Product supplierModern 2-Drawer Metal Frame Nightstand, Brushed 304 stainless steel tubular frame
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 500 × 420 × 480 mm | |
|---|---|---|
| Upper drawer front size | 460 x 180 mm | |
| Lower drawer front size | 460 x 200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 16 kg | |
|---|---|---|
| Top surface static load capacity | 30 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Recommended maximum user weight for edge sitting | 80 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Structural frame | Brushed 304 stainless steel tubular frame | |
|---|---|---|
| Drawer fronts | 18mm MDF substrate with matte beige polyurethane paint | |
| Top surface | 18mm MDF substrate with matte light gray polyurethane paint | |
| Lower open shelf | 18mm MDF substrate with brushed stainless steel veneer | |
| Drawer slides | Cold-rolled steel full-extension ball bearing slides | |
| Drawer internal liners | 0.5mm thick flocked anti-slip fabric lining | |
| Frame joint welds | TIG welded ground and polished corner joints | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper drawer storage | Full-extension pull-out drawer for small bedside essentials | |
|---|---|---|
| Lower drawer storage | Full-extension pull-out drawer for bulkier personal items | |
| Open lower shelf | Fixed open shelf for frequently accessed items or display | |
| Drawer soft-close function | Integrated soft-close damper for silent, slam-free drawer closure | |
| Leveling feet | Hidden adjustable leveling feet at base corners for uneven floor adjustment | |
| Surface scratch resistance | UV-cured top coat on painted panels for daily scratch and stain resistance | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential bedroom use | Placed beside beds as bedside storage for lamps, books and personal items | |
|---|---|---|
| Modern living room side table use | Positioned next to sofas as an end table for drinks and remote controls | |
| Boutique hotel guest room use | Installed in hotel rooms as a premium bedside unit for guest amenities | |
| Small apartment entry use | Placed in entryways as a compact console for keys and small accessories | |
| Matching modern bedroom set use | Paired with low-profile platform beds and dressers for coordinated interior design |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety requirements for domestic storage furniture, applicable to structural stability | |
|---|---|---|
| EN 1022:2019 | Stability test standard for domestic seating and storage furniture | |
| EN 12521:2015 | Durability requirements for domestic furniture hardware |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel components | |
|---|---|---|
| GB/T 3325-2017 | Test methods for metal furniture strength and durability, applicable to steel frame | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to panel finishing |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel components; 2. GB/T 3325-2017: Test methods for metal furniture strength and durability, applicable to steel frame; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to panel finishing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
