Automatic mm / inch conversion · Core engineering specifications
| Overall assembled size | 560 x 420 x 560 mm | |
|---|---|---|
| Tabletop usable area | 520 x 380 mm | |
| Tabletop thickness | 25 mm | |
| Case body size | 540 x 400 x 410 mm | |
| Drawer exterior size per drawer | 490 x 360 x 170 mm | |
| Drawer interior size per drawer | 430 x 310 x 130 mm | |
| Drawer handle length | 180 mm | |
| Leg height | 150 mm | |
| Floor clearance beneath case | 135 mm | |
| Front leg splay offset | 35 mm | |
| Rear wall clearance | 80 mm | |
| Footprint at floor | 520 x 390 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net weight | 17.5 kg | |
|---|---|---|
| Total static load capacity | 41 kg | |
| Tabletop static load | 20 kg | |
| Load per drawer | 10 kg | |
| Drawer sliding durability | 30,000 open/close cycles | |
| Drawer extension travel | 310 mm | |
| Leg assembly static load | 120 kg vertical test load | |
| Tip restraint pull-off resistance | 300 N lateral force | |
| Color option count | 1 visible color option | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main case panels | Engineered-wood panels with a smooth gray painted or laminated face; substrate grade requires BOM verification. | |
|---|---|---|
| Tabletop | 25 mm smooth gray panel with a slight reflective sheen and molded edge; visible finish, unconfirmed lacquer chemistry. | |
| Drawer fronts | Engineered-wood composite panels finished to match the gray case; no fluting or padded upholstery is visible. | |
| Drawer box | 12 mm engineered-wood sides with hardboard or 9 mm composite bottom; construction inferred from category hardware. | |
| Drawer glides | Side-mounted steel roller or ball-bearing glides with black or zinc finish; exact mechanism not visible. | |
| Drawer handles | 180 mm black coated horizontal metal bar pulls, one centered on each drawer. | |
| Legs | Four black tapered splayed legs, visually consistent with coated metal or wood-composite construction. | |
| Foot caps | Small light-colored floor-protecting pads visible at the bottom of the front legs. | |
| Internal joinery | Threaded inserts, metal brackets, cam bolts, and confirmat-style screws recommended for leg and rail connections. | |
| Surface treatment | Uniform satin or semi-gloss gray coating; gloss level, scratch rating, and VOC data require supplier documentation. | |
| Edge construction | Banded or sealed panel edges with softly radiused top corners, visible from the cabinet outline. | |
| Back panel | Stable composite back panel set into the rear case groove; not visible and subject to factory drawing confirmation. |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Two independently opening horizontal drawers provide stacked bedside storage on side-mounted glides. | |
|---|---|---|
| Drawer extension | Each drawer travels 310 mm outward for access to the 430 x 310 x 130 mm interior compartment. | |
| Handle access | The 180 mm centered black bar gives two-hand or one-hand access from the standing bedside position. | |
| Storage division | The interior is divided into two equal single-width drawers rather than doors, shelves, or open cubbies. | |
| Tabletop use | The flat 520 x 380 mm top supports a clock, lamp, books, phone, or two small decorative objects. | |
| Under-case cleaning | The 135 mm floor clearance permits robotic vacuum access and routine floor cleaning beneath the cabinet. | |
| Leg attachment | Four angled legs attach under the case corners and provide a stable elevated footprint on level flooring. | |
| Floor protection | Visible non-marking end caps reduce scratching and compensate for minor hard-floor irregularity. | |
| Tip restraint provision | A wall anchor should be installed when used by children or on plush carpet; inclusion requires packing-list confirmation. | |
| Assembly method | Knock-down assembly is expected, with legs, handles, glides, and drawer components installed from supplied hardware. | |
| Bedside clearance | The 420 mm depth keeps the body close to the bed while retaining access around curtains and baseboards. | |
| Soft-close status | No soft-close mechanism is visible; procurement should specify it as an optional upgraded glide package. |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Bedroom bedside use | Place one unit beside a single or double bed for clock, lamp, books, and two-drawer personal storage. | |
|---|---|---|
| Hotel or serviced apartment | Suitable in pairs for compact guest rooms where a durable gray case and black hardware are required. | |
| Children's room with anchoring | Can store clothing and bedside items only when a wall tip-restraint anchor is correctly installed. | |
| Guest room accent storage | Works beside a bed or in a small guest suite where a closed front keeps clutter concealed. | |
| Small apartment living area | Can serve as a compact storage side table next to a sofa due to its elevated leg and flat top. | |
| Procurement configuration | Specify pairs for master bedrooms and verify gray finish, glide type, and wall-anchor inclusion before bulk order. | |
| Flooring compatibility | Hard-floor pads and the 135 mm clearance suit timber, tile, herringbone, and low-pile carpet installations. |
EU Market Access Requirements* EN Standards
| EN 14749 storage furniture safety | Applies to household nightstand strength, durability, glass, drawer, and safety requirements. | |
|---|---|---|
| EN 16122 non-domestic storage furniture | Useful benchmark if the same cabinet is purchased for hotel or serviced-apartment projects. | |
| EN 717-1 formaldehyde release | Recommended test method for engineered-wood board emission verification. | |
| EN 12720 surface resistance to cold liquids | Recommended for evaluating the gray finish against spills common at bedside. |
Standards applicable to China-market projects
| GB/T 3324 dimensions and structural integrity | Applies as the Chinese general technical standard for wooden furniture cabinets used in acceptance inspection. | |
|---|---|---|
| GB/T 3325 surface physical and chemical property tests | Recommended for coating abrasion, impact, stain, moisture resistance, and adhesion checks. | |
| GB/T 3326 dimensional inspection | Provides the measuring method for cabinet dimensions, clearance, and tolerances. | |
| GB 18580 formaldehyde emission | Recommended acceptance basis for engineered-wood panel emission limits in indoor furniture. | |
| GB/T 10357 furniture mechanical tests | Recommended for cabinet strength, drawer operation, stability, and static-load verification. |
This product must meet the following technical requirements: 1. GB/T 3324 dimensions and structural integrity: Applies as the Chinese general technical standard for wooden furniture cabinets used in acceptance inspection.; 2. GB/T 3325 surface physical and chemical property tests: Recommended for coating abrasion, impact, stain, moisture resistance, and adhesion checks.; 3. GB/T 3326 dimensional inspection: Provides the measuring method for cabinet dimensions, clearance, and tolerances.; 4. GB 18580 formaldehyde emission: Recommended acceptance basis for engineered-wood panel emission limits in indoor furniture.; 5. GB/T 10357 furniture mechanical tests: Recommended for cabinet strength, drawer operation, stability, and static-load verification.; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
