Automatic mm / inch conversion · Core engineering specifications
| Single sofa overall dimensions | 900 x 850 x 900 mm | |
|---|---|---|
| Central matching side table dimensions | 500 x 500 x 550 mm | |
| Side matching end table dimensions | 600 x 600 x 550 mm | |
| Seat height from floor | 420 mm | |
| Seat cushion usable depth | 650 mm | |
| Seat cushion width per single unit | 700 mm | |
| Armrest height from seat surface | 200 mm | |
| Backrest total height from seat | 480 mm | |
| Wood frame member profile | 60 x 40 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Single sofa unit net weight | 45 kg | |
|---|---|---|
| Single seat static load capacity | 150 kg | |
| Total set seating capacity | 8 persons | |
| Seat cushion foam indentation load deflection | 45 kg/m3 | |
| Back cushion foam density | 35 kg/m3 | |
| Fabric/upholstery abrasion resistance | 50000 double rubs | |
| Wood frame static load bearing capacity | 300 kg per unit | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Frame joint durability | 100000 load cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural frame | Kiln-dried solid hardwood with dark reddish-brown lacquer finish | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam with top comfort layer | |
| Back cushion core | Medium-density polyurethane foam wrapped in soft polyester fiber | |
| Upholstery surface | Beige matte PU leather or top-grain corrected leather | |
| Protective covers | White lace-trimmed woven fabric doilies | |
| Frame joinery | Mortise and tenon reinforced wood joints with metal corner brackets | |
| Base feet | Solid wood block feet with polished stained finish, floor-protecting felt pads | |
| Side table tabletops | Solid wood frame with central cutout lattice apron | |
| Seat support system | 80mm wide elastic webbing spaced 60mm apart, secured with metal staples to frame rails | |
| Side table legs | 50x50mm solid wood square legs with horizontal cross-bracing for structural stability | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed 8-person arrangement with 8 single-seat sofas and 4 matching side tables | |
|---|---|---|
| Protective cover function | Removable lace doilies cover high-wear contact points (armrests, headrest areas, seat corners) to reduce upholstery soiling and abrasion | |
| Structural stability design | Wide solid wood base frame with block feet distributes weight evenly, eliminates wobble on hard commercial flooring | |
| Seating posture support | Upright padded backrest and wide padded armrests support formal upright sitting posture suitable for meetings and guest reception | |
| Maintenance feature | Surface upholstery is wipe-clean, allowing quick removal of common spills in high-traffic public reception areas | |
| Base foot block height | 50 mm | |
| Floor protection function | 5mm thick felt pads on all base feet prevent scratch damage to polished tile, wood and epoxy commercial flooring when units are repositioned for layout adjustments | |
| Side table load support | Each side table supports a 50 kg static load on its tabletop, suitable for holding tea sets, documents and small decorative items without deflection | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages per full set | 12 packages | |
|---|---|---|
| Single sofa shipping carton dimensions | 950 x 900 x 950 mm | |
| Single side table shipping carton dimensions | 550 x 550 x 600 mm (small central table), 650 x 650 x 600 mm (larger side tables) | |
| Total set gross shipping weight | 420 kg | |
| Total shipping volume per set | 8.5 CBM | |
| On-site assembly time per full set | 120 minutes | |
| 40HQ container loading quantity | 10 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Government and corporate executive reception rooms | Formal New Chinese styling, symmetric layout and durable construction suitable for receiving official guests and holding small formal meetings | |
|---|---|---|
| VIP waiting areas in hotels, banks and public institutions | Stain-resistant upholstery, structured supportive seating and classic aesthetic creates a respectful, comfortable waiting environment for high-priority visitors | |
| Tea rooms and small private meeting spaces | Compact single-seat units with integrated side tables accommodate small group discussion and tea service without oversized lounge-style furniture | |
| Senior care facility guest reception areas | Standard 420mm seat height and firm supportive cushions make seating easy to enter and exit for older adults, while sturdy wood frame provides stable support | |
| Standalone matching configuration for traditional-style office lounge areas | Matching wood finish can coordinate with solid wood office desks and bookcases in New Chinese style office interiors for a unified design aesthetic | |
| Traditional-style office lounge areas | Matching dark reddish-brown wood finish coordinates with solid wood office desks and bookcases in New Chinese style office interiors for a unified design aesthetic, with long service life for regular office use | |
| Memorial hall and cultural institution reception spaces | Restrained formal design and symmetrical layout is appropriate for solemn cultural and official reception environments, with durable construction suitable for infrequent but high-formality use |
EU Market Access Requirements* EN Standards
| EN 13759 | 2003 Furniture - Seating - Test methods for the determination of durability of upholstery |
|---|
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
