Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1920 x 2220 x 1100 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard total height | 1100 mm | |
| Footboard height | 350 mm | |
| Sleeping surface height | 450 mm | |
| Under-bed clearance | 180 mm | |
| Side rail thickness | 50 mm | |
| Headboard upholstered panel thickness | 80 mm | |
| Support leg cross-section | 60 x 60 mm | |
| Brass accent diameter at rail joints | 30 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 500 kg | |
|---|---|---|
| Slat count for king size base | 16 pieces | |
| Single slat static load | 60 kg | |
| Center support beam count | 2 pieces | |
| Slat spacing | 50 mm | |
| Headboard upholstery foam density | 45 kg/m³ | |
| Product net weight | 150 kg | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Frame and rails | Dark walnut-tone solid hardwood, sealed scratch-resistant matte finish | |
|---|---|---|
| Headboard central panel | Beige woven linen-look fabric upholstery over high-density foam | |
| Support legs | Solid hardwood matching frame finish, 4 corner-mounted units | |
| Decorative hardware | Brass-finish metal accents at rail and headboard joints | |
| Bed base slats | Solid plywood slats with sanded smooth surface | |
| Center support beams | 40mm thick solid wood beams with metal connecting brackets | |
| Footboard panel | Solid wood panel matching frame finish, full width low profile | |
| Fasteners | Zinc-plated steel bolts and barrel nuts for KD assembly | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Base support | Fixed slatted platform base, supports mattress directly without box spring | |
|---|---|---|
| Assembly structure | Knock-down assembly with pre-drilled holes, compatible with home or professional installation | |
| Floor protection | Equipped with adjustable plastic foot pads under each leg to prevent floor scratches | |
| Headboard design | Vertical slat wood frame surrounding padded upholstered panel for back support when sitting upright | |
| Storage configuration | No built-in under-bed drawers or pneumatic lift storage, open clearance for under-bed bins | |
| Connection system | Metal bracket connectors between side rails, headboard and footboard for structural rigidity | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Master bedrooms in residential homes, modern Chinese style interiors | |
|---|---|---|
| Compatible mattress type | 1800x2000mm spring, memory foam or latex mattresses, no box spring required | |
| Recommended matching furniture | Coordinating dark wood nightstands, dressers and upholstered leisure chairs from same collection | |
| User group suitability | Adult users seeking low-profile, solid wood bedroom furniture with soft headboard comfort | |
| Installation requirement | Two-person assembly recommended, compatible with standard residential bedroom ceiling heights |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture beds and mattresses safety and strength requirements | |
|---|---|---|
| EN 1022:2005 | Domestic furniture seating stability test method, applicable for edge load |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame durability testing | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wooden furniture | |
| GB/T 26706-2011 | Furniture upholstered mattress and sofa fabric abrasion resistance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame durability testing; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wooden furniture; 3. GB/T 26706-2011: Furniture upholstered mattress and sofa fabric abrasion resistance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
