch resistance rating | 6H | |
| surface heat resistance | 180 °C | |
| pedestal static vertical load | 300 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| tabletop surface | Polished white sintered stone | |
|---|---|---|
| tabletop edge apron | Brushed gold-finished 304 stainless steel | |
| pedestal connection ring | Brushed gold-finished stainless steel | |
| main pedestal body | Matte black powder-coated A3 carbon steel | |
| tabletop backing substrate | 15 mm thick high-density MDF | |
| fastener hardware | Zinc-plated steel M10 mounting bolts | |
| floor protection pad | 3 mm thick non-marking EVA rubber | |
| gold trim surface treatment | PVD anti-tarnish brushed finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| support structure | Single central conical pedestal delivers 360-degree legroom without corner obstructions | |
|---|---|---|
| assembly method | Knock-down design with 6 mounting bolts securing tabletop to pre-assembled pedestal | |
| surface maintenance | Non-porous polished surface supports wet wiping without staining or water damage | |
| floor protection | Bottom EVA ring prevents hard metal contact from scratching polished hard floors | |
| use environment | Designed for fixed indoor dining use without outdoor weather sealing | |
| edge safety | Rounded 2 mm profile on gold trim eliminates sharp exposed edges | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| residential dining room | Suits 6-seater modern luxury dining sets for open-plan home dining spaces | |
|---|---|---|
| hotel hospitality areas | Fits boutique hotel restaurant private dining rooms for guest seating | |
| high-end apartment common areas | Works for luxury residential building shared dining and lounge zones | |
| showroom display | Matches premium furniture showroom luxury contemporary dining collections | |
| small event banquet spaces | Supports flexible intimate event dining setups for 4 to 6 guests |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 12521:2015 | Domestic furniture strength/durability/stability for dining tables | |
|---|---|---|
| EN 15187:2007 | Furniture surface scratch resistance test standard for table tops |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk and table products performance standard for structural load testing |
|---|
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to hidden substrate structure | |
|---|---|---|
| GB/T 4893.1-2021 | Furniture surface cold liquid resistance test, applicable to stone top finish | |
| GB 28007-2011 | Furniture mechanical safety requirements, applicable to structural stability |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to hidden substrate structure; 2. GB/T 4893.1-2021:Furniture surface cold liquid resistance test, applicable to stone top finish; 3. GB 28007-2011:Furniture mechanical safety requirements, applicable to structural stability; 最终交付参数、检测报告和验收标准以双方采购合同为准。
