Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3500 × 1050 × 820 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth | 700 mm | |
| Seat width per position | 800 mm | |
| Back cushion height | 480 mm | |
| Armrest width | 200 mm | |
| Armrest height from floor | 620 mm | |
| Base clearance from floor | 20 mm | |
| Back cushion thickness | 220 mm | |
| Seat cushion thickness | 280 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static load capacity | 480 kg | |
|---|---|---|
| Sofa net weight | 135 kg | |
| Fabric abrasion resistance | 45000 Martindale cycles | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Back foam density | 30 kg/m³ | |
| Seam stitch pitch | 3 mm | |
| Warranty period | 3 years | |
| Available color variants | 6 | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery fabric | Performance technical fabric, water-repellent and stain-resistant surface | |
|---|---|---|
| Inner load-bearing frame | Kiln-dried solid pine wood, 30mm section thickness | |
| Seat support system | Sinuous spring suspension, 4mm gauge steel springs spaced 100mm apart | |
| Seat cushion fill | Multi-layer high-resilience foam with 20mm top soft foam layer | |
| Back cushion fill | Blown polyester fiber wrap over foam core | |
| Armrest decorative trim | Polished gold-finish 10mm wide metal strip along outer arm edge | |
| Base structure | Padded fabric-wrapped block frame, no visible separate legs | |
| Included throw pillows | 2 pieces, 1 light grey solid, 1 black-white houndstooth patterned | |
| Frame hardware | Zinc-plated steel corner brackets and dowel joinery | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cushion configuration | Three separate full-width back cushions, two one-piece deep seat cushions | |
|---|---|---|
| Upholstery design | Zippered removable cushion covers for spot cleaning and maintenance | |
| Armrest design | Integrated wide padded armrests on both ends, no adjustable components | |
| Seat support function | Sinuous spring suspension reduces pressure points across full seat width | |
| Delivery configuration | Split two-section design for residential entry access | |
| Throw pillow support | Two matching decorative throw pillows included as standard configuration | |
| Base stability | Low center of gravity floor-adjacent base prevents tipping during use | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Shipping carton dimensions | 1850 x 1100 x 700 mm per carton | |
|---|---|---|
| Total shipping gross weight | 155 kg | |
| 20ft container loading quantity | 18 units | |
| 40ft HQ container loading quantity | 44 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room main seating | Four-person capacity suitable for open-plan living areas for family and guest use | |
|---|---|---|
| Modern minimalist interior design | Warm orange finish with gold trim matches contemporary, Italian minimalist decor schemes | |
| Apartment large open lounge space | Low-profile deep seat design ideal for relaxed lounging and casual entertaining | |
| Hotel suite lounge area | Durable performance fabric suitable for high-use boutique hospitality seating | |
| Open concept home media space | Deep seat support for extended seated use during movie watching and leisure |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture strength, durability and safety requirements for seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance to smouldering cigarette source |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame components | |
|---|---|---|
| GB 20400-2006 | Leather and fabric furniture environmental protection limit for formaldehyde and harmful substances | |
| GB/T 1952.1-2012 | Strength and durability test standard for upholstered sofas for domestic use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame components; 2. GB 20400-2006: Leather and fabric furniture environmental protection limit for formaldehyde and harmful substances; 3. GB/T 1952.1-2012: Strength and durability test standard for upholstered sofas for domestic use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
