Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 500 x 500 x 550 mm | |
|---|---|---|
| Plinth base height | 40 mm | |
| Recessed top tray depth | 25 mm | |
| Raised top lip width | 20 mm | |
| Drawer front height | 220 mm | |
| Vertical slot pull length | 120 mm | |
| Corner radius | 60 mm | |
| Drawer internal usable depth | 380 mm | |
| Floor clearance under plinth | 10 mm | |
| Tray insert usable area | 460 x 460 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Top tray static load capacity | 20 kg | |
|---|---|---|
| Unit net weight | 25 kg | |
| Recommended maximum user weight for top seating | 80 kg | |
| Drawer runner cycle rating | 50000 open/close cycles | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal structural frame | 18 mm thick MDF board | |
|---|---|---|
| Exterior upholstery | 1.2 mm thick taupe top-grain leather | |
| Top perimeter lip | Walnut veneer with matte clear lacquer | |
| Tray insert surface | Light tone matte leather matching upholstery | |
| Drawer box construction | 12 mm thick solid birch plywood | |
| Plinth base | Dark brown powder-coated steel | |
| Drawer runners | Full-extension soft-close ball-bearing slides | |
| Padding under upholstery | 10 mm thick 30 kg/m³ high-density foam | |
| Vertical pull slot liner | Matching walnut veneer | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Side-access recessed vertical slot pull, full extension soft-close | |
|---|---|---|
| Top tray storage | Raised perimeter lip contains small items to prevent sliding | |
| Leveling adjustment | Integrated micro-adjustment feet on plinth base | |
| Safety design | Fully rounded vertical corners eliminate sharp impact points | |
| Drawer damping | Built-in hydraulic soft-close mechanism prevents slamming | |
| Surface protection | Leather upholstery resists minor scratches from daily contact | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary placement | Bedside in residential master or guest bedrooms | |
|---|---|---|
| Storage function | Holds small personal items, reading glasses, and bedside lamps | |
| Style matching | Pairs with upholstered platform beds, modern luxury, and minimalist bedroom interiors | |
| Space requirement | Requires 550 mm clear floor space for placement | |
| Secondary use | Functions as a small side end table beside lounge seating in boutique hotel rooms | |
| Recommended pairing | Positioned in pairs flanking king or queen size beds for symmetrical bedroom design |
EU Market Access Requirements* EN Standards
| Furniture safety standard | EN 12521:2015 residential furniture strength/durability | |
|---|---|---|
| Upholstered furniture emission | EN 16516:2017 volatile organic compound emission |
Standards applicable to China-market projects
| Formaldehyde emission limit | GB/T 39600E1 grade | |
|---|---|---|
| Furniture mechanical safety | GB/T 10357.1table static load test | |
| Leather furniture specification | GB/T 16799furniture leather performance requirements |
This product must meet the following technical requirements: 1. Formaldehyde emission limit: GB/T 39600E1 grade; 2. Furniture mechanical safety: GB/T 10357.1table static load test; 3. Leather furniture specification: GB/T 16799furniture leather performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
