PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1820 × 2180 × 1180 mm
Mattress opening	1800 x 2000 mm
Headboard visible height	1180 mm
Headboard thickness	180 mm
Footboard height	360 mm
Side rail height	360 mm
Sleeping surface height	480 mm
Under-bed clearance	150 mm
Leg height	150 mm
Side rail thickness	90 mm
Footboard thickness	90 mm
Slat width	70 mm
Slat spacing	70 mm
Center support count	2 longitudinal rails and 4 support legs
Recommended mattress thickness	300 mm
Nightstand clearance beside bed	600 mm minimum

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight	54 kg
Static load capacity	450 kg
Mattress weight allowance	75 kg
Occupant capacity	2 adults
Slat support quantity	14 slats
Platform edge load	120 kg
Fastener torque recommendation	12 Nm
Foam density target	35 kg/m3
Foam rebound target	35 percent
Seam stitch density	8 stitches per 25 mm

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Headboard upholstery	Woven padded fabric in mustard olive green
Headboard padding	Polyurethane foam channel cushions, 60 mm thick target
Side rail upholstery	Matching woven fabric over rigid rail boards
Footboard panel	Padded fabric-covered engineered wood panel
Internal frame	Solid hardwood and engineered wood rail frame
Platform board	18 mm plywood or laminated engineered wood support deck
Support slats	18 mm bentwood or laminated plywood slats
Center supports	Black powder-coated steel support rail with floor legs
Bed legs	25 mm black powder-coated steel tube, angled profile
Rail hardware	M8 cam bolts and barrel nuts with locking washers
Fabric backing	Non-woven fabric dust cover under the slat system
Seam construction	Sewn channel divisions with 8 stitches per 25 mm target

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Platform support	Removable wood slats carry the mattress directly without a box spring.
Headboard comfort	Three horizontal padded channels provide a soft backrest for seated reading.
Fixed upholstered surround	Fabric-covered side rails and footboard retain the mattress and conceal the support frame.
Raised leg design	Four angled metal legs provide 150 mm under-bed access for cleaning and low storage bins.
Center support system	Two longitudinal rails and four floor legs reduce slat deflection across the queen span.
Bolted assembly	Headboard, side rails, footboard, slats and legs join with knockdown hardware for flat-pack delivery.
Mattress ventilation	Open slat gaps provide underside airflow and reduce trapped moisture.
Fixed sleeping configuration	No recline, lift, drawer or folding mechanism is present in the visible frame.
Floor protection	Hard plastic ferrules on metal legs isolate finished floors and reduce lateral slip.
Edge entry support	Reinforced side rail and footboard construction support seated entry and bed-making loads.
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2300× 900× 450 mm/carton in 4 cartons
Reference Packaged Gross Weight	130 kg/set
Reference Packaging Volume	0.9 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Main bedroom	Suits a queen-bed room with two adults and coordinated bedside storage.
Modern residential interior	Mustard olive upholstery and slim black legs fit contemporary or boutique styling.
Hotel guest room	Padded headboard and platform support are suitable for durable room refurbishment.
Serviced apartment	Knockdown packaging and no-box-spring design simplify furnishing and replacement.
Bedroom reading area	Tall soft headboard supports seated use with pillows against the wall.
Compact luxury interior	Low footboard and open under-bed clearance preserve visual space in smaller rooms.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1725:1998	Safety, strength and durability requirements applicable to domestic beds.
EN 13722:2004	Test methods covering static load, impact, fatigue and stability for furniture beds.
EN 1022:2018	Stability test method applicable to assembled freestanding domestic seating and bed-edge behavior where relevant.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to frame dimensions, workmanship and stability.
GB/T 3325-2017	Metal furniture technical requirements, applicable to the steel legs and support components.
GB 18580-2017	Formaldehyde emission limit for wood-based panels used in the bed frame.
GB/T 10357.6-2013	Test method for furniture strength and durability, applicable to single-bed static and fatigue testing.

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame dimensions, workmanship and stability.;
2. GB/T 3325-2017: Metal furniture technical requirements, applicable to the steel legs and support components.;
3. GB 18580-2017: Formaldehyde emission limit for wood-based panels used in the bed frame.;
4. GB/T 10357.6-2013: Test method for furniture strength and durability, applicable to single-bed static and fatigue testing.;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · UPB-CH-Q-1800-BLKLEG

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · UPB-CH-Q-1800-BLKLEG

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · UPB-CH-Q-1800-BLKLEGOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Channel-Tufted Upholstered Platform Bed presents a modern low-profile sleeping centerpiece defined by a tall padded headboard, fully upholstered side rails, and a matching fabric footboard. Its mustard olive green woven upholstery is paired with slim angled black metal legs, giving the frame a contemporary, boutique-style appearance. The headboard uses three horizontal padded channels for a structured tufted look, while the consistent 360 mm height of the footboard and side rails creates a clean, tailored surround that conceals the support structure and helps retain the mattress. Overall dimensions are 1820 x 2180 x 1180 mm, with a 1800 x 2000 mm mattress opening and a 480 mm sleeping surface height. Construction combines a solid hardwood and engineered wood rail frame with a padded woven fabric exterior. The headboard cushions use polyurethane foam channel padding, and the footboard is a fabric-covered engineered wood panel. The platform features an 18 mm plywood or laminated engineered wood support deck with removable wood slats, supplied in a set of 14. Two longitudinal black powder-coated steel rails and four floor legs reinforce the queen-width span, while the bed rests on angled 25 mm black powder-coated steel tube legs. The frame is rated for two adults, with a 450 kg static load capacity, a 75 kg mattress weight allowance, and a 120 kg platform edge load. Designed for direct mattress use, the slatted platform removes the need for a box spring. Open gaps between slats allow underside airflow, and the padded headboard offers a soft backrest for reading or sitting up in bed. Four angled legs provide 150 mm of under-bed clearance for cleaning access and low-profile storage bins. Knockdown hardware connects the headboard, side rails, footboard, slats, and legs, supporting flat-pack delivery and on-site assembly; the recommended fastener torque is 12 Nm. The bed is well suited to main bedrooms with coordinated bedside storage, modern residential interiors, compact luxury rooms, hotel guest rooms, and serviced apartments. Its low footboard and open base preserve visual space, while the upholstered surround lends a refined residential feel. Procurement planning should account for the unbranded model UPB-CH-Q-1800-BLKLEG, queen-size mattress compatibility, two-adult use, assembly coordination, and packaged delivery details listed as one set across two cartons with a reference packaged gross weight of 130 kg.

Channel-Tufted Upholstered Platform Bed with Upholstered Side Rails Specifications
