PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	500 × 400 × 550 mm
Glass top thickness	8 mm
Drawer internal dimensions	420 x 340 x 120 mm
Drawer front panel height	120 mm
Open base recess height	180 mm
Side panel thickness	25 mm
Beveled glass edge overhang	10 mm
Lower front panel height	250 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Tabletop static load capacity	15 kg
Product net weight	12 kg
Recommended number of users	1
Drawer slide cycle rating	30000 cycles
Glass surface impact resistance	50 mm steel ball drop at 200 mm
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Tabletop	8mm thick clear tempered glass with beveled edges
Frame and side panels	Dark matte finish E1 grade engineered wood with 25mm thickness
Drawer front	Reddish-brown wood veneer over engineered wood substrate
Lower front panel	Dark matte engineered wood matching frame finish
Drawer box	15mm thick E1 grade MDF with smooth interior finish
Drawer slides	Cold-rolled steel side-mounted full-extension slides
Bottom foot pads	Non-slip PE plastic pads to prevent floor scratching
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Drawer operation	Handleless push-to-open mechanism with 300mm full extension travel
Storage zoning	Upper full-width drawer for small personal items, open lower recess for temporary foot or item placement
Surface function	Flat tempered glass top supports placing table lamps, books, phones and beverage containers
Floor protection	Built-in non-slip foot pads prevent scratches on hard flooring and reduce movement noise
Assembly requirement	Knock-down assembly with pre-drilled components, all hardware included
Edge safety	Beveled and polished glass top edges eliminate sharp corners for residential use
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Secondary placement	Living room end table next to sofas or accent chairs for holding drinks and remote controls
Applicable users	Residential users seeking minimalist modern bedroom furniture with contrasting color design
Recommended complementary furniture	Pair with low-profile platform beds, dark finish wardrobes or matching dressers for coordinated bedroom sets
Surface use suitability	Tempered glass top is water and stain resistant, suitable for placing humidifiers, skincare items and drinkware

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 14749:2016	Safety and strength requirements for domestic storage furniture including nightstands
EN 12150-1:2015	Thermally toughened soda lime silicate safety glass for furniture use

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to wood frame quality inspection
GB 15763.2-2005	Safety requirements for tempered glass used in furniture table tops
GB 18584-2001	Limit of formaldehyde emission for indoor wooden furniture, applicable to panel material acceptance

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame quality inspection;
2. GB 15763.2-2005: Safety requirements for tempered glass used in furniture table tops;
3. GB 18584-2001: Limit of formaldehyde emission for indoor wooden furniture, applicable to panel material acceptance;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · NS-GL1-DK48

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · NS-GL1-DK48

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · NS-GL1-DK48Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Modern Single-Drawer Nightstand with Beveled Glass Top, model NS-GL1-DK48, delivers a streamlined minimalist silhouette defined by clean lines and intentional material contrast. Its visual design pairs a dark matte engineered wood frame with a warm reddish-brown wood veneer drawer front, topped by a clear beveled tempered glass surface that extends slightly past the frame edges. The structure features an elevated open base recess, creating a light, uncluttered profile that avoids the heavy visual weight of fully enclosed case pieces, with consistent panel thickness across the frame for a balanced, polished look. Construction prioritizes durable, residential-grade materials: the 8mm thick tempered glass top features polished beveled edges to remove sharp corners, while the 25mm thick frame and side panels are made of E1 grade engineered wood with a smooth dark matte finish. The drawer is built from 15mm thick E1 grade MDF with a smooth interior, mounted on cold-rolled steel side-mounted full-extension slides, and fitted with a handleless push-to-open mechanism for seamless operation. Non-slip PE plastic foot pads are fitted to the base to protect hard flooring from scratches and reduce noise when the unit is shifted. All major joints use connectors with a minimum of two fixing points for structural stability, and the unit ships as knock-down components with pre-drilled holes and all included hardware for straightforward assembly. Functional design is tailored to daily use: the full-width upper drawer provides enclosed storage for small personal items, while the open lower recess offers flexible space for temporary item placement or foot room when positioned beside seating. The flat tempered glass top is water and stain resistant, supporting everyday items such as table lamps, books, mobile devices, beverage containers, humidifiers, and skincare products. The glass surface is engineered to withstand standard residential use impacts, and the drawer slides are rated for consistent long-term operation. This nightstand is ideal for residential bedrooms, particularly for users seeking modern minimalist furnishings with subtle contrasting color detail; it pairs seamlessly with low-profile platform beds, dark finish wardrobes, and matching dressers for coordinated room sets. It also functions effectively as a living room end table positioned next to sofas or accent chairs, to hold drinks and remote controls. When procuring, note that the unit ships across two cartons, requires roughly 40 minutes of assembly per set, and is offered in six recommended finish options to align with existing interior palettes; the single-user design is sized to fit compact bedside or seating side layouts without overwhelming surrounding space.

Modern Single-Drawer Nightstand with Beveled Glass Top Specifications
