Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 1000 x 750 mm | |
|---|---|---|
| Tabletop thickness | 18 mm | |
| Pedestal width (along table width) | 220 mm | |
| Pedestal depth (along table length) | 450 mm | |
| Minimum knee clearance height under top | 680 mm | |
| Foot clearance cutout height at pedestal base | 120 mm | |
| Tabletop edge bevel width | 5 mm | |
| Pedestal mounting offset from short edge | 150 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load capacity | 300 kg | |
|---|---|---|
| Seating capacity | 8 people | |
| Surface heat resistance | 180 °C | |
| Surface abrasion resistance | 4 grade | |
| Metal base wall thickness | 8 mm | |
| Net product weight | 140 kg | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 18mm polished light calacatta-veined sintered stone | |
|---|---|---|
| Pedestal supports | 8mm thick gunmetal black powder-coated carbon steel | |
| Mounting hardware | Zinc-plated steel M8 connector bolts | |
| Underside support frame | 1.5mm thick powder-coated steel cross bracing | |
| Foot pads | 8mm thick non-slip TPE adjustable glides | |
| Tabletop edge finish | Polished beveled stone edge | |
| Metal surface finish | Matte black powder coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Assembly type | Knock-down assembly required | |
|---|---|---|
| Seating access | Open knee clearance on all four sides | |
| Leveling adjustment | 10mm height adjustment via TPE foot glides | |
| Surface maintenance | Wipe-clean non-porous stone top | |
| Pedestal foot clearance | Arched base cutouts at each support | |
| Color options | 2 standard finishes | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room | Suitable for 8person family meals and casual gatherings | |
|---|---|---|
| Open-plan kitchen dining area | Minimalist silhouette complements modern and light-luxury interior styles | |
| Restaurant private dining rooms | Durable stone surface withstands high-frequency commercial use | |
| Hotel suite dining areas | Polished finish matches upscale hospitality interior specifications | |
| Showroom display | Pairs with upholstered dining chairs to showcase contemporary dining sets |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applicable for structural load testing | |
|---|---|---|
| EN 15185:2011 | Furniture - Assessment of surface resistance to abrasion, applicable for tabletop finish durability | |
| EN 15186:2011 | Furniture - Assessment of surface resistance to staining, applicable for stone top cleanability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for hardware assembly and structural stability | |
|---|---|---|
| GB 6566-2010 | Limit of radionuclides in building materials, applicable for natural stone/sintered stone top radiological safety | |
| GB/T 4893.9-2013 | Furniture surface test for heat resistance, applicable for stone top hot cookware contact performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for hardware assembly and structural stability; 2. GB 6566-2010: Limit of radionuclides in building materials, applicable for natural stone/sintered stone top radiological safety; 3. GB/T 4893.9-2013: Furniture surface test for heat resistance, applicable for stone top hot cookware contact performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
