基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 660 × 680 × 1220 mm | |
|---|---|---|
| Armrest pad width | 60 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Recommended user weight capacity | 150 kg | |
|---|---|---|
| Net weight | 20 kg | |
| Seat foam density | 45 kg/m3 | |
| Back foam density | 35 kg/m3 | |
| Foam rebound value | 40% | |
| Suggested daily use duration | 8 hours | |
| Seating capacity | 1 person | |
| Gas lift vertical stroke | 80 mm | |
| Tilt recline angle | 15 degrees | |
| Caster rolling durability target | 100,000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Outer upholstery | Beige leather-look upholstered surface with stitched horizontal back division | |
|---|---|---|
| Seat cushion | 100 mm thick polyurethane foam pad over a load-bearing seat shell | |
| Back cushioning | Two-zone polyurethane foam padding with an 80 mm upper panel and 90 mm lumbar panel | |
| Internal seat shell | 12 mm thick molded plywood or engineered composite seat board | |
| Back inner frame | 18 mm thick plywood or steel-reinforced framed back board | |
| Armrests | Upholstered curved arms with integrated padded top and continuous side support | |
| Arm inner support | 25 mm diameter bent steel tubular insert | |
| Five-star base | Polished die-cast aluminum five-star base with five radiating legs | |
| Base wall thickness | 3 mm | |
| Gas lift | Chrome-plated steel telescopic gas cylinder with black lower collar | |
| Tilt mechanism | Black painted steel multi-lever tilt plate under the seat | |
| Casters | Black nylon twin-wheel casters with steel mounting stems |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| 360-degree swivel | Seat rotates fully around the central gas lift for side-to-side workstation access | |
|---|---|---|
| Gas-lift height adjustment | Paddle lever controls an 80 mm lift stroke, giving a maximum seat height of 530 mm | |
| Recline tilt | Back reclines 15 degrees from upright through the synchro-style tilt mechanism | |
| Tilt lock | 3-position lock retains upright, mid-recline or full-recline working angles | |
| Tilt tension control | Rear knob adjusts spring tension for users up to 150 kg | |
| Arm support | Integrated curved arms provide 230 mm forearm support above the seat | |
| Caster mobility | Five 60 mm twin-wheel casters provide omnidirectional movement on hard floors | |
| Single-person ergonomic support | High segmented back supports lumbar, shoulder and head regions for one occupant | |
| Stable parking base | 700 mm polished five-star base distributes load around the vertical lift axis | |
| Swivel caster braking target | Two of five casters include user-applied brake pedals for stationary work | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive office | Suitable for a 720 to 760 mm high executive desk where the user needs 450 to 530 mm seat-height adjustment. | |
|---|---|---|
| Private workstation | Supports 8-hour single-shift computer work with high-back padding and 360-degree swivel access. | |
| Conference room | Provides mobile guest or manager seating around board tables with five twin-wheel casters. | |
| Management meeting area | Fits formal meeting spaces due to beige upholstery, polished metal base and padded curved arms. | |
| Hotel business center | Supports temporary work and printing-station tasks with easy movement and quick height adjustment. | |
| Private consulting room | Provides one-person seating for interviews or advisory sessions with a restrained executive appearance. | |
| Home office | Suitable for professional home workrooms paired with a 720 to 760 mm desk and hard-floor protection mat. | |
| Recommended Matching Desk Size | 2.4 m executive desk |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| ANSI/BIFMA X5.1-2017 general-purpose office chair | recommended acceptance reference for static load, back, arm, base, swivel and durability tests. |
|---|
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB 18584-2001 Indoor decoration materials | limit of formaldehyde emission for wood-based furniture, applicable to hidden board components. | |
|---|---|---|
| GB/T 10357.3-2013 Test of mechanical properties of furniture | strength and durability of chairs and stools, recommended for acceptance testing. |
本产品须满足以下技术参数要求: 1. GB 18584-2001 Indoor decoration materials:limit of formaldehyde emission for wood-based furniture, applicable to hidden board components.; 2. GB/T 10357.3-2013 Test of mechanical properties of furniture:strength and durability of chairs and stools, recommended for acceptance testing.; 最终交付参数、检测报告和验收标准以双方采购合同为准。
