| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 400 x 450 mm | |
|---|---|---|
| Side drawer internal dimensions | 480 x 330 x 150 mm | |
| Central open cubby internal dimensions | 260 x 360 x 220 mm | |
| Tapered leg height | 120 mm | |
| Top panel thickness | 18 mm | |
| Carcass panel thickness | 15 mm | |
| Back panel thickness | 9 mm | |
| Open shelf thickness | 15 mm | |
| Drawer front panel thickness | 18 mm | |
| Leg diameter at floor contact | 30 mm | |
| Drawer pull diameter | 60 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 50 kg | |
|---|---|---|
| Product net weight | 38 kg | |
| Recommended maximum TV size | 75 in | |
| Drawer slide cycle rating | 30000 open/close cycles | |
| Moisture content of wood components | 12% | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top surface | Solid pine or rubberwood with clear matte water-based lacquer | |
|---|---|---|
| Body carcass | E1-grade medium density fiberboard with natural oak veneer | |
| Support legs | Solid rubberwood tapered legs, matching natural wood finish | |
| Drawer fronts | Solid wood panels with recessed circular ring pulls | |
| Drawer glides | Cold-rolled steel side-mount glides, optional soft-close damping | |
| Back panel | Hardboard with pre-cut cable management openings | |
| Open shelf surfaces | Veneered engineered wood, edge-banded to prevent chipping | |
| Pull hardware | Zinc alloy circular ring pulls, brushed brass finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Side-mounted steel glides with full extension access for stored items | |
|---|---|---|
| Cable management | Pre-cut 60mm diameter openings at rear of each open cubby | |
| Ventilation design | 10mm gap between open shelf rear and back panel | |
| Surface protection | Rounded edge profiling on all top and panel corners | |
| Stability anchoring | Included anti-tip wall anchor kit for earthquake/tip prevention | |
| Storage configuration | Two enclosed side drawers plus three equal central open cubbies | |
| Leveling adjustment | Small plastic floor glides on each leg base | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room media placement | Positioned against main wall opposite seating to hold flat-screen TV and AV devices | |
|---|---|---|
| Small to medium apartment use | 1800mm length fits 4 m wide living room walls without overcrowding | |
| Open-concept living space | Low 450mm height preserves sight lines across open plan living areas | |
| Matching set configuration | Pairs with coordinating solid wood coffee table and sofa set for cohesive living room decor | |
| Media equipment organization | Open bays provide easy access to set-top boxes, game consoles and soundbars | |
| Secondary storage use | Drawers store remote controls, media discs, blankets and small living room accessories |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Domestic furniture strength, durability and safety requirements for storage units | |
|---|---|---|
| EN 717-1:2004 | Wood-based panel formaldehyde emission test method, E1 class reference | |
| EN 14749:2016 | Safety and structural requirements for domestic and kitchen storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to dimensional and structural tolerances | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for indoor wooden furniture, E1 grade ≤0.124mg/m³ requirement | |
| GB/T 4893.9-2013 | Surface wear resistance test for furniture finishes, applicable to top surface durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to dimensional and structural tolerances; 2. GB 18584-2001: Formaldehyde emission limit for indoor wooden furniture, E1 grade ≤0.124mg/m³ requirement; 3. GB/T 4893.9-2013: Surface wear resistance test for furniture finishes, applicable to top surface durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
