Automatic mm / inch conversion · Core engineering specifications
| Overall cabinet size | 500 x 400 x 520 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net weight | 18 kg | |
|---|---|---|
| Top static load capacity | 30 kg | |
| Drawer count | 2 drawers | |
| Drawer operating cycles | 20,000 cycles | |
| Leg floor load points | 4 points | |
| Recommended users per unit | 1 sleeper | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Case body | Engineered-wood panels with an ivory matte painted surface | |
|---|---|---|
| Drawer fronts | Matte ivory painted panel fronts with flush inset alignment | |
| Top panel | Painted engineered-wood top with a formed edge frame | |
| Side panels | Smooth painted engineered-wood panels with square vertical edges | |
| Handles | Dark powder-coated metal bar pulls with straight mounting posts | |
| Legs | Dark matte metal splayed legs with tapered profile | |
| Drawer slides | Side-mounted metal ball-bearing drawer slides | |
| Internal drawer bottom | 3 mm hardboard or 5 mm engineered-wood drawer base | |
| Body panel thickness | 18 mm nominal board thickness | |
| Foot contact pads | Injection-molded polymer glide pads at each leg end | |
| Joinery hardware | Cam-lock bolts, confirmat screws, and metal corner brackets | |
| Surface finish | Low-sheen polyurethane or powder-coated paint system |
Adjustment / rotation / tilt / mobility / storage features
| Upper drawer storage | Horizontal pull-out drawer providing a 430 x 340 x 150 mm interior envelope for personal items | |
|---|---|---|
| Lower drawer storage | Horizontal pull-out drawer providing a 430 x 340 x 150 mm interior envelope for folded textiles | |
| Drawer extension | Side-mounted ball-bearing slides with 350 mm travel for full access to the drawer interior | |
| Handle operation | Two fixed horizontal bar pulls, one centered on each drawer, allowing two-finger pull operation | |
| Freestanding support | Four splayed metal legs stabilize the cabinet without wall attachment | |
| Floor cleaning access | 105 mm under-case clearance permits a robotic vacuum or broom to pass below the lower rail | |
| Leveling adjustment | Polymer foot pads with a 3 mm thread adjustment compensate for minor floor unevenness | |
| Bedside device placement | The flat top supports a lamp, phone, clock, or small charging tray within a 30 kg top load | |
| Soft-close behavior | Drawers are specified with optional self-closing action requiring slide selection before order | |
| Locking function | No lock is present on either visible drawer front | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Carton count | 1 flat-pack carton | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Bedroom bedside use | Place beside a single, double, queen, or king bed to hold a lamp, phone, book, and nighttime accessories | |
|---|---|---|
| Hotel guest room | Use as a matching pair around a double bed for compact personal storage and a clean room appearance | |
| Serviced apartment | Install in short-stay apartments where guests need concealed storage without a large dresser | |
| Youth bedroom | Use beside a student or youth bed for stationery, chargers, clothing, and personal items | |
| Small bedroom or studio | Select where floor space is limited because the 500 x 400 mm footprint is narrower than a chest of drawers | |
| Matching bedroom set | Pair with an ivory bed, dresser, or wardrobe sharing matte panels and dark metal legs | |
| Care facility bedroom | Suitable where a simple easy-to-clean top and elevated floor clearance support routine housekeeping |
EU Market Access Requirements* EN Standards
| Household furniture safety | EN 14749 addresses storage furniture safety, including stability and safe assembly | |
|---|---|---|
| Formaldehyde emission | EN 13986 provides wood-based panel performance requirements, including formaldehyde classes | |
| Surface performance | EN 12720 and EN 12721 cover resistance to cold liquids and wet-heat exposure | |
| Hardware corrosion guidance | EN 1670 applies to corrosion resistance of building hardware where metal legs or handles are coated |
Standards applicable to China-market projects
| Formaldehyde emission guidance | GB/T 39600 applies to artificial wood panels used in the painted carcass | |
|---|---|---|
| Wood furniture quality guidance | GB/T 3324 covers general wooden furniture dimensions, workmanship, and inspection | |
| Furniture hardware guidance | GB/T 3325 applies to metal furniture hardware such as handles and drawer slides |
This product must meet the following technical requirements: 1. Formaldehyde emission guidance: GB/T 39600 applies to artificial wood panels used in the painted carcass; 2. Wood furniture quality guidance: GB/T 3324 covers general wooden furniture dimensions, workmanship, and inspection; 3. Furniture hardware guidance: GB/T 3325 applies to metal furniture hardware such as handles and drawer slides; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
