Automatic mm / inch conversion · Core engineering specifications
| Overall 3-seat sofa dimensions | 2240 x 760 x 900 mm | |
|---|---|---|
| Overall 2-seat sofa dimensions | 1590 x 760 x 900 mm | |
| Overall single-seat armchair dimensions | 940 x 760 x 900 mm | |
| Overall coffee table dimensions | 1200 x 600 x 450 mm | |
| Overall TV media console dimensions | 1800 x 400 x 450 mm | |
| Overall square side end table dimensions | 600 x 600 x 450 mm | |
| Sofa seat height from floor | 420 mm | |
| Sofa seat cushion depth | 580 mm | |
| TV console speaker cutout diameter | 180 mm | |
| Coffee table tabletop thickness | 40 mm | |
| Sofa under-seat drawer internal height | 150 mm | |
| Side table slatted shelf clearance from floor | 200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| 3-seat sofa total static load capacity | 408 kg | |
|---|---|---|
| Drawer slide rated cycle life | 50000 open/close cycles | |
| Total set combined net weight | 280 kg | |
| Cushion foam indentation load deflection | 40 kg/m³ density | |
| Upholstery fabric abrasion resistance | 30000 Martindale cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural sofa and table frames | Solid rubberwood with natural matte clear finish | |
|---|---|---|
| Drawer front panels | E0 grade MDF with matte off-white paint finish | |
| Drawer and door hardware pulls | Brushed gold-toned zinc alloy with polished finish | |
| Seat and back cushion core | High-density polyurethane foam with spring core support | |
| Seat and back cushion upholstery | Woven polyester linen-look fabric, removable for washing | |
| Table and console support legs | Solid rubberwood, tapered short style with floor protection pads | |
| Side table lower shelf | Solid rubberwood slatted construction, evenly spaced slats | |
| TV console speaker grille panels | Perforated solid wood matching frame finish | |
| Drawer slide hardware | Side-mounted 3-section ball bearing metal slides | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Sofa under-seat storage | Each seat position has a pull-out drawer for storing linens and items | |
|---|---|---|
| Sofa armrest side storage | Open built-in pockets on both armrests for books and remote controls | |
| Coffee table storage | Two front-facing soft-close drawers for media accessories and small items | |
| TV console mixed storage | Two central open media shelves, two side drawers, two end speaker compartments | |
| Side table storage | Lower slatted open shelf for magazines, decor or frequently used items | |
| Cushion cover maintenance | All seat and back cushion covers are removable for machine washing | |
| TV console ventilation | Circular end grilles provide airflow for built-in speakers or AV equipment | |
| Floor protection | All unit legs have non-slip felt pads to prevent hardwood floor scratches | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential living rooms | Suitable for 40sqm open-plan Nordic or modern style living spaces | |
|---|---|---|
| Apartment seating | Ideal for small to medium family apartments with integrated storage to save space | |
| Rental property furnishing | Durable construction with removable covers suitable for long-term rental properties | |
| Vacation home furnishing | Coordinated matching set removes need to source individual matching pieces | |
| Family daily use | Soft cushioning and accessible storage fits families with children for daily relaxation |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture strength, durability and safety for seating units | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units and worktops safety requirements | |
| EN 1022:2018 | Domestic furniture seating stability test standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to all wood frame and table components | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applies to wood finishes and boards | |
| GB/T 1952.1-2012 | General technical requirements for upholstered sofas, applies to all seating units | |
| GB 20400-2006 | Leather and fabric harmful substance limits, applies to sofa upholstery materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to all wood frame and table components; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applies to wood finishes and boards; 3. GB/T 1952.1-2012: General technical requirements for upholstered sofas, applies to all seating units; 4. GB 20400-2006: Leather and fabric harmful substance limits, applies to sofa upholstery materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
