Automatic mm / inch conversion · Core engineering specifications
| Side Rail Thickness | 40 mm | |
|---|---|---|
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Recommended static bed load | 350 kg | |
|---|---|---|
| Mattress support capacity | 80 kg | |
| Recommended occupant capacity | 2 adults | |
| Platform slat spacing | 70 mm | |
| Net weight reference | 95 kg | |
| Packaged gross weight reference | 115 kg | |
| Fabric seam pull target | 300 N | |
| Frame cyclic load target | 10000 cycles | |
| Pillow display capacity | 4 pillows | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Charcoal woven textile with a raised interlaced surface over the headboard, side rails and foot rail | |
|---|---|---|
| Headboard padding | High-loft soft padding under woven fabric with rounded perimeter roll | |
| Bed surround padding | Padded panels on the foot and side rails, producing a soft rounded outer edge | |
| Internal support frame | Engineered timber or plywood load-bearing frame with corner blocking | |
| Mattress support system | Flat slatted timber or composite platform inside the upholstered frame | |
| Base construction | Recessed dark plinth or concealed support rail beneath the upholstered surround | |
| Edge treatment | Fabric-wrapped rounded corners and continuous border without exposed hard trim | |
| Upholstery attachment | Tacked or stapled fabric over padded panels with concealed fixings | |
| Hardware | Concealed cam bolts, brackets and joinery plates for headboard and rail assembly | |
| Mattress retention | Raised upholstered perimeter around the mattress platform | |
| Fabric finish | Matte charcoal-black woven surface with tonal variation | |
| Internal filling reference | 25 mm polyurethane padding over rigid panels in the surround and 40 mm padding in the headboard |
Adjustment / rotation / tilt / mobility / storage features
| Sleeping configuration | Provides a fixed king-size sleeping platform for a 1800 x 2000 mm mattress | |
|---|---|---|
| Headboard function | Full-height padded panel supports seated reading and pillows while forming a complete visual backstop | |
| Mattress location | Recessed platform holds the mattress inside the padded side and foot surround | |
| Bed access | Three-side access is supported by the open side layout, with a fixed upholstered foot rail | |
| Under-bed function | 20 mm shadow clearance allows floor cleaning access but not practical storage use | |
| Assembly method | Knock-down headboard, side rails, foot rail and slat platform connect with concealed fittings | |
| Surface maintenance | Woven removable-dust upholstery requires vacuuming and spot cleaning; fabric removability is not visible | |
| Stability design | Wide floor-contacting perimeter platform distributes load and eliminates the need for protruding legs | |
| Storage provision | No lift mechanism, drawer fronts or external handles are visible, so fixed non-storage construction is specified | |
| Bedding retention | Padded 150 mm side and foot borders help retain duvets and define the mattress zone | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Headboard carton dimensions | 2150 x 250 x 1300 mm | |
|---|---|---|
| Rail carton dimensions | 2200 x 420 x 220 mm | |
| Hardware and slat carton dimensions | 2050 x 320 x 120 mm | |
| Packaged gross weight | 115 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary bedroom | Suits a spacious modern main bedroom where the charcoal woven bed is the visual focal point | |
|---|---|---|
| Boutique hotel suite | Fits luxury or design-led hotel rooms requiring a soft, tactile bed with durable perimeter protection | |
| Residential master suite | Pairs with light stone floors, sheer glazing and minimal side tables as shown in the room setting | |
| Urban penthouse | Appropriate for high-end apartments seeking a low-profile bed with a tall padded backrest | |
| Two-adult use | Designed for a 1800 mm king mattress and simultaneous use by two adults | |
| Interior design showhome | Suitable for styled photography or display suites because the textured charcoal fabric adds depth without patterns | |
| Low-clearance bedroom | Works where under-bed storage is not required and a nearly floor-level silhouette is preferred |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Applies to safety, strength and durability requirements for domestic beds | |
|---|---|---|
| EN 1022:2018 | Applies to stability determination for seating but may inform headboard/back-support assessment only where relevant | |
| EN 71-3:2019+A1:2021 | Applies to migration of certain elements if child-use fabric or coating claims are made |
Standards applicable to China-market projects
| GB/T 3324-2024 | Applies to general technical requirements for wooden furniture used in the upholstered bed frame | |
|---|---|---|
| GB/T 3325-2017 | Applies to metal furniture hardware and strength requirements if metal connectors are used | |
| GB 18580-2017 | Applicable standards and test results require confirmation |
This product must meet the following technical requirements: 1. GB/T 3324-2024: Applies to general technical requirements for wooden furniture used in the upholstered bed frame; 2. GB/T 3325-2017: Applies to metal furniture hardware and strength requirements if metal connectors are used; 3. GB 18580-2017: Applicable standards and test results require confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
