Automatic mm / inch conversion · Core engineering specifications
| Overall assembled size | 2160 x 1800 x 1130 mm | |
|---|---|---|
| Mattress platform size | 1800 x 2000 mm | |
| Headboard overall size | 1800 x 1130 x 180 mm | |
| Headboard grid layout | 6 vertical columns and 2 horizontal padded panels | |
| Individual headboard panel size | 280 x 430 x 70 mm | |
| Platform base height | 300 mm | |
| Side rail size | 2050 x 180 x 35 mm | |
| Foot rail size | 1800 x 300 x 35 mm | |
| Upper sleep-surface height | 650 mm | |
| Under-bed clearance | 20 mm | |
| Nightstand clearance per side | 500 mm walkway and 450 mm nightstand width | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Recommended user capacity | 2 adults | |
|---|---|---|
| Static bed-system load | 363 kg | |
| Mattress and bedding weight allowance | 90 kg | |
| Slat count | 14 slats | |
| Slat clear spacing | 120 mm | |
| Center support legs | 3 legs | |
| Foam density for procurement | 35 kg/m3 | |
| Foam rebound | 40 percent | |
| Net weight reference | 68 kg | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Beige velvet-look polyester fabric with woven nap | |
|---|---|---|
| Headboard padding | 35 kg/m3 polyurethane foam under grid-stitched fabric | |
| Panel substrate | 18 mm engineered board behind upholstered headboard and rails | |
| Side and foot rails | Timber or engineered-wood rails wrapped in matching beige fabric | |
| Slat support system | 80 mm wide solid timber slats on a central support rail | |
| Structural hardware | Carbon steel corner brackets, bolts and center support legs | |
| Base plinth | Fabric-upholstered lower frame with recessed dark support strip | |
| Seam construction | Sunken fabric seams forming the rectangular grid face | |
| Mattress shown | Light gray woven fabric mattress with bordered edge | |
| Backing fabric | Non-woven dust cover under the slat platform | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| Platform support | Timber slats carry the mattress directly without requiring a box spring | |
|---|---|---|
| Headboard comfort | Two rows of foam-filled panels provide padded back support for seated reading | |
| Grid retention | Recessed seams divide padding into 12 fixed soft panels and limit foam migration | |
| Assembly method | Bolt-together headboard, side rails, foot rail, slats and center legs | |
| Mattress retention | Upholstered side and foot rails surround the mattress and reduce lateral movement | |
| Floor protection | Recessed plinth contact points isolate fabric from routine floor abrasion | |
| Storage status | No gas-lift hinge, handle or drawer front is visible, so the published model is a non-storage platform bed | |
| Ventilation | 120 mm slat gaps allow air circulation beneath the mattress | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary bedroom | Suits a contemporary main bedroom where a wide padded headboard forms the focal point | |
|---|---|---|
| Hotel or serviced apartment | Suitable for upscale rooms needing a soft, low-profile bed and compact bedside clearance | |
| Double-occupancy use | Designed for two adults with an 1800 x 2000 mm mattress platform | |
| Dark feature-wall interiors | Works with charcoal or wood-grain walls and metallic task lamps | |
| Low-profile bedding scheme | Pairs best with a 300 mm mattress and tailored cover for a 650 mm sleep surface | |
| Bedroom groups | Can be procured with matching beige, taupe, gray or charcoal fabric accent furniture |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture safety, strength and durability requirements for beds | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating stability principles may guide bed stability test setup |
Standards applicable to China-market projects
| GB/T 3324-2024 | General technical requirements for wooden furniture, applicable to frame strength, dimensions and workmanship | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel brackets and support legs | |
| GB 18584-2001 | Indoor decorative materials limit formaldehyde release from wood-based furniture components | |
| GB/T 10357.6-2013 | Furniture mechanical surface test for beds, applicable to static load and stability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2024: General technical requirements for wooden furniture, applicable to frame strength, dimensions and workmanship; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel brackets and support legs; 3. GB 18584-2001: Indoor decorative materials limit formaldehyde release from wood-based furniture components; 4. GB/T 10357.6-2013: Furniture mechanical surface test for beds, applicable to static load and stability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
