Automatic mm / inch conversion · Core engineering specifications
| Overall set layout footprint | 3800 x 3200 mm | |
|---|---|---|
| 3-seat sofa dimensions | 2280 x 760 x 900 mm | |
| 2-seat loveseat dimensions | 1590 x 760 x 900 mm | |
| Single armchair dimensions | 940 x 760 x 900 mm | |
| Sofa seat height | 420 mm | |
| Sofa seat depth | 580 mm | |
| Coffee table dimensions | 1200 x 600 x 450 mm | |
| TV/media console dimensions | 2000 x 400 x 450 mm | |
| Side end table dimensions | 600 x 600 x 600 mm | |
| Table top thickness | 25 mm | |
| Sofa armrest width | 120 mm | |
| Under-seat storage compartment depth | 350 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Per-seat static load capacity | 150 kg | |
|---|---|---|
| Coffee table top distributed load | 50 kg | |
| TV console top distributed load | 80 kg | |
| Complete set total net weight | 280 kg | |
| Cushion foam density | 40 kg/m³ | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Recommended user capacity | 6 adults total across all seating pieces | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa and table frame material | Solid rubberwood with clear natural lacquer finish | |
|---|---|---|
| Upholstery fabric | Off-white cotton-linen blend, removable covers | |
| Cushion fill material | High-density polyurethane foam with top dacron wrap | |
| Table drawer and door panels | E0-grade MDF with matte white paint finish | |
| TV console door insets | 8mm tempered frosted circular glass panels | |
| Hardware components | Zinc alloy gold-finish pulls and hinges | |
| Table legs and sofa feet | Solid cylindrical rubberwood legs, 60mm diameter | |
| Side table lower shelf | Slatted solid rubberwood construction | |
| Joinery construction | Mortise-and-tenon frame joints with metal screw reinforcement | |
| Cushion cover seam pitch | 8 stitches per inch | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Sofa under-seat storage | Lift-up seat cushions reveal 350mm deep enclosed storage compartments | |
|---|---|---|
| Removable cushion covers | Zip-off fabric covers allow machine washing for easy maintenance | |
| Coffee table storage | Two full-extension smooth-glide drawers for remote controls and small items | |
| TV console mixed storage | Two frosted glass cabinet doors, three central drawers, two open media slots | |
| Side table storage | Lower slatted open shelf for magazines, coasters or small decor items | |
| Cable management | 2 x 60mm cable ports at rear of TV console for AV cord routing | |
| Hardware soft-close mechanism | Drawer slides and door hinges include 100000-cycle soft-close damping | |
| Floor protection | All furniture feet include non-scratch felt pads | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room use | Ideal for 40sqm modern, Scandinavian or Japanese-style living spaces | |
|---|---|---|
| Small apartment layout fit | Compact storage-integrated design suitable for urban small-family apartments | |
| Family and guest use | Seats up to 6 people comfortably for daily family use or small gatherings | |
| Matching decor compatibility | Light wood and off-white palette pairs well with neutral, bohemian or coastal decor styles | |
| Coastal or sunroom installation | Durable solid wood construction suitable for bright sunroom or lake-view living areas | |
| Recommended decor pairing | Pair with neutral low-pile area rug and linen curtains for cohesive minimalist look |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture strength, durability and safety requirements for seating | |
|---|---|---|
| EN 14749:2016 | Safety and performance requirements for domestic storage units and tables | |
| EN 1022:2018 | Stability testing standard for domestic seating furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and panel construction | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for interior decoration wooden furniture, E0 grade recommended | |
| GB/T 1952.1-2012 | Safety and durability requirements for upholstered sofas for residential use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and panel construction; 2. GB 18584-2001: Formaldehyde emission limit for interior decoration wooden furniture, E0 grade recommended; 3. GB/T 1952.1-2012: Safety and durability requirements for upholstered sofas for residential use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
