PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Distributed worktop static load	120 kg per seat
Central drawer load	15 kg per drawer
Central cabinet shelf load	25 kg per shelf
Recommended users	3 persons
Netted system weight	190 kg
Worktop surface impact acceptance	22 kg drop-ball test at 1020 mm
Divider stability lateral load	30 kg per panel bay
Drawer slide durability	50,000 open-close cycles
Seat-side daily load limit	45 kg concentrated desktop load
Top Static Load Reference	150 kg uniformly distributed

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	25 mm melamine-faced particleboard with sealed ABS or PVC edge banding
Lower privacy panels	Fabric-laminated board panels with dark gray woven face
Upper divider panels	Ribbed translucent acrylic or glass-reinforced screen panels with aluminum rails
Divider framework	Anodized aluminum alloy posts and horizontal rails, 1.2 mm section thickness
Central cabinet	Wood-grain melamine board carcass with two doors and two drawers
Support and modesty structure	Powder-coated steel frame with black modesty boards and floor-contact end panels

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Workstation separation	Fabric lower panels and translucent upper screens separate three users while preserving light transmission
Central storage	Two lockable shallow drawers sit above two hinged cabinet doors for shared or adjacent-seat storage
Cable management	Desk-level grommet and under-desk cable tray route power and data from equipment to floor outlets
Seated access	Concave curved front panels create two knee bays for swivel-task chairs at the foreground stations

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office cluster	Suitable for three-person departments that need individual visual privacy, shared storage and compact L-shaped circulation
Procurement configuration	Recommended for call centers, administration teams and renovation projects requiring repeatable modular bays

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1 Office worktables and desks safety	Applies to desk dimensions, stability, strength and safe use in office environments
EN 527-2 Office worktables mechanical safety	Applies to static load, durability and impact testing of office work surfaces
EN 13986 Wood-based panels for construction	Use only when building-grade panel documentation is supplied; office panel standard should remain primary

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5 Desk and tablet products	Applies to desktop load, safety, cycle and stability verification for commercial desks
ANSI/BIFMA X5.9 Storage cabinets and pedestals	Applies to drawer, door, lock and cabinet structural performance
ANSI/BIFMA e3 Furniture sustainability	Applicable standards and test results require confirmation

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017 General technical requirements	Applies to wooden furniture dimensions, workmanship, edge sealing, stability and surface quality
GB/T 3325-2017 Metal furniture requirements	Applies to steel supports, coating quality, structural strength and hardware durability
GB 18584-2001 Indoor decorative materials wooden furniture limit	Applies to formaldehyde emission from wood-based panels and finished wooden furniture
GB/T 10357 furniture mechanical tests	Applies to desk strength, drawer durability, stability and load tests

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017 General technical requirements: Applies to wooden furniture dimensions, workmanship, edge sealing, stability and surface quality;
2. GB/T 3325-2017 Metal furniture requirements: Applies to steel supports, coating quality, structural strength and hardware durability;
3. GB 18584-2001 Indoor decorative materials wooden furniture limit: Applies to formaldehyde emission from wood-based panels and finished wooden furniture;
4. GB/T 10357 furniture mechanical tests: Applies to desk strength, drawer durability, stability and load tests;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-3P-L120-PANEL

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-3P-L120-PANEL

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-3P-L120-PANELOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Three-Person L-Shaped Panel Workstation with Central Storage combines three individual work positions in a compact, angular layout suited to coordinated team work. Its L-shaped plan forms an efficient cluster, with two foreground seating positions defined by concave curved front panels that create accessible knee bays for swivel task chairs. Fabric-covered lower privacy panels give each user visual separation, while ribbed translucent upper screens maintain a light, open feel. Anodized aluminum posts and horizontal rails frame the divider system, giving the workstation a structured commercial appearance with dark gray woven lower panels and a wood-grain central storage cabinet. The work surfaces use melamine-faced particleboard with sealed ABS or PVC edge banding, presented as durable panel tops with a finished top thickness of 50 mm. The support structure is powder-coated steel, paired with black modesty boards and floor-contact end panels that visually anchor the arrangement. Each main seat provides knee clearance of 680 mm in height and 900 mm in width. The metal support section is 80 mm with a 2 mm wall thickness. Rated static loading is 120 kg per seat, while the divider system accepts a lateral load of 30 kg per panel bay. The worktop surface is accepted under a 22 kg drop-ball impact test at 1020 mm. At the center of the layout, a shared storage unit integrates two lockable shallow drawers above two hinged cabinet doors. Each drawer is rated for 15 kg, and each cabinet shelf is rated for 25 kg, making the unit suitable for stationery, documents, and personal or team items. Cable management is built into the workstation through an 80 mm diameter desk-level grommet and an under-desk cable tray with 120 mm depth, helping route power and data cabling from equipment toward floor outlets. This model is appropriate for open-plan offices where three users require personal visual privacy without losing convenient shared access. It is particularly relevant for call centers, administration teams, and renovation projects using repeatable modular bays. It can also support residential work suites or study areas arranged for multiple users, provided the floor space and circulation requirements suit an L-shaped cluster. Procurement teams should plan for a three-person configuration with a netted system weight of 190 kg and allow time for assembly, referenced at 40 minutes per set. Packaging information should be confirmed at order stage because the supplied records vary between a two-carton reference and a four-carton gross-weight reference, the latter listing 180 kg per set and one cubic meter of packaging volume. Buyers should also verify finish choices for edge banding and upper screen material, confirm lock and key requirements, and coordinate delivery access, floor protection, and installation staffing around the substantial panel and steel components.

Three-Person L-Shaped Panel Workstation with Central Storage Specifications
