PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended occupancy	2 users
Worktop distributed load	80 kg per work surface
Open shelf load	15 kg per shelf
Lower cabinet storage load	25 kg
Product net weight	145 kg
Panel fastener pull-out resistance	80 kg per connection
Drawer slide endurance	No drawer slide fitted
Warranty target	5 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	25 mm melamine-faced wood-based panel with sealed edges
Vertical panels	25 mm gray melamine-faced wood-based panels
Central cabinet doors	Vertical woodgrain melamine panel doors
Divider screen frame	Silver aluminum extruded frame with horizontal slats and translucent infill strips
Cable management hardware	60 mm plastic grommets and one recessed cable/access port
Structural hardware	Cam locks, connecting screws, hinges, and floor-leveling glides

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Two-seat opposing layout	Each user receives a separate 1200 x 600 mm work surface and independent knee opening
Privacy division	A 350 mm-high slatted screen above each desk reduces visual distraction while retaining open sightlines
Central storage system	The shared spine combines open shelves, a lower woodgrain door, and a narrow CPU bay
Cable routing	Round 60 mm grommets and a rectangular desk port route laptop and monitor cables toward the central cabinet

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Largest carton dimensions	2450 x 620 x 120 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office	Suitable for two staff needing separate seated work surfaces with shared filing and visual division
Administrative or reception back office	Fits laptop-based paperwork, phone work, and central storage for documents or a CPU

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-2P-LSH-2800-1200

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-2P-LSH-2800-1200

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-2P-LSH-2800-1200Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Person L-Shaped Panel Workstation is an unbranded office workstation designed for two users in a compact opposing layout. Its model is WS-2P-LSH-2800. The composition uses an L-shaped plan with separate work surfaces, a central storage spine, and low divider screens that organize the seating area without fully enclosing either workspace. Each user receives an individual 1200 by 600 mm work surface and an independent knee opening, creating clear personal zones while keeping the overall footprint suited to shared work areas. Visually, the workstation combines gray melamine-faced wood-based panels with vertical woodgrain central cabinet doors. The divider screens feature silver extruded aluminum frames, horizontal slats, and translucent infill strips. The screens rise 350 mm above each desk, reducing visual distraction while preserving open sightlines across the workstation. This gives the installation a structured, modern office appearance that balances privacy with collaboration. The work surfaces are made from 25 mm melamine-faced wood-based panels with sealed edges, while the finished top thickness is 50 mm. Vertical panels use 25 mm gray melamine-faced wood-based panels. Construction relies on cam locks, connecting screws, hinges, metal hardware, and floor-leveling glides. The main support section measures 80 mm with a 2 mm metal wall, and each connection is rated for 80 kg of panel fastener pull-out resistance. The product net weight is 145 kg. Each work surface is rated for an 80 kg distributed load, open shelves support 15 kg per shelf, and the lower cabinet storage area supports 25 kg. No drawer slide is fitted. Practical functionality is centered on shared storage and cable management. The central spine includes open shelves, a lower woodgrain door, and a narrow CPU bay, giving two users convenient storage for documents and equipment while keeping the desk surfaces clear. Round 60 mm plastic grommets and a rectangular recessed cable or access port route laptop and monitor cables toward the central cabinet. The cable opening is 80 mm in diameter, with a cable tray depth of 120 mm. These features help reduce visible cabling and support tidy daily use. The workstation is well suited to open-plan offices where two staff need separate seated work surfaces, shared filing, and limited visual division. It is also appropriate for administrative areas or reception back offices handling laptop-based paperwork, phone work, and document storage. Buyers should plan for two-person occupancy, confirm access and floor conditions for the 145 kg unit, and allow time for assembly. Logistics reference a packaged gross weight of 180 kg per set, a packaging volume of 1 cubic meter per set, and an assembly time of 40 minutes per set. Packaging records vary between two and four cartons, so shipment details should be confirmed before delivery and installation.

Two-Person L-Shaped Panel Workstation with Central Storage and Divider Screens Specifications
