基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 680 × 700 × 1220 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Recommended user weight capacity | 160 kg | |
|---|---|---|
| Net weight | 21 kg | |
| Static base load reference | 900 kg | |
| Seat impact durability reference | 100000 cycles | |
| Caster rolling durability reference | 100000 cycles | |
| Back tilt durability reference | 200000 cycles | |
| Gas-lift service reference | 200000 height cycles | |
| Suitable users | 1 person | |
| Upholstery abrasion reference | 50000 Martindale rubs | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Back upholstery | Tan leather-faced or leather-match upholstery over segmented foam padding | |
|---|---|---|
| Seat upholstery | Tan leather-faced seating surface with matching side panels and padded front edge | |
| Seat foam | High-resilience polyurethane cushion foam, 100 mm thick with 45 kg/m3 density reference | |
| Back foam | Molded polyurethane back padding, 80 mm lumbar thickness and 35 kg/m3 density reference | |
| Head-zone padding | Integrated padded upper-back section, 60 mm foam thickness reference | |
| Internal seat shell | 12 mm molded plywood or engineered composite seat carrier with steel reinforcement | |
| Back frame | 20 mm tubular steel or bent plywood internal frame with upholstered outer panel | |
| Armrests | Upholstered fixed arm pads over rigid steel or molded support posts | |
| Tilt mechanism | Black powder-coated steel multi-position mechanism under the seat | |
| Gas lift | 50 mm polished steel class-4 gas lift with black upper collar | |
| Five-star base | Polished die-cast aluminum five-star base with five radiating legs | |
| Casters | Black nylon or polyurethane twin-wheel casters with steel swivel stems |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Height adjustment | Pneumatic seat-height adjustment through a 100 mm stroke using the visible side lever | |
|---|---|---|
| Swivel | 360-degree continuous swivel around the central gas-lift axis | |
| Recline action | Synchronized back tilt with a 15-degree rearward recline endpoint | |
| Tilt lock | One-position upright lock operated through the under-seat lever cluster | |
| Tilt tension | Manual tension adjustment by under-seat rotary control for user weight up to 160 kg | |
| Fixed arm support | Rigid upholstered armrests provide forearm support at 240 mm above the seat | |
| Mobility | Five 60 mm twin-wheel casters provide rolling movement on hard floors and low-pile carpet | |
| Lumbar support | Integrated raised lower-back cushion with 80 mm padded section for passive lumbar contact | |
| High-back support | Integrated upper-back and shoulder zone supports reclined executive seating | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive office | Fits a manager or director desk where a tan high-back chair supports 4 to 8 hours of desk work | |
|---|---|---|
| Meeting room | Suitable for conference seating around boardroom tables with hard-floor or low-pile carpet mobility | |
| Private home office | Works in a premium home office with wood, neutral, or warm-tone furniture | |
| Professional consulting rooms | Appropriate for advisory, legal, or financial meeting spaces requiring a polished client-facing chair | |
| Open-plan senior workstation | Can serve senior staff workpoints needing ergonomic height and recline adjustment | |
| Recommended floor conditions | Use directly on hard floors or low-pile carpet; add soft-floor replacement casters for high-pile carpet | |
| Recommended desk pairing | Pair with a 720 to 760 mm high executive desk and 600 mm minimum knee clearance | |
| Recommended Matching Desk Size | 2.4 m executive desk |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.1 |
|---|
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
本产品须满足以下技术参数要求: 1. 技术标准与检测报告由供应商在投标或采购确认阶段提供; 最终交付参数、检测报告和验收标准以双方采购合同为准。
