Automatic mm / inch conversion · Core engineering specifications
| Overall assembled footprint | 4200 x 3600 x 720 mm | |
|---|---|---|
| Single sofa module seat width | 800 mm | |
| Seat depth from front edge to backrest | 700 mm | |
| Seat height from floor to top of seat cushion | 420 mm | |
| Backrest height above seat surface | 300 mm | |
| Corner connecting square seat module dimension | 800 x 800 mm | |
| Freestanding small ottoman dimension | 450 x 450 x 420 mm | |
| Side table top diameter (round model) | 600 mm | |
| Side table height from floor to tabletop | 500 mm | |
| Upholstery thickness on seat surface | 80 mm | |
| Internal frame square tubing wall thickness | 1.5 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total product set weight | 280 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Total seated occupant capacity | 10 | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 55% | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Product warranty for structural frame | 5 years | |
| Upholstery and foam warranty | 2 years | |
| Structural frame durability | 100000 cycle load test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest outer upholstery | Two-tone dark charcoal and warm orange commercial grade fabric/PU leather | |
|---|---|---|
| Seat core padding | High-resilience polyurethane foam | |
| Internal support frame | Kiln-dried solid hardwood and plywood frame | |
| Sofa base support structure | Hidden powder-coated metal square tube legs with integrated levelers | |
| Side table tabletops | Matte white painted MDF or tempered glass top | |
| Side table support structure | Matte white powder-coated steel pedestal base with three-prong floor rest | |
| Freestanding ottoman upholstery | Matching two-tone charcoal or orange commercial grade fabric/PU leather over foam padding | |
| Frame joint hardware | Zinc-plated steel corner brackets and heavy-duty staples | |
| Seat and backrest core padding | 100mm thick high-resilience polyurethane foam, wrapped in 20g Dacron batting for soft edge feel | |
| Suspension support system | 50mm wide elastic webbing spaced 80mm apart across seat frame, no-sag support for cushion base | |
| Sofa base support | Hidden powder-coated steel square tube legs, fitted with 10mm adjustable nylon glides | |
| Freestanding ottoman construction | Matching two-tone charcoal or orange commercial grade upholstery over 80mm thick high-resilience foam, internal plywood frame with hidden glides |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration capability | Individual sofa segments connect via integrated heavy-duty metal joining clips, allowing layout rearrangement for different space shapes | |
|---|---|---|
| Freestanding ottoman flexible use | 4 lightweight cube ottomans are fully movable, usable as extra guest seating, footrests, or temporary side surfaces | |
| Floor level adjustment | Integrated adjustable glides on each sofa module base, compensating for up to 10mm of floor unevenness to eliminate rocking | |
| Open central circulation zone | L-shaped configuration creates a 2000mm wide central gathering area, suitable for placing side tables and supporting face-to-face collaborative discussion | |
| Sightline-optimized low back design | 300mm high backrest provides lumbar support without blocking cross-room sightlines in open office spaces | |
| Stain-resistant surface maintenance | Commercial grade upholstery supports dry cleaning and spot wiping for routine spill removal in high-traffic public areas | |
| Modular segment replacement | Damaged individual seat or backrest segments can be replaced without disassembling the entire sofa set | |
| Freestanding ottoman multi-use | 4 lightweight cube ottomans are fully unconnected, usable as extra guest seating, footrests, or temporary side surfaces for drinks and devices | |
| Central circulation zone design | L-shaped configuration creates a 2000mm wide central gathering area, sized to accommodate face-to-face collaborative discussion and side table placement | |
| Segmented replacement capability | Damaged individual seat, backrest or ottoman units can be replaced without disassembling the full sofa set, reducing long-term maintenance cost | |
| Non-marking floor protection | Nylon glides on all unit bases prevent scuffing and scratching on hard flooring, and avoid snagging on low-pile commercial carpet | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total shipping carton count | 12 cartons | |
|---|---|---|
| Sofa module carton dimensions (per unit) | 850 x 750 x 450 mm | |
| Ottoman carton dimensions (per unit) | 500 x 500 x 470 mm | |
| Side table carton dimensions (per unit) | 650 x 650 x 120 mm | |
| Total shipment gross weight | 320 kg | |
| Total shipment volume (CBM) | 3.2 CBM | |
| Full set assembly time | 90 minutes | |
| 20ft GP container loading quantity | 8 sets | |
| 40ft HQ container loading quantity | 20 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Office open plan breakout zones | Suitable for informal employee collaboration, short breaks, and impromptu small meetings, with flexible ottomans for ad-hoc seating | |
|---|---|---|
| Corporate reception and waiting areas | Creates a welcoming, contemporary visitor waiting space adjacent to building entrances or elevator lobbies, with easy-to-clean upholstery for high visitor traffic | |
| Co-working space common lounges | Supports flexible rearrangements for events, casual working, or member gatherings, with movable ottomans to adjust seating capacity dynamically | |
| Campus library or learning common areas | Provides durable group study and rest seating for student and staff use, with high-wear upholstery rated for high daily foot traffic | |
| Recommended complementary furniture pairing | Pair with the included round and square white side tables, plus low-pile commercial carpet, to create a cohesive, uncluttered lounge zone | |
| Campus library and learning commons | Provides durable group study and rest seating for students and staff, with high-abrasion upholstery rated for high daily foot traffic; 420mm seat height is accessible for adult and young adult users | |
| Startup office casual collaboration spaces | Suits relaxed team discussions and informal client meetings, with a minimalist block aesthetic that matches modern open office interior design | |
| Recommended complementary configuration | Pair with the included square and round white side tables, placed on low-pile commercial carpet in the central zone, to create a cohesive uncluttered gathering space with easy access to surfaces for drinks and devices |
EU Market Access Requirements* EN Standards
| EN 16139:2013 Furniture - Strength, durability and safety - Non-domestic seating | Applicable to structural strength, durability, and safety testing for commercial office lounge seating | |
|---|---|---|
| EN 1022:2018 Furniture - Seating - Determination of stability | Applicable to sofa and ottoman stability testing to prevent tipping during normal use | |
| EN 13722:2004 Furniture - Strength and durability of furniture surfaces | Applicable to tabletop surface resistance to scratches, heat, and liquid spills |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable to wooden internal frame structural strength, dimensional tolerance, and finish quality requirements | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable to formaldehyde emission limits for plywood and wood-based frame components | |
| GB/T 16799-2008 Furniture using leather | Applicable if PU or genuine leather upholstery is used, covering abrasion, color fastness, and tear strength requirements | |
| GB/T 27904-2011 Furniture - Determination of stability for seating | Applicable to sofa and ottoman stability testing to prevent tipping during normal adult use |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable to wooden internal frame structural strength, dimensional tolerance, and finish quality requirements; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable to formaldehyde emission limits for plywood and wood-based frame components; 3. GB/T 16799-2008 Furniture using leather: Applicable if PU or genuine leather upholstery is used, covering abrasion, color fastness, and tear strength requirements; 4. GB/T 27904-2011 Furniture - Determination of stability for seating: Applicable to sofa and ottoman stability testing to prevent tipping during normal adult use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
