| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall external dimensions | 2070 x 1350 x 1170 mm | |
|---|---|---|
| Recommended compatible mattress size | 1200 x 2000 mm | |
| Headboard total height | 1170 mm | |
| Sleeping platform surface height | 300 mm | |
| Under-bed drawer internal depth | 180 mm | |
| Under-bed storage drawer count | 3 | |
| Wooden support slat thickness | 20 mm | |
| Slat spacing between supports | 120 mm | |
| Center support rail count | 1 | |
| Drawer face width per unit | 620 mm | |
| Footboard height above floor | 300 mm | |
| Floor clearance under side rail | 20 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static bed load capacity | 227 kg | |
|---|---|---|
| Maximum per-drawer static load | 15 kg | |
| Recommended user age range | 2 to 12 years | |
| Net product weight | 46 kg | |
| Upholstery abrasion resistance | 30000 cycles | |
| Headboard padding foam density | 35 kg/m³ | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Inner bed frame structure | Solid pine wood frame | |
|---|---|---|
| Headboard upholstery surface | Soft-touch silicone leather | |
| Headboard internal padding | High-resilience polyurethane foam | |
| Mattress support slats | 20mm thick solid pine slats | |
| Storage drawer boxes | 12mm thick plywood drawer bodies | |
| Drawer handle hardware | Recessed black plastic pull handles | |
| Bed base foot pads | Non-slip black plastic foot glides | |
| Frame side rails | Upholstery-covered wood rails, 25mm thick padded wrap | |
| Drawer sliding tracks | Cold-rolled steel side-mount drawer glides | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Under-bed drawer operation | 3 independent side-pull drawers roll out on steel glides for under-bed storage | |
|---|---|---|
| Mattress support design | Wooden slat platform eliminates requirement for separate box spring | |
| Headboard safety design | Fully padded rounded edges with no exposed hard corners for child impact protection | |
| Drawer stop mechanism | Integrated glide stops prevent drawers from pulling fully out during use | |
| Low platform access | 300mm high sleeping surface allows children to climb on and off independently | |
| Mattress retention feature | Raised inner side rail lip prevents mattress from shifting off slat base | |
| Storage access configuration | Drawers accessible from side of bed without requiring mattress removal | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Children's bedroom use | Ideal for single children aged 12in residential home bedrooms | |
|---|---|---|
| Small space bedrooms | Built-in under-bed storage reduces need for separate dressers in compact rooms | |
| Paired configuration | Matches 2-drawer upholstered nightstands for coordinated bedside storage set | |
| Gender flexible design | Available in multiple soft color options including pink, white and cream | |
| Independent sleep training | Low platform height supports safe independent bed access for young children |
EU Market Access Requirements* EN Standards
| EN 747-1:2012+A1:2015 | Furniture, bunk beds and high beds for domestic use, applicable for structural stability requirements | |
|---|---|---|
| EN 12520:2015 | Furniture, strength, durability and safety requirements for domestic seating and beds |
Standards applicable to China-market projects
| GB 28007-2011 | General safety technical code for children's furniture, applicable for sharp edge and stability testing | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame strength and dimensional checks | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB 28007-2011: General safety technical code for children's furniture, applicable for sharp edge and stability testing; 2. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame strength and dimensional checks; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
