Automatic mm / inch conversion · Core engineering specifications
| Overall combined dimensions (both units placed adjacent) | 2000 x 850 x 900 mm | |
|---|---|---|
| Single seat width per seating position | 600 mm | |
| Seat depth from front edge to backrest | 550 mm | |
| Seat height from floor to top of seat cushion | 430 mm | |
| Armrest height from floor to top of armrest | 620 mm | |
| Backrest height from seat surface to top of backrest | 470 mm | |
| Armrest width at front edge | 180 mm | |
| Dark wood decorative trim width at corner joints | 50 mm | |
| Floor clearance under seating base | 10 mm | |
| Single unit dimensions (single armchair) | 900 x 850 x 900 mm | |
| Single unit dimensions (2-seater sofa) | 1100 x 850 x 900 mm | |
| Backrest thickness at lumbar support position | 100 mm | |
| Armrest padding thickness | 60 mm | |
| Single position seat cushion dimensions | 600 x 550 x 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm |
Net weight / load capacity / users / durability
| Total product weight (both units) | 120 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seat cushion foam density | 40 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Seat cushion foam thickness | 120 mm | |
| Backrest foam thickness | 80 mm | |
| Recommended maximum seated users per set | 3 | |
| Fabric seam stitch pitch | 8 stitches per 30mm | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Frame joint static load durability | 100000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | Cream white PU (faux) leather | |
|---|---|---|
| Decorative frame trim | Dark walnut-stained solid hardwood | |
| Internal seating frame | Kiln-dried hardwood with mortise-and-tenon reinforced joints | |
| Seat support system | 8mm thick sinuous steel springs with polyester webbing | |
| Seat cushion fill | High-density polyurethane foam wrapped in 20mm soft dacron layer | |
| Backrest fill | Medium-density polyurethane foam with integrated lumbar pad | |
| Armrest padding | High-density polyurethane foam with rounded edge finishing | |
| Base bottom trim | Black PVC edge banding | |
| Floor protection glides | Black non-marking nylon glides fitted at each base corner | |
| Upholstery seam construction | Bonded polyester thread, lockstitch construction, 8 stitches per 30mm pitch | |
| Wood trim joint construction | Mitered corner joints with wood dowel reinforcement, stained to match trim finish | |
| Back panel covering | Matching cream PU leather upholstery over 9mm thick hardboard backing |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Two separate modular units (1 single armchair, 1 2-seater sofa) placed adjacent as shown | |
|---|---|---|
| Seating posture support | Fixed upright seat and back angle at 105 degrees between seat and backrest | |
| Integrated lumbar support | Built-in horizontal padded lumbar section on each backrest | |
| Floor protection | Non-marking nylon glides at all base corners | |
| Upholstery maintenance | Smooth non-porous PU leather surface | |
| Structural stability | Geometric wood frame trim integrated into base structure | |
| Color customization option | Available in standard cream, black and dark brown upholstery finishes with matching wood trim | |
| Leveling adjustment | Optional screw-in height-adjustable glides available (10mm adjustment range) | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 2 | |
|---|---|---|
| Individual carton dimensions (per unit) | 950 x 900 x 700 mm for single armchair, 1150 x 900 x 700 mm for 2-seater | |
| Total shipping gross weight (both units) | 140 kg | |
| Total shipping volume (CBM) | 1.32 | |
| On-site assembly time | 15 minutes | |
| 20ft GP container loading quantity | 34 sets | |
| 40ft HQ container loading quantity | 82 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Executive office reception areas | Formal cream and dark wood finish matches traditional executive office decor, provides guest seating for visitor meetings | |
|---|---|---|
| Corporate lobby waiting zones | Wipe-clean upholstery and rigid construction suitable for high-traffic public waiting areas with regular visitor turnover | |
| Government and institutional meeting spaces | Formal upright seating design and neutral color scheme meets requirements for official meeting and reception spaces | |
| VIP lounge areas in commercial buildings | Wide padded armrests and integrated lumbar support provide comfortable short-term seating for guests | |
| Matching configuration recommendation | Pair with 1200x600mm dark wood reception coffee table at 450mm height to align with seat height, procurement standard for matching reception furniture sets | |
| Recommended warranty period for commercial projects | 3 years frame warranty, 1 year upholstery warranty | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 13761:2004 Office furniture - Visitor chairs | Applies to structural stability, static load and durability requirements for public area reception seating | |
|---|---|---|
| EN 1021-1:2014 Upholstered furniture - Ignitability assessment - Part 1: Ignition source smouldering cigarette | Recommended minimum fire safety standard for office public area seating | |
| EN 1021-2:2014 Upholstered furniture - Ignitability assessment - Part 2: Ignition source match flame equivalent | Recommended enhanced fire safety standard for high-occupancy public reception areas |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 Lounge and Public Seating | Applies to static load, stability and durability testing requirements for commercial lounge seating, recommended as third-party acceptance benchmark |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to structural safety, dimension tolerance and finish quality of wood trim and frame components, used as acceptance benchmark | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applies to formaldehyde and heavy metal emission limits for wood and upholstery components, minimum requirement for indoor office use | |
| GB/T 16799-2008 Furniture leather | Applies to physical performance and harmful substance limits for PU leather upholstery, used as acceptance benchmark for upholstery material |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to structural safety, dimension tolerance and finish quality of wood trim and frame components, used as acceptance benchmark; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applies to formaldehyde and heavy metal emission limits for wood and upholstery components, minimum requirement for indoor office use; 3. GB/T 16799-2008 Furniture leather: Applies to physical performance and harmful substance limits for PU leather upholstery, used as acceptance benchmark for upholstery material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
