基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 680 × 700 × 1230 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Recommended user weight capacity | 160 kg | |
|---|---|---|
| Net weight | 22 kg | |
| Seat foam density | 45 kg/m3 | |
| Back foam density | 35 kg/m3 | |
| Foam rebound rating | 40% | |
| Recommended user height range | 1900 mm | |
| Seating capacity | 1 person | |
| Base static load rating | 500 kg | |
| Tilt mechanism durability | 100,000 cycles | |
| Gas-lift durability | 100,000 height cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Seat upholstery | Brown leather-look surface over padded cushion with piped perimeter; exact leather grade requires supplier BOM confirmation. | |
|---|---|---|
| Back upholstery | Continuous brown upholstered shell divided into upper, central, and lumbar padded zones; visible texture suggests leather or PU leather. | |
| Arm upholstery | Curved fixed arm pads and side cheeks covered in the same brown upholstery, attached to the seat-back shell. | |
| Seat cushion core | Molded polyurethane foam at 100 mm thickness, selected for executive-chair support and edge appearance. | |
| Back cushion core | Layered polyurethane padding at 70 mm thickness, creating the visible lumbar and head-zone padding breaks. | |
| Internal seat shell | 12 mm molded plywood or reinforced composite seat carrier supporting the cushion and mechanism. | |
| Back support frame | 1.5 mm steel inner frame or equivalent reinforced board structure hidden beneath upholstery. | |
| Five-star base | Polished chrome-plated metal five-star leg base with five outward-radiating support arms. | |
| Gas lift | Chrome-plated steel telescopic gas lift with black upper collar and 50 mm outer tube. | |
| Tilt mechanism | Black steel tilt plate under the seat with two visible side lever controls. | |
| Floor contacts | Five black non-swivel glide pads with chrome surrounds for hard-floor use. | |
| Fasteners and hinges | Steel bolts, hinge brackets, and control levers with black powder-coated or painted finish. |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| 360-degree swivel | Central swivel mount enables full 360-degree rotation around the gas-lift axis. | |
|---|---|---|
| Seat-height adjustment | Pneumatic lever provides 80 mm height travel from 450 to 530 mm while the occupant is seated. | |
| Backrest recline | Tilt mechanism reclines from upright 95 degrees to 115 degrees with lock positions at 95, 105, and 115 degrees. | |
| Tilt tension control | Rotary tension knob adjusts backward-recline resistance for users up to 160 kg. | |
| Fixed arm support | Matching upholstered arms provide 220 mm elbow support above the seat without height or width adjustment. | |
| Lumbar-contact support | Contoured lower back zone maintains padded contact at 220 mm above the seat. | |
| Single-lever upright lock | Recline lever locks the back in the upright 95-degree position for formal meeting use. | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive private office | Use behind a 720 to 760 mm executive desk for managers needing formal styling and 450 to 530 mm seat-height fit. | |
|---|---|---|
| Boardroom or meeting room | Place around conference tables for formal seated meetings, using glides to reduce unintended rolling. | |
| Consultation room | Use for client or supervisor meetings where a tall back and padded arms support 60 to 120 minute discussions. | |
| Hard-floor executive suite | Specify for wood, tile, or stone floors where five non-marring glides are preferred over twin-wheel casters. | |
| Traditional or contemporary management office | Pair with dark wood or leather-look case goods to maintain a coordinated brown and chrome interior. | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.1 |
|---|
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
本产品须满足以下技术参数要求: 1. 技术标准与检测报告由供应商在投标或采购确认阶段提供; 最终交付参数、检测报告和验收标准以双方采购合同为准。
