PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 720 × 780 × 1180 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 28 kg | |
|---|---|---|
| Maximum static user weight capacity | 180 kg | |
| Recommended user height range | 1900 mm | |
| Swivel rotation range | 360 degrees | |
| Tilt mechanism static load rating | 200 kg | |
| Caster rolling durability cycles | 40000 cycles | |
| Seam stitch pitch | 8 mm | |
| Standard warranty period | 3 years | |
| Available color options | 2 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | 1.2mm thick black faux leather (PU) | |
|---|---|---|
| Cushion core foam | 45kg/m³ high-density polyurethane foam | |
| Armrest and side support frame | Polished medium-hardness solid wood with glossy lacquer finish | |
| Internal support frame | 1.5mm thick welded steel tube | |
| Gas lift cylinder | 100mm diameter Class 3 steel gas lift | |
| Tilt mechanism plate | 3mm thick stamped steel with black powder coat | |
| Five-star base | Chrome-plated steel frame wrapped in matching faux leather | |
| Caster wheels | Black nylon with chrome-plated steel stem | |
| Control button panel | Black plastic adjustment panel on left wood side panel | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Five-star Base Material Thickness | Metal base wall 3.5 mm; diameter 700 mm |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | 100mm vertical seat height travel via gas lift | |
|---|---|---|
| Backrest tilt function | 15 degree recline angle with infinite position lock | |
| 360-degree swivel | Full rotational movement around central vertical axis | |
| Mobility function | Smooth rolling on hard floors and low-pile carpet via dual-wheel casters | |
| Lumbar support | Contoured built-in lumbar zone with 80mm foam padding | |
| Integrated headrest | Fixed curved padded support for neck and upper back | |
| Arm support | Fixed curved polished wood armrests for stable forearm rest | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Formal seating for senior management desks, matching traditional wood office furniture | |
|---|---|---|
| Conference meeting room | Formal guest or host seating for boardrooms and high-level meeting spaces | |
| Executive reception area | Comfortable premium seating for important visitor waiting areas | |
| Home office study | High-back supportive seating for long-duration remote work in residential offices | |
| Government/agency office | Formal durable seating for institutional and administrative office environments | |
| Management workstation open plan | Seating for team lead and department head workstations in open office layouts | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
No standards data is available for this market.
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.1 |
|---|
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
No standards data is available for this market.
Standardized tender description text
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
