Automatic mm / inch conversion · Core engineering specifications
| Single armchair overall dimensions | 900 x 850 x 900 mm | |
|---|---|---|
| Side table overall dimensions | 600 x 600 x 550 mm | |
| Armchair seat height from floor | 450 mm | |
| Armchair seat usable width | 580 mm | |
| Armchair seat depth | 550 mm | |
| Armchair backrest height from seat | 480 mm | |
| Armrest top height from floor | 620 mm | |
| Side table tabletop thickness | 12 mm | |
| Solid wood arm support width | 80 mm | |
| Armchair leg footprint width (front) | 750 mm | |
| Seat cushion thickness | 120 mm | |
| Armrest padding thickness | 20 mm | |
| Backrest padding thickness | 80 mm | |
| Side table leg cross-section | 50 x 50 mm | |
| Knee clearance under side table | 480 mm | |
| Chair rear leg footprint depth | 720 mm |
Net weight / load capacity / users / durability
| Single armchair net weight | 45 kg | |
|---|---|---|
| Single armchair static seat load rating | 150 kg | |
| Side table static tabletop load rating | 30 kg | |
| Seat foam density | 40 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Foam rebound rate | 45% | |
| Recommended single chair user weight | 120 kg | |
| Seam stitching durability | 60000 abrasion cycles | |
| PU upholstery abrasion resistance | 50000 Martindale cycles | |
| Wood finish cold liquid resistance | 24 hours |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | 1.2mm thick cream polyurethane (PU) leather | |
|---|---|---|
| Seat core padding | 40kg/m³ high-density polyurethane foam | |
| Backrest padding | 30kg/m³ medium-density polyurethane foam | |
| Armrest support posts and legs | Solid stained red hardwood with clear lacquer finish | |
| Armrest top padding | 20mm thick PU-covered polyurethane foam | |
| Internal seat frame | 25mm thick engineered hardwood plywood frame | |
| Side table tabletop | 12mm thick clear tempered glass with polished edge | |
| Side table frame and legs | Solid stained red hardwood with lacquer finish, matching chair wood components | |
| Upholstery stitching | High-tenacity polyester thread with 8mm stitch pitch | |
| Foot glides | Hard plastic floor protection glides fitted to base of all wood legs | |
| Side table apron panel | 18mm thick solid hardwood panel with matching stained red finish | |
| Decorative arm inlay | 3mm thick black resin inlay along curved wood arm post |
Adjustment / rotation / tilt / mobility / storage features
| Fixed position seating | Fully fixed non-adjustable structure, no recline, swivel or height adjustment, designed for stable static guest seating | |
|---|---|---|
| Fully padded arm support | Padded armrest tops extend full length from seat front to backrest, providing arm support for seated users at a consistent height | |
| Matching modular side table placement | Compact square side table sized to fit flush between two armchairs, providing shared surface for guests on either seat | |
| Integrated back lumbar support | Curved lower backrest contour provides built-in lumbar support without additional cushions, for upright seated posture during short waits | |
| Floor protection design | Hard plastic glides on all leg bases prevent scuffing and scratching on hard office flooring without requiring additional pads | |
| Non-removable upholstery covers | Upholstery is permanently fitted to the frame, designed for spot cleaning rather than cover removal for laundering | |
| Stable four-leg base | Four wide-set solid wood legs per chair provide a low center of gravity to prevent tipping when users sit or stand | |
| Tempered glass safety design | 12mm tempered glass tabletop breaks into small granular fragments on impact to reduce laceration risk | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Total package count per 2-chair + 1-table set | 3 packages | |
|---|---|---|
| Single armchair carton dimensions | 950 x 900 x 650 mm | |
| Side table carton dimensions | 650 x 650 x 150 mm | |
| Total gross weight per full set | 125 kg | |
| Total set shipping volume (CBM) | 0.62 CBM | |
| On-site assembly time | 40 minutes | |
| 20ft GP container loading quantity | 36 sets | |
| 40ft HQ container loading quantity | 88 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for formal lobby and guest waiting areas in government and corporate offices, matching traditional executive office wood trim finishes | |
|---|---|---|
| Executive office visitor seating | Pairs of chairs placed with side table opposite an executive desk for short guest meetings and visitor seating | |
| VIP lounge and meeting waiting zones | Modular configuration allows multiple sets to be arranged in rows or clusters for larger waiting areas in conference centers and hospitality suites | |
| High-traffic public service waiting areas | Durable PU upholstery and solid wood frame withstand regular daily use in bank, hospital administration and public service waiting spaces | |
| Hotel business center seating | Conservative formal design fits hotel business center and meeting room pre-function areas, complementing classic interior decor | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office furniture structural strength recommendation | EN 16139:2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating | |
|---|---|---|
| Furniture surface finish recommendation | EN 12720:2009+A1:2013 Furniture - Assessment of surface resistance to cold liquids | |
| Upholstery fabric durability recommendation | EN 14465:2005 Textiles - Upholstery fabrics - Specification and test methods | |
| Glass furniture safety recommendation | EN 12150:2015 Glass in building - Thermally toughened soda lime silicate safety glass |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB 18584 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
|---|---|---|
| Furniture mechanical safety recommendation | GB/T 3324 Wooden furniture general technical requirements | |
| Glass safety recommendation | GB 15763.2 Safety glazing materials in building - Part 2: Tempered glass | |
| Upholstery harmful substance limit recommendation | GB 20400 Leather and fur - Limit of harmful matter |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB 18584 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; 2. Furniture mechanical safety recommendation: GB/T 3324 Wooden furniture general technical requirements; 3. Glass safety recommendation: GB 15763.2 Safety glazing materials in building - Part 2: Tempered glass; 4. Upholstery harmful substance limit recommendation: GB 20400 Leather and fur - Limit of harmful matter; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
