Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 3250 x 1020 x 737 mm | |
|---|---|---|
| Module count | 5 connected seat modules | |
| Individual seat module | 650 x 1020 x 737 mm | |
| Seat width per position | 650 mm | |
| Seat depth | 610 mm | |
| Seat height above floor | 420 mm | |
| Backrest height above seat | 317 mm | |
| Armrest height above seat | 150 mm | |
| Armrest pad size | 620 x 220 x 120 mm | |
| Front apron height | 260 mm | |
| Pillow count | 4 loose pillows | |
| Pillow size | 450 x 450 mm | |
| Curved inner seating radius | 1800 mm | |
| Floor clearance | 0 mm | |
| Total floor area | 3.32 m2 | |
| Seat Cushion Thickness | 180 mm |
Net weight / load capacity / users / durability
| Recommended occupants | 5 adults | |
|---|---|---|
| Total static seating load | 295 kg | |
| Per-seat static load | 100 kg | |
| Product net weight | 88 kg | |
| Seat foam density | 35 kg/m3 | |
| Back pillow fill density | 25 kg/m3 | |
| Foam rebound rating | 45% | |
| Cushion recovery time after unpacking | 72 h | |
| Fabric abrasion acceptance level | 30000 Martindale cycles | |
| Fabric mass | 380 g/m2 |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main upholstery | Mustard polyester chenille-looking woven textile with visible plush pile | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam with soft polyester fiber wrap | |
| Back cushions | Soft fiber-filled padded backs with rounded edge tailoring | |
| Loose pillows | Four removable fabric pillows with contrasting woven covers | |
| Internal support frame | Solid wood or engineered-wood sectional frame with concealed joinery | |
| Seat suspension | Elastic webbing support layer over timber rails, 80 mm webbing target | |
| Module connection hardware | Concealed metal side connector plates between adjoining modules | |
| Base panel | Upholstered floor-resting plinth without exposed legs | |
| Arm cushion | Integrated padded arm wrapped in the same mustard textile | |
| Seam construction | Tailored perimeter seams with 70 mm visible cushion segmentation | |
| Fabric finish | Soft tactile pile surface in solid mustard color with woven tonal variation | |
| Protective floor treatment | Concealed non-marking fabric or felt bottom glides recommended |
Adjustment / rotation / tilt / mobility / storage features
| Seating layout | Five-position continuous inward-facing arc for group conversation | |
|---|---|---|
| Modular arrangement | Five upholstered sections join side-to-side to form one sweeping sectional | |
| Reconfiguration method | Modules can be separated at side connectors and re-locked in matching curved sequences | |
| Back support | Low integrated padded back with four movable loose pillows for lumbar and shoulder support | |
| Arm support | Padded low arms at both ends define the seating boundary without blocking sight lines | |
| Lounge posture | Deep 610 mm seat permits relaxed, slightly reclined seating with throw-pillow support | |
| Stationary use | Floor-resting design without recline, swivel, fold, or storage mechanisms | |
| Floor protection | Continuous upholstered plinth distributes load and avoids exposed hard feet | |
| Cushion maintenance | Loose pillows and tailored seat pads permit rotation and fabric surface vacuuming | |
| Room zoning | Arc shape creates a defined lounge zone around a central low table | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Suits a large lounge or open-plan family room requiring five-seat conversation seating. | |
|---|---|---|
| Showroom or design studio | Mustard finish and organic arc create a strong display piece around a low coffee table. | |
| Hotel lobby lounge | Suitable for soft-seating breakout zones where guests face each other in a relaxed arc. | |
| Executive hospitality area | Works in informal meeting and reception spaces using low-profile residential styling. | |
| Retail lounge | Fits fashion, automotive, or furniture showrooms needing photogenic modular guest seating. | |
| Recommended pairing | Pair with a 1100 mm organic coffee table centered inside the curve. | |
| Circulation requirement | Provide 700 mm clear access behind the arc for walking and pillow adjustment. |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
