Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 600 x 400 x 550 mm | |
|---|---|---|
| Top panel thickness | 10 mm | |
| Individual drawer front height | 230 mm | |
| Drawer internal usable width | 470 mm | |
| Drawer internal usable depth | 340 mm | |
| Plinth base height | 40 mm | |
| Side panel thickness | 25 mm | |
| Corner radius | 40 mm | |
| Top panel overhang | 2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Product net weight | 25.3 kg | |
|---|---|---|
| Top surface static load capacity | 30 kg | |
| Drawer glide cycle rating | 50000 open/close cycles | |
| Top glass impact resistance | 50 mm steel ball drop from 1m | |
| Surface scratch resistance rating | 2H pencil hardness | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top surface | 10mm black tempered glass | |
|---|---|---|
| Cabinet body panels | 18mm E0-grade engineered wood with light grey vertical wood-grain laminate | |
| Drawer box construction | 12mm plywood with dovetail joinery | |
| Drawer glides | 35mm cold-rolled steel full-extension soft-close slides | |
| Plinth base | Powder-coated black steel support frame | |
| Drawer interiors | Matte dark grey melamine lining | |
| Edge banding | Matching PVC edge banding on all cut panels | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Two equal-height full-extension soft-close drawers, push-to-open flush fronts | |
|---|---|---|
| Soft-close mechanism travel | 35mm damping stroke, auto-closes drawers from 50mm from closed position | |
| Corner safety design | All front vertical edges rounded to 40mm radius, no sharp exposed corners | |
| Top surface use | Smooth non-porous glass top, stain-resistant and easy to wipe clean | |
| Anti-tip feature | Wall anchor kit included to secure unit to wall for household safety | |
| Storage configuration | Two stacked equal-capacity closed storage compartments, no open shelves | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential bedroom bedside use | Ideal for placement next to queen or king size beds for small-item storage | |
|---|---|---|
| Living room side table application | Can be used as a compact end table next to sofas in modern living spaces | |
| Modern interior styles | Suitable for minimalist, contemporary, Italian-modern or luxury interior schemes | |
| Small space storage solution | Compact footprint suits studio apartments, small bedrooms or hotel guest rooms | |
| Pair configuration | Designed for paired placement on both sides of a bed for symmetrical layout |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic storage furniture including nightstands | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety requirements for residential bedroom furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and dimensional acceptance | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for body panel material performance | |
| GB 15763.2-2017 | Safety standards for tempered glass used in furniture tops | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E0-grade material verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and dimensional acceptance; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for body panel material performance; 3. GB 15763.2-2017: Safety standards for tempered glass used in furniture tops; 4. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E0-grade material verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
