Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 660 x 470 x 719 mm | |
|---|---|---|
| top surface perimeter lip height | 20 mm | |
| drawer internal usable dimensions | 280 x 400 x 120 mm | |
| open storage cubby internal usable dimensions | 320 x 400 x 120 mm | |
| central pedestal column cross section | 80 x 40 mm | |
| four-prong cross base overall footprint | 560 x 560 mm | |
| base cross foot width | 50 mm | |
| base foot thickness | 15 mm | |
| drawer face integrated pull cutout width | 160 mm | |
| storage compartment opening height | 120 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| top surface static load capacity | 34 kg | |
|---|---|---|
| unit net weight | 16 kg | |
| base tip-over resistance load | 15 kg lateral | |
| surface scratch resistance | 2000 abrasion cycles | |
| standard warranty length | 1 year | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| tray top panel | 1.5 mm thick steel with matte dark bronze powder coat | |
|---|---|---|
| drawer box construction | 1.2 mm thick steel with matching powder-coated finish | |
| open cubby frame | 1.2 mm thick steel with matching matte dark bronze finish | |
| central pedestal column | 2 mm thick rectangular steel tubing | |
| four-prong cross base feet | 3 mm thick flat steel bar | |
| drawer slide hardware | Side-mounted 3/4 extension ball-bearing steel glides | |
| surface finish | Textured matte dark bronze powder coating | |
| floor contact pads | 3 mm thick non-slip felt pads | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| lipped tray top retention | 20 mm raised perimeter lip prevents small items from sliding off surface | |
|---|---|---|
| enclosed drawer storage | 1 fully extending drawer provides concealed storage for personal items | |
| open cubby access | Side-mounted open compartment allows quick access to frequently used items | |
| drawer operation | Side-mounted ball-bearing glides allow smooth pull-out access to 300 mm depth | |
| floor protection | Felt pads on each cross base foot prevent scratches on hard flooring | |
| stable support | Four-prong cross base distributes weight evenly to prevent wobble | |
| monolithic construction | Welded frame minimizes loose fasteners for long-term structural rigidity | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| packaged carton count | 1 unit per carton | |
|---|---|---|
| packaged carton dimensions | 720 x 530 x 180 mm | |
| packaged gross weight | 19 kg | |
| packaged cubic volume | 0.07 CBM | |
| 20ft GP container loading quantity | 360 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| residential bedroom bedside placement | Compact footprint fits adjacent to standard and king-size bed frames for bedside access | |
|---|---|---|
| living room sofa side end table use | Stable cross base supports placement next to seating for drinks and remote controls | |
| modern minimalist interior settings | Monolithic dark bronze geometric form aligns with contemporary and industrial decor schemes | |
| small space studio apartment use | Dual storage (drawer + open cubby) maximizes utility in compact floor plans | |
| hotel guest room bedside furnishing | Durable powder-coated finish withstands high-frequency commercial hospitality use |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic storage furniture | |
|---|---|---|
| EN 14749:2016 | Requirements and test methods for domestic and kitchen storage units and worktops |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB/T 4893.8-2013 | Surface abrasion resistance test method for furniture finishes, applicable for finish durability validation | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable for static load and stability validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB/T 4893.8-2013: Surface abrasion resistance test method for furniture finishes, applicable for finish durability validation; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable for static load and stability validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
