Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3200 x 1080 x 850 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat depth | 680 mm | |
| Seat cushion thickness | 250 mm | |
| Back cushion height | 500 mm | |
| Armrest width | 240 mm | |
| Armrest height | 600 mm | |
| Leg height | 20 mm | |
| Back cushion thickness | 180 mm | |
| Clearance under sofa | 15 mm | |
| Seat width per module | 1360 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total weight | 95 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seat foam density | 50 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Frame structural warranty | 10 years | |
| Upholstery and cushion warranty | 2 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Inner frame | Kiln-dried solid fir and plywood, moisture content ≤12% | |
|---|---|---|
| Seat suspension | 50 mm wide elastic webbing, spaced 80 mm apart | |
| Seat cushion core | High-density polyurethane foam wrapped in 30 mm polyester fiber | |
| Back cushion core | Blown polyester fiber fill with foam core support | |
| Upholstery fabric | 380 g/m² matte olive green woven performance fabric | |
| Armrest structure | Padded foam core wrapped in matching upholstery fabric | |
| Support feet | Black matte ABS plastic with non-slip thermoplastic pads | |
| Piping trim | Matching fabric piped edge along all cushion and arm seams | |
| Throw pillows (included) | 1 light gray fabric pillow, 1 black-and-white houndstooth fabric pillow | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Module connection | Slot-in metal bracket locking system between adjacent seat modules | |
|---|---|---|
| Cushion placement | Loose, non-fixed seat and back cushions for easy repositioning | |
| Cover maintenance | Zippered removable cushion covers for spot cleaning or replacement | |
| Seating configuration | Straight 3-seat lounge layout with wide armrests on both ends | |
| Weight distribution | Evenly distributed load support across full seat surface via elastic webbing | |
| Non-marking feet | Non-slip thermoplastic foot pads to protect hard flooring from scratches | |
| Posture support | Semi-reclined 105° backrest angle for relaxed lounging | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Primary application space | Residential living room, open-plan lounge or home leisure area | |
|---|---|---|
| Target users | Households requiring 3-seat deep lounge seating for daily relaxation and guest use | |
| Recommended pairing | Low nested glass or metal coffee tables and soft textured area rugs | |
| Style compatibility | Contemporary, minimalist, wabi-sabi and modern casual interior design schemes | |
| Space requirement | Minimum 3800 mm wall length to accommodate sofa and side clearance | |
| Secondary use case | Upscale office reception lounge or residential open-plan waiting area |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable European standard for domestic seating strength, durability and safety requirements | |
|---|---|---|
| EN 1021-1:2019 | Applicable standard for upholstered furniture resistance to ignition by smouldering cigarette |
Standards applicable to China-market projects
| GB 18401-2010 Category B | Applicable national safety standard for formaldehyde and harmful substance limits in upholstery textiles | |
|---|---|---|
| GB/T 35607-2017 | Applicable standard for evaluation of furniture upholstery fabric performance and durability |
This product must meet the following technical requirements: 1. GB 18401-2010 Category B: Applicable national safety standard for formaldehyde and harmful substance limits in upholstery textiles; 2. GB/T 35607-2017: Applicable standard for evaluation of furniture upholstery fabric performance and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
