Two-Tone Modular Floor Storage Cabinet with Glass Doors and Drawers Specifications

MSC-2400TW-FS

代码:YBY2B3V1
获取供应商报价
2026-09-02 17:05人气: 26
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

MSC-2400TW-FS

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions2400 x 400 x 1880 mm
Left solid door section width400 mm
Smoked glass display column width320 mm
Single drawer front width347 mm
Open shelf compartment depth360 mm
Fluted decorative panel height300 mm
Lower curved cutout door height420 mm
Carcass panel thickness18 mm
Back panel thickness5 mm
Tempered glass door thickness5 mm
Edge band thickness1 mm
Adjustable shelf hole spacing32 mm
Door / Drawer Front Thickness22 mm
Shelf Thickness25 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Product net weight55 kg
Open shelf static load capacity25 kg
Tempered glass door impact resistance10 J
Door hinge open/close cycle rating50000 cycles
Drawer slide open/close cycle rating30000 cycles
Total internal storage volume1.52 m³
Shelf Distributed Load30 kg/shelf
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening Angle / Life165°; 80000 cycles
Anti-tip Fixing ReferenceProducts above 1200 mm should use at least 2 wall fixing points
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Main carcass panels18mm P2 grade MDF with matte off-white lacquer
Wood-tone drawer and door panels18mm particle board with light oak wood veneer
Vertical display compartments5mm smoked tempered glass framed in black metal trim
Middle decorative panel18mm MDF with vertical fluted ribbed off-white finish
Drawer and door hingesCold-rolled steel with soft-close hydraulic damping
Drawer slidesThree-section side-mount cold-rolled steel slides
Back panel5mm hardboard with matte finish
Base plinth18mm engineered wood with matching light wood veneer
Door catchesMagnetic ABS plastic catches for solid and glass doors
Edge banding1mm PVC matching panel finish on all exposed edges
Edge Band Thickness2 mm
Primary Connector SpecificationReference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Left solid door storageTwo vertically stacked swing doors open 110 degrees for concealed full-height storage
Upper open shelvesThree rows of divided open compartments for display and frequently accessed items
Smoked glass cabinetThree vertically stacked hinged glass doors for dust-protected display storage
Middle drawer storageThree equal-width soft-close drawers for small item organization in upper middle section
Curved lower door storageCurved-cutout swing door provides access to lower right open storage compartment
Adjustable shelvesAll open and glass-enclosed compartments support 32mm pitch height adjustment
Anti-tip safetyTwo wall-mounted anti-tip brackets secure tall cabinet to prevent forward tipping
Fluted decorative panelFixed fluted center panel adds textural contrast without operational function
Cable / Vent Opening ReferenceIf fitted, 80 mm diameter
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package Dimensions2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight100 kg/set in 3 cartons
Reference Packaging Volume0.65 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Modern living roomProvides mixed open and concealed storage for media accessories, decor and books
Home officeStores documents, office supplies and display items behind mixed door and shelf modules
Open-plan reception areaDisplays corporate decor and stores reception supplies in tidy mixed storage modules
Contemporary dining roomStores tableware, linens and display items with accessible drawer and shelf space
Recommended wall placementPosition against flat load-bearing wall secured with anti-tip hardware for stability
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 14749:2016Safety and strength requirements for domestic and kitchen storage furniture
EN 12521:2015Strength, durability and safety requirements for domestic storage furniture
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

北美市场选型与验收ANSI/BIFMA X5.9 办公储物单元
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to cabinet dimensional and structural tolerance
GB 18580-2017Formaldehyde emission limits for wood-based panels, applicable to panel material acceptance
GB/T 4893.4-2013Surface wear resistance test for furniture coatings, applicable to finish durability acceptance
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to cabinet dimensional and structural tolerance;
2. GB 18580-2017:Formaldehyde emission limits for wood-based panels, applicable to panel material acceptance;
3. GB/T 4893.4-2013:Surface wear resistance test for furniture coatings, applicable to finish durability acceptance;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · MSC-2400TW-FS

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · MSC-2400TW-FS

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · MSC-2400TW-FS打开导出工具

页面快速操作

发布采购询价

产品描述

The Two-Tone Modular Floor Storage Cabinet with Glass Doors and Drawers (model MSC-2400TW-FS) is an unbranded modern storage solution defined by a balanced mixed-material facade arranged in a linear, floor-standing profile. Its two-tone finish pairs matte off-white structural panels with light oak-toned drawer and door elements, arranged across distinct functional zones: a left full-height solid door section, central upper open display shelves, a vertical smoked glass display column, three equal-width upper-middle drawers, and a lower right compartment accessed via a curved-cutout swing door. A vertical fluted decorative panel adds subtle textural contrast between upper storage zones, while black metal trim frames glass elements for a polished, contemporary look. Constructed from durable engineered wood substrates, the cabinet’s 18mm main carcass uses P2 grade MDF finished in matte off-white lacquer, while wood-tone panels consist of 18mm particle board clad in light wood veneer. Vertical display compartments feature 5mm smoked tempered glass, with soft-close hydraulic damping cold-rolled steel hinges supporting 110-degree swing for solid and glass doors, and three-section side-mount cold-rolled steel slides for smooth drawer operation. Magnetic ABS plastic catches secure all doors, a 5mm matte hardboard forms the back panel, and a matching veneer engineered wood plinth creates a seamless base. Wall-mounted anti-tip brackets are included to secure the tall unit to supporting surfaces. Functionally, the cabinet delivers flexible mixed storage for varied use cases. The left solid door section offers full-height concealed storage, while three rows of divided upper open shelves hold frequently accessed items, and three stacked smoked glass doors protect displayed pieces from dust. Three soft-close drawers organize small items, and the lower curved-cutout door grants access to open lower storage. All open and glass-enclosed compartments support height adjustment for customizable storage configurations. This cabinet suits a range of residential and commercial spaces, including modern living rooms for media accessories, decor and books; home offices for documents, supplies and display pieces; open-plan reception areas for corporate decor and reception essentials; and contemporary dining rooms for tableware, linens and display items. It is designed for placement against flat load-bearing walls, secured with the included anti-tip hardware. For procurement, note that the unit ships split across cartons, requires assembly, and has a total internal storage volume suited to medium to large storage needs, with weight ratings aligned to general domestic and light commercial storage use.
