Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 600 x 430 x 560 mm | |
|---|---|---|
| Raised tray top lip height | 40 mm | |
| Single drawer front height | 210 mm | |
| Under-base floor clearance height | 120 mm | |
| Tray top interior usable width | 540 mm | |
| Tray top interior usable depth | 370 mm | |
| Drawer internal usable depth | 380 mm | |
| Drawer internal usable width | 480 mm | |
| Outer panel upholstery thickness | 20 mm | |
| Corner radius on curved front edges | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 20 kg | |
|---|---|---|
| Product net weight | 25 kg | |
| Drawer slide operation cycle rating | 50000 cycles | |
| Surface abrasion resistance (Martindale) | 50000 cycles | |
| Recommended maximum user weight applied to top edge | 50 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal structural frame | 18 mm thick E1-grade engineered wood (MDF) | |
|---|---|---|
| Exterior upholstery | 1.2 mm thick matte beige faux leather with contrast light stitching | |
| Panel padding under upholstery | 20 mm thick 30 kg/m³ density high-resilience polyurethane foam | |
| Raised tray interior finish | Walnut wood veneer with matte clear lacquer | |
| Drawer slide hardware | Cold-rolled steel full-extension side-mount ball-bearing slides | |
| Cantilever base inner support | 1.5 mm thick powder-coated steel reinforcement bracket | |
| Drawer box construction | 12 mm thick engineered wood with smooth matte interior finish | |
| Stitching specification | 8 mm stitch pitch with matching light-toned bonded thread | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Upper raised tray storage | Lipped open top to contain small items and prevent rolling off | |
|---|---|---|
| Two handleless drawer storage | Push-to-open operation for fully flush front panels without external handles | |
| Open under-base recess | 120 mm high clearance to accommodate robot vacuum access under the unit | |
| Soft rounded corner protection | Curved front/side edges eliminate sharp corners for bedroom safety | |
| Flush seamless front design | Drawer fronts align perfectly with upholstered side panels for gap-free appearance | |
| Soft-close drawer damping | Built-in hydraulic dampers prevent slamming during drawer closure | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Master bedroom bedside placement | Positioned adjacent to standard 600 mm height bed frames for easy access | |
|---|---|---|
| Hotel guest room bedside furnishing | Durable upholstered finish suited for high-turnover hospitality environments | |
| Small apartment compact storage | Narrow footprint fits tight spaces beside platform beds or in studio apartments | |
| Open-shelf modern interior schemes | Soft curved minimalist design complements contemporary, wabi-sabi, or luxury decor | |
| Robot-vacuum compatible bedroom layouts | Open under-base clearance allows standard robot vacuums to pass underneath | |
| Secondary living room side table use | Functions as an end table beside sofas for holding drinks, remotes, and reading materials |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units worktops safety requirements, applicable to nightstand use | |
|---|---|---|
| EN 13356:2010 | Upholstered furniture furniture leather performance requirements | |
| EN 12521:2015 | Domestic furniture strength durability safety for seating and storage units |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame performance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 16799-2008 | Performance requirements for polyurethane synthetic leather used for upholstery | |
| GB/T 10357.5-2011 | Furniture mechanical performance test for storage units strength and durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame performance; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 3. GB/T 16799-2008: Performance requirements for polyurethane synthetic leather used for upholstery; 4. GB/T 10357.5-2011: Furniture mechanical performance test for storage units strength and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
