PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Number of users	4 persons
Distributed desktop load	100 kg per workstation
Pedestal load capacity	30 kg per drawer or shelf level
Net weight	260 kg
Floor loading	33 kg per square meter
Recommended chair seat width	550 mm
Panel connection durability	50 assembly cycles
Workstation warranty	5 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	25 mm wood-grain melamine-faced particleboard with sealed exposed edges
Edge banding	2 mm PVC edge banding on high-impact front and side edges
Divider panels	Grey fabric-laminated modular panels with composite core
Screen frame and rails	Silver aluminium extrusions with horizontal louver inserts
Modesty panels	25 mm black laminate or powder-coated panels beneath rear tops
Support structure	Powder-coated steel internal rails and panel-to-floor supports

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Workspace division	Four diagonal partitions meet at the center, creating four separate seated work bays
Privacy configuration	Low 350 mm screen above the desktop blocks peripheral vision while preserving room visibility
Cable management	Desktop grommets route monitor and power cables into the central partition and under-top raceway
Storage division	The central 600 x 600 mm block provides shared or user-assigned storage and anchors the four-way screens

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office	Suitable for four staff in a compact 2.8 x 2.8 m cluster where visual separation and shared floor space are required
Administration or processing area	Appropriate for data entry, customer service and shared back-office tasks because each seat has a 1400 x 600 mm surface and cable outlet

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-CROSS4-WOOD-GRY

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-CROSS4-WOOD-GRY

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-CROSS4-WOOD-GRYOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Four-Person Cross-Shaped Panel Workstation with Dividing Screens is an unbranded office workstation designed as a compact four-seat cluster. Model WS-CROSS4-WOOD-GRY uses a cross-shaped layout in which four diagonal partitions meet at the center, producing four separate seated work bays. Low divider screens rise 350 mm above the desktop, helping to block peripheral vision between users while retaining visibility into the surrounding room. The arrangement gives the installation a structured, open-plan appearance without fully enclosing each workspace. Each work surface features a 25 mm wood-grain melamine-faced particleboard top with sealed exposed edges and 2 mm PVC edge banding on the high-impact front and side edges. The finished top thickness is 50 mm. Grey fabric-laminated modular panels with a composite core form the dividers, while silver aluminium extrusions and horizontal louver inserts provide the screen frame and rails. Black 25 mm laminate or powder-coated modesty panels sit beneath the rear tops, and powder-coated steel internal rails with panel-to-floor supports form the structural frame. The main support section is 80 mm with a 2 mm metal wall. Practical functions are integrated into the layout. Desktop grommets, each with an 80 mm opening, route monitor and power cables into the central partition and under-top raceway, where the cable tray provides 120 mm of depth. The central 600 x 600 mm block anchors the four-way screens and can be used for shared or individually assigned pedestal storage. Each main seat offers effective knee clearance of 680 mm in height and 900 mm in width, with a recommended chair seat width of 550 mm. Individual work surfaces measure 1400 x 600 mm. The workstation supports a distributed desktop load of 100 kg per workstation and a pedestal load of 30 kg per drawer or shelf level. The panel connection is rated for 50 assembly cycles. This configuration is well suited to open-plan offices that need to accommodate four staff in a 2.8 x 2.8 m cluster while balancing visual separation with shared floor space. It is also appropriate for administration, data entry, customer service and back-office processing areas, where each user requires a defined surface, cable outlet and modest storage access. Procurement planning should account for a net product weight of 260 kg and floor loading of 33 kg per square meter. The stated reference packaging is one set in two cartons, with additional logistics data noting a packaged gross weight of 180 kg per set in four cartons and a packaging volume of 1 cubic meter per set; buyers should confirm final packing details before ordering. Reference assembly time is 40 minutes per set. The wood-grain work surfaces, grey fabric panels, aluminium rails and black modesty panels should be reviewed against the intended interior palette, and storage allocation should be planned before installation.
