Automatic mm / inch conversion · Core engineering specifications
| Headboard dimensions | 1930 x 180 x 1200 mm | |
|---|---|---|
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Recommended static bed load | 350 kg | |
|---|---|---|
| Nightstand top load | 25 kg per cabinet | |
| Drawer load | 10 kg per drawer | |
| Mattress weight capacity | 55 kg | |
| Occupant capacity | 2 adults | |
| Suggested mattress thickness | 250 mm | |
| Nightstand net weight | 22 kg per cabinet | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Light gray padded upholstery over six vertical soft channels | |
|---|---|---|
| Headboard internal support | 30 mm engineered-board or hardwood channel backing with foam padding | |
| Side rail upholstery | Matching light gray upholstered rail with padded outer face and rigid board core | |
| Foot rail | Low upholstered board rail with corner-sewn cover and black supporting leg | |
| Support legs | Black tapered hard-plastic or powder-coated metal legs, 150 mm high | |
| Bed base slats | Horizontal plywood or engineered-wood slat system on a central support rail | |
| Nightstand carcass | 18 mm melamine-faced engineered board with light gray exterior | |
| Nightstand drawer fronts | Two smooth light gray panel fronts with recessed horizontal black pulls | |
| Nightstand legs | Four black tapered legs matching the bed legs | |
| Drawer runners | Side-mounted roller or ball-bearing drawer slides with full or 3/4 extension | |
| Upholstery foam | 30 mm polyurethane foam on headboard and 20 mm foam on rails | |
| Fastening hardware | Cam bolts, wood dowels, corner brackets, and floor-protecting leg pads |
Adjustment / rotation / tilt / mobility / storage features
| Sleeping configuration | Platform bed accommodates one 1800 x 2000 mm mattress without requiring a box spring | |
|---|---|---|
| Headboard support | Tall padded headboard provides seated back support and six independent vertical soft channels | |
| Under-bed access | 150 mm open clearance permits robot vacuum access and limited under-bed storage bins | |
| Bedside storage | Each freestanding nightstand provides two vertically stacked drawers for personal and bedside items | |
| Bedside work surface | 520 x 420 mm cabinet top supports a lamp, phone, drink, book, or decorative object | |
| Installation method | Knock-down assembly using upholstered headboard, side rails, foot rail, slats, legs, and bedside cabinets | |
| Style configuration | Bed is flanked by two matching nightstands, creating a symmetric double-bedside layout | |
| Floor protection | Small foot pads at the base of tapered legs reduce floor scratching and improve leveling | |
| Storage limitation | Nightstand drawers are suited to compact items and are not designed as wardrobe or wardrobe-depth storage | |
| Mattress retention | Upholstered side and foot rails contain the mattress perimeter and reduce lateral movement | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Master bedroom | Suitable for an 1800 mm wide two-adult sleeping area with matching bedside storage on both sides | |
|---|---|---|
| Hotel guest room | Appropriate for upscale economy or boutique hotel rooms needing a soft headboard and compact nightstands | |
| Apartment furnishing | Suitable for serviced apartments and rental suites requiring one coordinated bed and two storage cabinets | |
| Modern residential interior | Light gray channel headboard and black tapered legs fit neutral contemporary interiors | |
| Low-ceiling room | Low-profile upholstered rails reduce visual bulk while the tall headboard anchors the bed | |
| Hard-floor bedroom | Recommended for wood, tile, or laminate floors with protective pads under all tapered legs |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
