Two-Person 120-Degree L-Shaped Panel Workstation with Divider Screens and Central Storage (model WS-L2-2800-WAL) is listed under L-Shaped Office Desk. Dimensions: 2800 × 2400 × 1100 mm. Materials: 25 mm particleboard core with walnut-look thermofused melamine and 2 mm PVC edge banding. Load capacity: 80 kg per workstation top. Product Features: panel,workstation,two-person,layout,L-shaped,desk,privacy,divider,mobile,storage,pedestal,cable,grommets. This page consolidates 5 groups of specifications and GB / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | GENUOWA | Model | WS-L2-2800-WAL |
| Finished Top Thickness | 50 mm | Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
| Recommended occupancy | 2 users | Uniform desktop static load | 80 kg per workstation top |
| Central pedestal drawer load | 15 kg per drawer | Concentrated worktop load | 50 kg on a 200 x 200 mm area |
| Drawer rated load | 15 kg per drawer | Drawer slide durability | 50000 open-close cycles |
| Door hinge durability | 100000 open-close cycles | Cable tray distributed load | 10 kg per user |
| Worktop horizontal stability load | 40 kg lateral force | Leveling adjustment range | 15 mm per foot |
| Worktop substrate and finish | 25 mm particleboard core with walnut-look thermofused melamine and 2 mm PVC edge banding | Side support panels | 25 mm moisture-resistant particleboard panels with charcoal melamine face and matching PVC edge |
| Modesty panels | 18 mm charcoal melamine-faced particleboard with finished vertical edges | Central pedestal carcass | 18 mm gray melamine-faced particleboard joined with knockdown cam-and-dowel fittings |
| Drawer fronts | 18 mm walnut-grain melamine particleboard with recessed pull detail and 1 mm PVC edges | Storage door panels | 18 mm gray fabric-look laminate or melamine particleboard in slab construction |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
| Reference Packaging Volume | 1 m³/set | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended occupancy | 2 users | |
|---|---|---|
| Uniform desktop static load | 80 kg per workstation top | |
| Central pedestal drawer load | 15 kg per drawer | |
| Concentrated worktop load | 50 kg on a 200 x 200 mm area | |
| Drawer rated load | 15 kg per drawer | |
| Drawer slide durability | 50000 open-close cycles | |
| Door hinge durability | 100000 open-close cycles | |
| Cable tray distributed load | 10 kg per user | |
| Worktop horizontal stability load | 40 kg lateral force | |
| Leveling adjustment range | 15 mm per foot |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop substrate and finish | 25 mm particleboard core with walnut-look thermofused melamine and 2 mm PVC edge banding | |
|---|---|---|
| Side support panels | 25 mm moisture-resistant particleboard panels with charcoal melamine face and matching PVC edge | |
| Modesty panels | 18 mm charcoal melamine-faced particleboard with finished vertical edges | |
| Central pedestal carcass | 18 mm gray melamine-faced particleboard joined with knockdown cam-and-dowel fittings | |
| Drawer fronts | 18 mm walnut-grain melamine particleboard with recessed pull detail and 1 mm PVC edges | |
| Storage door panels | 18 mm gray fabric-look laminate or melamine particleboard in slab construction |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
|---|---|---|
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | recommended for panel dimensions, workmanship, and stability acceptance. | |
|---|---|---|
| GB/T 3325-2017 Metallic furniture general technical conditions | recommended for metal frames, hardware, and finish inspection. | |
| GB/T 10357.5-2011 Furniture mechanical surface test | recommended for worktop and storage panel strength acceptance. | |
| GB 18580-2017 Formaldehyde emission for interior decoration materials | recommended procurement limit for wood-based panels. | |
| GB/T 3326-2016 Furniture main dimensions | recommended to verify desk height and seated clearance. |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: recommended for panel dimensions, workmanship, and stability acceptance.; 2. GB/T 3325-2017 Metallic furniture general technical conditions: recommended for metal frames, hardware, and finish inspection.; 3. GB/T 10357.5-2011 Furniture mechanical surface test: recommended for worktop and storage panel strength acceptance.; 4. GB 18580-2017 Formaldehyde emission for interior decoration materials: recommended procurement limit for wood-based panels.; 5. GB/T 3326-2016 Furniture main dimensions: recommended to verify desk height and seated clearance.; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
