Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 560 × 560 × 560 mm | |
|---|---|---|
| Tabletop usable diameter | 480 mm | |
| Top rim height | 30 mm | |
| Upper drawer front height | 200 mm | |
| Lower drawer front height | 220 mm | |
| Recessed drawer pull gap height | 20 mm | |
| Drawer interior depth | 380 mm | |
| Drawer interior width | 440 mm | |
| Base plinth height | 40 mm | |
| Foot glide height | 5 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 45 kg | |
|---|---|---|
| Total product net weight | 20 kg | |
| Drawer slide cycle rating | 20000 open/close cycles | |
| Upholstery abrasion resistance | 30000 Martindale cycles | |
| Adjustable foot leveling range | 10 mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Internal frame | 18 mm thick E1-grade MDF engineered wood | |
|---|---|---|
| Exterior upholstery | 1.2 mm thick beige faux leather with contrast edge stitching | |
| Top rim and base plinth | Dark brown walnut wood veneer over MDF substrate | |
| Drawer boxes | 12 mm thick MDF with fabric-lined interior bottoms | |
| Drawer slides | Cold-rolled steel side-mount silent extension glides | |
| Foot glides | Nylon-tipped adjustable leveling glides | |
| Drawer pull recess | Dark wood veneer finish matching top rim and plinth | |
| Stitching | High-tensile polyester thread with 8 mm seam pitch | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Two vertically stacked drawers | Provide enclosed storage for bedside essentials with curved front panels | |
|---|---|---|
| Integrated recessed horizontal pull | Allows grip access to both drawers without protruding hardware | |
| Silent drawer operation | Metal side glides enable smooth, low-noise open/close movement | |
| Leveling adjustment | Bottom nylon glides rotate to adjust height and stabilize on uneven floors | |
| Scratch-resistant tabletop rim | Raised wood edge prevents small items from sliding off the surface | |
| Floor protection design | Nylon glide tips prevent scuffs and scratches on hard flooring materials | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential bedroom bedside placement | Fits adjacent to standard or upholstered beds for lamp, book, and personal item storage | |
|---|---|---|
| Living room side end table use | Placed next to sofas or armchairs to hold beverages, remotes, and decorative objects | |
| Luxury modern interior design schemes | Matches contemporary, minimalist, and upholstered bedroom or living room furniture sets | |
| Small-space studio or guest room use | Compact circular footprint saves space while providing enclosed hidden storage | |
| Hotel or serviced apartment guest room furnishing | Durable upholstered construction meets high-turnover residential furnishing needs |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Residential furniture strength, durability and safety requirements for storage units |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to case good structural integrity | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, recommended for MDF substrateAcceptance | |
| GB/T 16799-2008 | Performance requirements for polyurethane synthetic leather upholstery materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to case good structural integrity; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, recommended for MDF substrateAcceptance; 3. GB/T 16799-2008: Performance requirements for polyurethane synthetic leather upholstery materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
