Light Gray Performance Fabric L-Shaped Chaise Sectional Sofa with Tan Faux Leather Arm Panels (model SEC-LCH-3500-GY-TN) is listed under Apartment Sofa. Dimensions: 3500 × 1840 × 890 mm. Materials: Light gray stain-resistant performance tech fabric, 350g/sqm weight. Load capacity: 1000 kg. Product Features: Modern,minimalist,style,fixed,left,chaise,layout,upholstered,multi-seat,design,mixed-material,trim. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | Zhenxi Muye | Model | SEC-LCH-3500-GY-TN |
| Overall dimensions (W × D × H) | 3500 × 1840 × 890 mm | Seat height from floor | 440 mm |
| Main sofa seat depth | 760 mm | Chaise lounge extended length | 1840 mm |
| Armrest height above seat | 160 mm | Armrest panel width | 120 mm |
| Seat cushion thickness | 240 mm | Back cushion height above seat | 450 mm |
| Minimum required entry door width | 1370 mm | Throw pillow dimensions | 500 x 500 mm |
| Back Cushion Thickness | 160 mm | Leg Height / Floor Clearance | 160 mm |
| Total static load capacity | 1000 kg | Seating capacity | 4 persons |
| Seat core foam density | 45D | Foam rebound rate | 60% |
| Fabric abrasion resistance | 30000 Martindale cycles | Upholstered product net weight | 113 kg |
| Frame load cycle rating | 50000 use cycles | Standard limited warranty period | 365 days |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
| Seat and back cushion upholstery | Light gray stain-resistant performance tech fabric, 350g/sqm weight | Outer arm panels | Tan faux leather (cat-scratch resistant PU) with stitched panel seams |
| Internal structural frame | Kiln-dried solid hardwood and engineered hardwood composite, 30mm member thickness | Seat cushion core fill | High-density polyurethane foam wrapped with 2cm soft latex layer |
| Back cushion fill | Blown 3D hollow PP fiber with down-like softness | Support spring system | 100mm diameter sinuous zigzag springs spaced 80mm apart |
| Lower base enclosure | Matching gray performance fabric wrap with hidden black support glides | Seam construction | Reinforced polyester stitching with 8 stitches per 30mm pitch |
| Decorative throw pillows | 1 solid tan pillow, 1 black-and-white houndstooth pillow, removable covers | Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
| Cushion cover removability | All seat, back and throw pillow covers have hidden zippers for machine washing | Chaise orientation | Fixed left-facing chaise lounge for full-leg reclining, non-reversible design |
| Assembly requirement | Two-person assembly required for joining sections and attaching base glides, hardware included | Seat support function | Sinuous spring base prevents cushion sag over long-term repeated use |
| Armrest function | Wide low-profile armrests support padded arm resting and partial side seating | Cushion recovery function | High-resilience foam core regains 95% original shape within 10 seconds after loading |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods | Total shipping gross weight | 125 kg |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | Reference Packaging Volume | 1.8 m³/item |
| Reference Packaged Gross Weight | 110 kg/item | Residential living room main seating | Suits open-plan living spaces 25sqm or larger as primary seating group, 4-person capacity |
| Modern style apartment configuration | Matches minimalist, light luxury contemporary interiors with neutral and warm color palettes | Reclining lounge use | Extended chaise supports full-leg reclining for reading, watching TV or casual resting |
| Family media room placement | Deep plush cushions provide long-sitting comfort for regular home entertainment use | Open-concept lounge space | Low-profile silhouette does not block sightlines in rooms with arched openings or open layouts |
| Recommended pairing | Pair with nested round gold-frame coffee tables as shown for coordinated modern aesthetic | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3500 × 1840 × 890 mm | |
|---|---|---|
| Seat height from floor | 440 mm | |
| Main sofa seat depth | 760 mm | |
| Chaise lounge extended length | 1840 mm | |
| Armrest height above seat | 160 mm | |
| Armrest panel width | 120 mm | |
| Seat cushion thickness | 240 mm | |
| Back cushion height above seat | 450 mm | |
| Minimum required entry door width | 1370 mm | |
| Throw pillow dimensions | 500 x 500 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static load capacity | 1000 kg | |
|---|---|---|
| Seating capacity | 4 persons | |
| Seat core foam density | 45D | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Upholstered product net weight | 113 kg | |
| Frame load cycle rating | 50000 use cycles | |
| Standard limited warranty period | 365 days | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back cushion upholstery | Light gray stain-resistant performance tech fabric, 350g/sqm weight | |
|---|---|---|
| Outer arm panels | Tan faux leather (cat-scratch resistant PU) with stitched panel seams | |
| Internal structural frame | Kiln-dried solid hardwood and engineered hardwood composite, 30mm member thickness | |
| Seat cushion core fill | High-density polyurethane foam wrapped with 2cm soft latex layer | |
| Back cushion fill | Blown 3D hollow PP fiber with down-like softness | |
| Support spring system | 100mm diameter sinuous zigzag springs spaced 80mm apart | |
| Lower base enclosure | Matching gray performance fabric wrap with hidden black support glides | |
| Seam construction | Reinforced polyester stitching with 8 stitches per 30mm pitch | |
| Decorative throw pillows | 1 solid tan pillow, 1 black-and-white houndstooth pillow, removable covers | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cushion cover removability | All seat, back and throw pillow covers have hidden zippers for machine washing | |
|---|---|---|
| Chaise orientation | Fixed left-facing chaise lounge for full-leg reclining, non-reversible design | |
| Assembly requirement | Two-person assembly required for joining sections and attaching base glides, hardware included | |
| Seat support function | Sinuous spring base prevents cushion sag over long-term repeated use | |
| Armrest function | Wide low-profile armrests support padded arm resting and partial side seating | |
| Cushion recovery function | High-resilience foam core regains 95% original shape within 10 seconds after loading | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total shipping gross weight | 125 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room main seating | Suits open-plan living spaces 25sqm or larger as primary seating group, 4-person capacity | |
|---|---|---|
| Modern style apartment configuration | Matches minimalist, light luxury contemporary interiors with neutral and warm color palettes | |
| Reclining lounge use | Extended chaise supports full-leg reclining for reading, watching TV or casual resting | |
| Family media room placement | Deep plush cushions provide long-sitting comfort for regular home entertainment use | |
| Open-concept lounge space | Low-profile silhouette does not block sightlines in rooms with arched openings or open layouts | |
| Recommended pairing | Pair with nested round gold-frame coffee tables as shown for coordinated modern aesthetic |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture strength, durability and safety requirements for seating, applicable for residential use | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignition resistance to smouldering cigarette fire safety standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame strength and dimensional tolerances | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood furniture, ≤0.124mg/m³ requirement | |
| GB/T 1952.1-2012 | Upholstered furniture sofa safety and performance standard for durability and stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame strength and dimensional tolerances; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood furniture, ≤0.124mg/m³ requirement; 3. GB/T 1952.1-2012: Upholstered furniture sofa safety and performance standard for durability and stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
