Name: Nordic Two-Tone Light Wood and White TV Media Console with Round Porthole Glass Doors
Brand: Zhenxi Muye
SKU: EV6QB7

Time

Field

Original Value

Corrected Value

Note / Status

No correction records yet. Found an error? Click the flag at the end of a row to report it.

PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2000 × 400 × 480 mm
Leg height	120 mm
Under-unit floor clearance	100 mm
Central open media bay width	480 mm
Glass door cabinet internal width	380 mm
Drawer internal width	320 mm
Tabletop thickness	30 mm
Carcass side panel thickness	18 mm
Back panel cable opening diameter	60 mm
Internal adjustable shelf height in glass cabinets	220 mm
Drawer internal depth	330 mm
Round glass porthole diameter	180 mm
Maximum supported TV size	70 in
Carcass Panel Thickness	25 mm
Back Panel Thickness	9 mm
Door / Drawer Front Thickness	22 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Tabletop static load capacity	50 kg
Product net weight	52 kg
Surface scratch resistance	2H pencil hardness
Drawer slide cycle rating	50000 open/close cycles
Door hinge cycle rating	80000 open/close cycles
Finish VOC emission grade	E0
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Angle / Life	165°; 80000 cycles
Anti-tip Fixing Reference	Products above 1200 mm should use at least 2 wall fixing points

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Frame and tabletop	Solid rubberwood with clear matte natural finish
End cabinet door fronts	White matte painted MDF with clear tempered round glass inserts
Central drawer fronts	White matte painted MDF with small brass-finish metal pull handles
Support legs	Solid tapered rubberwood legs with natural finish
Cabinet and drawer hardware	Brass-plated zinc alloy pulls, concealed soft-close hinges, ball-bearing slides
Internal shelves	18 mm thick solid rubberwood adjustable shelves
Back panel	3 mm thick MDF with pre-cut cable management openings
Glass door inserts	5 mm thick clear tempered safety glass
Finish coating	Matte water-based polyurethane wood sealant
Edge Band Thickness	2 mm
Primary Connector Specification	Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Storage layout	Two end glass-door cabinets, two central drawers, two open media bays
Cable management	Pre-cut rear openings in open media bays for AV cord routing
Ventilation design	Open-front media bays with rear clearance for AV equipment heat dissipation
Drawer operation	Soft-close full-extension ball-bearing drawer slides with pull handles
Cabinet door operation	Soft-close concealed hinges with magnetic door catches and pull knobs
Adjustable shelving	Single position-adjustable shelf in each glass door cabinet
Surface protection	Rounded edge profiling on all corners to reduce impact injury
Floor protection	Felt floor protection pads pre-installed on leg bases
Cable / Vent Opening Reference	80 mm diameter; recommend 4rear cable/vent openings

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Residential living room	Placed against seating-facing wall for TV setup and media storage
Apartment and small home spaces	Low-profile design fits compact floor plans without blocking sightlines
Coordinated living room sets	Matches complementary solid wood sofas and coffee tables in light wood/white finish
Media equipment storage	Open bays accommodate routers, set-top boxes, game consoles and AV receivers
Decor display	Flat tabletop supports vases, photo frames, trays and decorative accessories
Display storage	Glass door cabinets showcase collectibles while protecting items from dust

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 312:2010	Specification for particleboard and MDF panels used in carcass and door construction
EN 12521:2015	Safety, strength and durability requirements for residential storage furniture including cabinets and consoles
EN 13722:2004	Performance requirements for furniture drawer slides and cabinet door hardware

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to dimensional and structural quality checks
GB 18584-2001	Indoor decorating and refurbishing materials – limit of harmful substances of wood based furniture, required for formaldehyde emission verification
GB/T 4893.4-2013	Furniture surface test – determination of adhesion and wear resistance for finished wood surfaces

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural quality checks;
2. GB 18584-2001: Indoor decorating and refurbishing materials – limit of harmful substances of wood based furniture, required for formaldehyde emission verification;
3. GB/T 4893.4-2013: Furniture surface test – determination of adhesion and wear resistance for finished wood surfaces;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · TVC-RW2000-WHGD

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · TVC-RW2000-WHGD

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · TVC-RW2000-WHGDOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Zhenxi Muye TVC-RW2000-WHGD is a Nordic-style floor-standing two-tone TV and media console balancing refined visual appeal and practical utility. Its design pairs light natural wood tones with crisp white accents, featuring a streamlined low-profile silhouette anchored by tapered solid rubberwood legs, with rounded edge profiling across all corners for safer everyday interaction. The facade balances open and closed storage: two central open media bays sit flanked by end cabinets fitted with round porthole-style clear tempered glass doors, with two central drawers positioned between the open bays, accented by understated brass-finish hardware that complements the warm wood and matte white palette. Crafted for long-term residential use, the console’s frame and tabletop are built from solid rubberwood sealed with a matte water-based polyurethane finish, with a 30 mm thick tabletop rated for 50 kg static load, and 18 mm thick carcass side panels. End cabinet and drawer fronts use white matte painted MDF; the glass door inserts are 5 mm clear tempered safety glass, while each enclosed cabinet includes an 18 mm thick position-adjustable solid rubberwood shelf rated for 30 kg distributed load. Hardware includes brass-plated zinc alloy pulls, concealed soft-close hinges tested for 80,000 open/close cycles, and full-extension ball-bearing drawer slides rated for 50,000 cycles, alongside magnetic door catches for secure closure. The 3 mm thick back panel features pre-cut openings for cable routing, and the 100 mm under-unit clearance supports air flow, while the open media bays include rear clearance to support heat dissipation for stored electronics. The surface finish delivers 2H pencil hardness scratch resistance, with E0 grade VOC emissions for low indoor environmental impact. Functionally, the console offers mixed storage for media devices, decor and personal items: open bays accommodate routers, set-top boxes, game consoles and AV receivers, glass-door cabinets showcase collectibles while blocking dust, drawers hold small loose accessories, and the flat tabletop supports decorative pieces like vases, photo frames and display trays. Pre-cut rear cable openings simplify organized cord routing for AV setups, and soft-close hardware reduces operational noise and wear. This console is suited for residential living rooms placed on walls facing seating areas for TV setups, compact apartment and small home spaces where its low-profile form avoids blocking sightlines, and coordinated living room layouts paired with complementary light wood and white solid wood sofas and coffee tables. For procurement, note the unit ships in multiple cartons with a total packaged gross weight of 100 kg per set, requires 40 minutes of on-site assembly per unit, and is designed for floor-standing placement without wall mounting hardware included.
