PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2000 × 2250 × 1150 mm
Side Rail Thickness	40 mm
Slat Spacing	80 mm
Center Support Leg Count	Recommended 6legs

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight	85 kg
Recommended mattress weight	55 kg
Static bed-system load	450 kg
Recommended occupant capacity	2 adults
Slat support spacing	65 mm
Slat static point load	35 kg per slat
Leg compressive load target	120 kg per leg
Fabric abrasion acceptance target	30000 Martindale cycles
Upholstery color options	4 colorways
Warranty reference	5 years frame and 2 years upholstery

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Headboard upholstery	Woven soft-touch fabric over padded grid-tufted panel
Foot-rail upholstery	Matching woven fabric with continuous channel-tufted front face
Side-rail padding	High-resilience polyurethane padding wrapped around timber or composite rail
Internal load frame	Kiln-dried hardwood-composite frame with engineered-wood panels
Mattress support	Bentwood or laminated slats seated in a central steel support rail
Support legs	Four square hardwood-composite legs with dark matte finish
Frame hardware	Powder-coated steel bolts, corner brackets, and barrel nuts with M8 thread specification
Headboard core panel	18 mm engineered-wood backing board with padded fiber and foam layers
Padding specification	35 kg/m3 polyurethane foam with 200 g/m2 polyester fiber wrap
Fabric face weight	320 g/m2 woven upholstery textile
Seam construction	Self-fabric piped or stitched tuft seams at 80 mm stitch pitch
Floor contact pads	Polyethylene or felt glide pads bonded to each leg base

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Sleeping function	Fixed king-size platform providing two-adult support on an 1800 x 2000 mm mattress
Tufted head support	Padded 1150 mm headboard provides seated back support and pillow retention
Mattress support system	Slatted platform ventilates beneath the mattress and distributes load across a central rail
Mattress restraint	Raised upholstered side and end rails retain the mattress with a 20 mm recessed platform
Under-bed cleaning access	120 mm open clearance permits floor cleaning and limited low-profile storage access
Delivery and assembly	Knockdown headboard, side rails, foot rail, slat roll, and leg pack join with cam and bolt fittings
Orientation	Single-sided placement with the tall padded panel intended against a wall
Floor stabilization	Four fixed legs transfer load directly without casters, preventing sleep-surface movement
Upholstery maintenance	Removable dust and light soiling by low-moisture fabric cleaning; fixed upholstery is not machine-washable
Seam geometry	Repeated square tuft bays at 115 mm centers create the visible structured facade
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Headboard carton	2080 x 260 x 240 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2300× 900× 450 mm/carton in 4 cartons
Reference Packaged Gross Weight	130 kg/set
Reference Packaging Volume	0.9 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Primary bedroom	Suits a 2800 mm-wide or larger bedroom wall where the 2000 mm headboard creates a central focal point
Modern residential interior	Pairs with dark walls, warm ambient lighting, soft rugs, and floating bedside cabinets
Hotel guest room	Applicable to upscale rooms requiring a soft, impact-resistant padded headboard and low foot rail
Serviced apartment	Suitable for long-stay units where two adults need a fixed platform bed without moving casters
Pairing furniture	Use with 500 mm-high bedside tables and pendant lights suspended beyond the headboard corners
Floor condition	Recommended on wood, tile, or low-pile carpet with felt-pad protection under all four legs
User profile	Designed for adult users seeking a soft contemporary bed rather than lift-storage or bunk functionality

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1725:1998	Use as domestic bed safety, strength, and durability acceptance reference
EN 1021-1:2014	Use for cigarette ignition smouldering upholstery assessment if flame-retardant supply is required
EN 717-1:2004	Use for formaldehyde release verification by chamber method if panel substrates are supplied

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	Use for dimensional tolerances, structural inspection, and wooden furniture general technical requirements
GB 18584-2001	Use for indoor wooden furniture formaldehyde emission limits
GB/T 3325-2017	Use for metal furniture inspection where steel rails, bolts, and support bars are included

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: Use for dimensional tolerances, structural inspection, and wooden furniture general technical requirements;
2. GB 18584-2001: Use for indoor wooden furniture formaldehyde emission limits;
3. GB/T 3325-2017: Use for metal furniture inspection where steel rails, bolts, and support bars are included;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · BED-UPH-1800-CHT-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · BED-UPH-1800-CHT-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · BED-UPH-1800-CHT-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Channel-Tufted Upholstered Bed with Tall Padded Headboard presents a refined modern bedroom focal point through its fully upholstered form, tall padded headboard, matching foot rail, and low-profile platform base. Its continuous channel tufting gives the headboard and footboard a structured, tailored appearance, while soft-touch woven upholstery creates a calm residential or hospitality look. The bed is designed for single-sided placement, with the tall headboard positioned against a wall and the low foot rail preserving an open visual feel. Its fixed king-size platform supports an 1800 x 2000 mm mattress and is intended for two adults. Construction combines a kiln-dried hardwood-composite internal frame with engineered-wood panels, a central steel support rail, and four square hardwood-composite legs in a dark matte finish. Bentwood or laminated slats rest across the central rail to support and ventilate the mattress, while powder-coated steel bolts, corner brackets, and barrel nuts secure the frame. Padding uses high-resilience polyurethane foam and a polyester fiber wrap beneath the woven fabric. Side rails are padded around timber or composite rails, and the headboard uses an engineered-wood backing board with padded fiber and foam layers. Functionally, the tall tufted headboard offers seated back support and helps retain pillows. Raised upholstered side and end rails hold the mattress within a recessed platform, reducing lateral movement. The slatted base allows air circulation beneath the mattress and distributes weight across the central support structure. Open under-bed clearance provides access for floor cleaning and limited low-profile storage. The bed arrives in knockdown form, with separate headboard, rails, slat roll, and leg components joined with cam and bolt fittings. This upholstered bed suits modern primary bedrooms, particularly as a central feature on a wide wall, as well as hotel guest rooms and serviced apartments. Its soft padded surfaces work well in spaces seeking comfort and visual warmth, while the low footboard supports a clean, unobstructed room layout. It pairs naturally with bedside tables, ambient lighting, soft rugs, and floating case goods. Procurement planning should account for the unbranded BED-UPH-1800-CHT-01 model, multi-carton delivery, assembly time, and packaged weight. Buyers should also confirm delivery access, floor protection with felt pads, and compatibility with wood, tile, or low-pile carpet. The fixed, caster-free design is best suited to installations where the bed will remain in a stable planned position.

Channel-Tufted Upholstered Bed with Tall Padded Headboard Specifications
