Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2050 x 2250 x 1150 mm | |
|---|---|---|
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Recommended user count | 2 adults | |
|---|---|---|
| Recommended distributed static load | 350 kg | |
| Headboard impact load per panel | 50 kg | |
| Recommended mattress weight | 55 kg | |
| Net weight | 78 kg | |
| Weight capacity per support leg | 70 kg | |
| Recommended mattress thickness | 280 mm | |
| Color options for procurement | 2 SKUs | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Woven light-gray fabric over shaped padding with embossed flowing-line relief | |
|---|---|---|
| Headboard padding | High-resilience polyurethane foam and soft polyester wadding over curved panel | |
| Headboard core panel | 18 mm curved engineered-wood or composite panel | |
| Side and foot rails | Fabric-upholstered padded rails with stitched corner joints | |
| Platform support base | Reinforced wood or steel bed frame with timber slat deck | |
| Support slats | 12 plywood slats, 60 mm wide and 12 mm thick | |
| Front legs | Gold-toned tubular metal legs, 25 mm diameter | |
| Internal joining hardware | Bolted bed-rail connectors and corner brackets with M8 fasteners | |
| Mattress retainer | Concealed metal or timber center stopper at head end | |
| Surface stitching | Single-needle seam construction with 8 mm seam pitch | |
| Floor contact pads | Injected plastic or rubber protective glides on each metal leg | |
| Slat Thickness | 15 mm bent plywood or solid timber |
Adjustment / rotation / tilt / mobility / storage features
| Sleeping configuration | Two-person king platform supporting an 1800 x 2000 mm mattress | |
|---|---|---|
| Headboard design | Two independent curved padded panels forming one continuous rounded envelope | |
| Back support | Padded headboard provides upright reading support over a 250 mm exposed zone | |
| Bed entry | Three-sided entry from left, right, and foot with 120 mm under-bed clearance | |
| Mattress retention | Inset platform and head-end stopper limit lateral and rearward mattress movement | |
| Assembly method | Knock-down assembly using bolted rails, separate headboard panels, and screw-in legs | |
| Under-bed maintenance | 120 mm open clearance permits robot vacuum access and dry floor cleaning | |
| Center support | Three longitudinal support zones and a center rail reduce mattress sag | |
| Floor protection | Removable glides distribute leg pressure and isolate metal from hard flooring | |
| Style customization | Replaceable upholstery color and leg finish can be quoted at order placement | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Total gross weight | 88 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary bedroom | Suits a 14 sq m or larger residential bedroom where a soft sculptural bed is the focal element | |
|---|---|---|
| Hotel guest room | Fits upscale boutique hotel rooms using one upholstered king bed and soft neutral finishes | |
| Pairing furniture | Pairs with 450 mm-high nightstands positioned beside the 520 mm sleeping surface | |
| Interior style | Works in contemporary, minimalist, and warm neutral schemes with rounded furniture forms | |
| User group | Designed for two adults seeking a low platform bed with soft back support | |
| Flooring compatibility | Suitable for polished tile, timber, vinyl, or rug-covered floors with protective glides | |
| Bedding selection | Use a 280 mm-thick king mattress and oversized bedding to preserve headboard relief visibility |
EU Market Access Requirements* EN Standards
| Bed safety recommendation | EN 1725 structural safety requirements for domestic beds | |
|---|---|---|
| Durability recommendation | EN 1957 test methods for bed strength and durability using defined static and cyclic loads |
Standards applicable to China-market projects
| Formaldehyde emission recommendation | Recommended references: GB/T 39600 | |
|---|---|---|
| Furniture safety recommendation | GB/T 3324 general technical requirements for wooden furniture dimensions and workmanship | |
| Upholstered furniture fire recommendation | GB 17927 assessment for burning behavior of upholstered bedding furniture |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: Recommended references: GB/T 39600; 2. Furniture safety recommendation: GB/T 3324 general technical requirements for wooden furniture dimensions and workmanship; 3. Upholstered furniture fire recommendation: GB 17927 assessment for burning behavior of upholstered bedding furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
