3-Person Linear L-Shaped Office Cubicle Workstation Cluster with Privacy Partitions and Mobile Storage Pedestals (model CWS-3L-1400-MP) is listed under L-Shaped Office Desk. Dimensions: 4200 × 2800 × 1200 mm. Materials: 25mm E1 grade MFC with melamine laminate, PVC edge banding. Load capacity: 300 kg. Product Features: modular,commercial,structure,two-tone,neutral,finish,slatted,privacy,dividers,mobile,wheeled,storage,seated,workstations. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | JUNPIN | Model | CWS-3L-1400-MP |
| Overall dimensions (W × D × H) | 4200 × 2800 × 1200 mm | Overall cluster dimensions | 4200 x 2800 x 1200 mm |
| Single L-station worktop dimensions | 1400 x 1200 x 750 mm | Desktop thickness | 25 mm |
| Partition panel total height | 1200 mm | Partition panel thickness | 32 mm |
| Opaque lower partition height | 700 mm | Translucent slatted upper partition height | 500 mm |
| Under-desk knee clearance height | 620 mm | Knee clearance minimum width per station | 600 mm |
| Worktop depth (main work surface) | 600 mm | Mobile storage pedestal dimensions | 400 x 500 x 600 mm |
| Cable grommet diameter per station | 60 mm | Support panel thickness | 18 mm |
| Caster wheel diameter on pedestals | 50 mm | Primary Component Thickness | 40 mm according to load-bearing role |
| Hardware / Moving-part Clearance | 5 mm operating clearance | Per-station desktop static load capacity | 300 kg |
| Mobile pedestal drawer static load per drawer | 30 kg | Recommended user count per cluster | 3 |
| Partition sound transmission class (STC) reference | 22 dB | Surface scratch resistance rating | Class 2 |
| Net weight per complete 3-station cluster | 280 kg | Design service life | 10 years |
| Desktop heat resistance (short-term) | 120 °C | Reference Static Load | 150 kg depending on category |
| Moving-part Durability Reference | Acceptance target 50000 cycles | Worktop panels | 25mm E1 grade MFC with melamine laminate, PVC edge banding |
| Partition lower panels | 18mm charcoal MFC with matte melamine finish | Partition upper sections | Translucent frosted acrylic horizontal slats with aluminum trim |
| Partition support frames | Anodized aluminum alloy profile connectors, 1.2mm wall thickness | Desk support panels/legs | 18mm matching MFC panels with powder-coated steel internal brackets |
| Mobile pedestal cabinets | 18mm beige MFC carcass, lockable drawer and door, PVC edging | Pedestal casters | 50mm nylon swivel casters, 2 lockable brakes per unit |
| Drawer slides | Ball-bearing full-extension steel slides, 350mm travel length | Cabinet door hinges | Soft-close concealed steel hinges, 110° opening angle |
| Cable grommets | ABS plastic round grommets with brush seal, located per station | Surface finish performance | Stain-resistant, water-resistant, easy-to-clean melamine coating |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | Privacy divider configuration | 1200mm half-height partitions separate each station, reducing visual distraction |
| Cable management system | Grommet access per worktop, hidden internal routing channels along partition frames | Mobile pedestal mobility | Swivel casters allow pedestals to be repositioned under desks or beside stations |
| Storage security | Pedestal drawers include integrated key locks to secure personal documents and belongings | Modular reconfiguration capability | Aluminum frame connectors allow layout adjustment or additional stations to be added |
| Work surface orientation | Each L-station provides dual work zones for computer work and document writing | Pedestal storage layout | Each mobile unit includes one lockable drawer, one open shelf, and one enclosed cabinet for storage |
| Assembly structure | Knock-down flat-pack construction with cam-lock connectors for on-site assembly | Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Packaging Volume | 0.8 m³/set | Reference Packaged Gross Weight | 120 kg/set |
| Open-plan corporate offices | Provides individual semi-private workstations in collaborative open office layouts | Small to medium business work areas | Supports 3 staff in a compact linear footprint for startup or branch offices |
| Call center and admin departments | Balances personal workspace definition with easy team accessibility | Modular office fit-out projects | Compatible with standard commercial cubicle layout planning and expansion |
| Workstation clusters with built-in storage | Eliminates need for separate under-desk filing units for personal storage | Long-term commercial office installation | Durable panel construction suitable for high-traffic daily office use |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 4200 × 2800 × 1200 mm | |
|---|---|---|
| Overall cluster dimensions | 4200 x 2800 x 1200 mm | |
| Single L-station worktop dimensions | 1400 x 1200 x 750 mm | |
| Desktop thickness | 25 mm | |
| Partition panel total height | 1200 mm | |
| Partition panel thickness | 32 mm | |
| Opaque lower partition height | 700 mm | |
| Translucent slatted upper partition height | 500 mm | |
| Under-desk knee clearance height | 620 mm | |
| Knee clearance minimum width per station | 600 mm | |
| Worktop depth (main work surface) | 600 mm | |
| Mobile storage pedestal dimensions | 400 x 500 x 600 mm | |
| Cable grommet diameter per station | 60 mm | |
| Support panel thickness | 18 mm | |
| Caster wheel diameter on pedestals | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-station desktop static load capacity | 300 kg | |
|---|---|---|
| Mobile pedestal drawer static load per drawer | 30 kg | |
| Recommended user count per cluster | 3 | |
| Partition sound transmission class (STC) reference | 22 dB | |
| Surface scratch resistance rating | Class 2 | |
| Net weight per complete 3-station cluster | 280 kg | |
| Design service life | 10 years | |
| Desktop heat resistance (short-term) | 120 °C | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop panels | 25mm E1 grade MFC with melamine laminate, PVC edge banding | |
|---|---|---|
| Partition lower panels | 18mm charcoal MFC with matte melamine finish | |
| Partition upper sections | Translucent frosted acrylic horizontal slats with aluminum trim | |
| Partition support frames | Anodized aluminum alloy profile connectors, 1.2mm wall thickness | |
| Desk support panels/legs | 18mm matching MFC panels with powder-coated steel internal brackets | |
| Mobile pedestal cabinets | 18mm beige MFC carcass, lockable drawer and door, PVC edging | |
| Pedestal casters | 50mm nylon swivel casters, 2 lockable brakes per unit | |
| Drawer slides | Ball-bearing full-extension steel slides, 350mm travel length | |
| Cabinet door hinges | Soft-close concealed steel hinges, 110° opening angle | |
| Cable grommets | ABS plastic round grommets with brush seal, located per station | |
| Surface finish performance | Stain-resistant, water-resistant, easy-to-clean melamine coating | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Privacy divider configuration | 1200mm half-height partitions separate each station, reducing visual distraction | |
|---|---|---|
| Cable management system | Grommet access per worktop, hidden internal routing channels along partition frames | |
| Mobile pedestal mobility | Swivel casters allow pedestals to be repositioned under desks or beside stations | |
| Storage security | Pedestal drawers include integrated key locks to secure personal documents and belongings | |
| Modular reconfiguration capability | Aluminum frame connectors allow layout adjustment or additional stations to be added | |
| Work surface orientation | Each L-station provides dual work zones for computer work and document writing | |
| Pedestal storage layout | Each mobile unit includes one lockable drawer, one open shelf, and one enclosed cabinet for storage | |
| Assembly structure | Knock-down flat-pack construction with cam-lock connectors for on-site assembly | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan corporate offices | Provides individual semi-private workstations in collaborative open office layouts | |
|---|---|---|
| Small to medium business work areas | Supports 3 staff in a compact linear footprint for startup or branch offices | |
| Call center and admin departments | Balances personal workspace definition with easy team accessibility | |
| Modular office fit-out projects | Compatible with standard commercial cubicle layout planning and expansion | |
| Workstation clusters with built-in storage | Eliminates need for separate under-desk filing units for personal storage | |
| Long-term commercial office installation | Durable panel construction suitable for high-traffic daily office use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables, safety and strength requirements for commercial use | |
|---|---|---|
| EN 527-2:2016 | Office worktables, dimensional and mechanical strength requirements | |
| EN 13986:2004+A1:2015 | Wood-based panels for construction and furniture, E1 formaldehyde class | |
| EN 14073-2:2004 | Office storage furniture, safety and strength requirements for pedestals |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel office desk systems | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks and workstations | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade ≤0.124mg/m³ requirement | |
| GB/T 4893.4-2013 | Surface wear resistance test for furniture coatings and laminates | |
| GB/T 4893.7-2013 | Surface heat resistance test for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel office desk systems; 2. GB/T 3327-2016: Performance requirements for office desks and workstations; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade ≤0.124mg/m³ requirement; 4. GB/T 4893.4-2013: Surface wear resistance test for furniture coatings and laminates; 5. GB/T 4893.7-2013: Surface heat resistance test for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
