Automatic mm / inch conversion · Core engineering specifications
| Overall bed dimensions | 2100 x 2300 x 950 mm | |
|---|---|---|
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Recommended user capacity | 2 adults | |
|---|---|---|
| Frame static load capacity | 350 kg | |
| Mattress platform distributed load | 250 kg | |
| Mattress retention lip height | 100 mm | |
| Net weight | 75 kg | |
| Color options | 1 visible grey finish | |
| Warranty target | 36 months | |
| Fabric seam service target | 50000 rub cycles | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| External upholstery | Grey woven fabric with soft matte surface | |
|---|---|---|
| Headboard padding | High-resilience polyurethane foam behind fabric | |
| Side and foot rail padding | Foam-cushioned upholstered panels with edge piping | |
| Internal support frame | Plywood and engineered-wood rail frame | |
| Mattress support | Plywood board or closely spaced slat base | |
| Frame internal board thickness | 18 mm | |
| Corner joining hardware | Metal brackets, bolts, and wood dowels | |
| Feet or base | Floor-bearing upholstered base without exposed legs | |
| Stitching and seams | Visible panel seams with dark matching thread | |
| Surface treatment | Soft-touch fabric over padded panels | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support | Fixed platform support accepts an 1800 x 2000 mm mattress without a box spring | |
|---|---|---|
| Headboard comfort | Two padded vertical backrest panels provide cushioned shoulder and head support | |
| Mattress location | Raised upholstered perimeter holds the mattress and limits lateral movement | |
| Bed access | Low 450 mm sleeping height allows entry from both sides and the foot end | |
| Assembly method | Knockdown headboard, side rails, foot rail, and support deck join with bolts and brackets | |
| Storage configuration | No drawers or lift-up storage are visible on the exterior | |
| Floor contact | Continuous base distributes load directly to the floor | |
| Bedding fit | Wide platform accommodates two large pillows and layered king-size bedding | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Headboard carton dimensions | 2050 x 320 x 650 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary bedroom | Suitable for a king-size bed in a modern master bedroom | |
|---|---|---|
| Hotel guest room | Appropriate for upscale hotel rooms requiring a soft, low-profile upholstered bed | |
| Serviced apartment | Suits long-stay apartments needing a complete platform bed without a box spring | |
| Contemporary residential suite | Fits minimalist interiors using grey fabric and low floor-hugging lines | |
| Bedroom display or showroom | Useful for lifestyle staging with layered bedding and contrasting pillows | |
| Buyer specification | Recommended where quiet soft edges and wide rail surround are preferred over storage beds |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
