Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 1200 x 950 x 850 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat cushion usable width | 700 mm | |
| Seat cushion usable depth | 650 mm | |
| Backrest height above seat | 430 mm | |
| Armrest height above floor | 600 mm | |
| Armrest width | 250 mm | |
| Lower wood base height from floor | 50 mm | |
| Dark wood frame trim thickness | 40 mm | |
| Seat cushion thickness | 150 mm | |
| Backrest cushion thickness | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Product net weight | 55 kg | |
|---|---|---|
| Maximum static seat load capacity | 150 kg | |
| Maximum distributed backrest load | 80 kg | |
| Armrest vertical static load per side | 40 kg | |
| Seat foam density | 40 kg/m³ | |
| Back cushion foam density | 32 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Fabric abrasion resistance (Martindale) | 30000 cycles | |
| Recommended user count | 1 person | |
| Seat durability cycle rating | 25000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| External upholstery | Off-white vertical corduroy fabric, 0.8mm thickness | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam wrapped with 20mm soft polyester fiber batting | |
| Back cushion core | Medium-density polyurethane foam with fiber wrap | |
| Armrest padding | High-resilience polyurethane foam covered with matching corduroy | |
| Structural internal frame | Kiln-dried solid hardwood, 30mm thick structural members | |
| External frame accent trim | Dark brown wood veneer over engineered wood substrate | |
| Seat support platform | 12mm thick plywood decking with elastic webbing suspension | |
| Frame base feet | Dark finished wood feet integrated into lower frame, no exposed metal glides visible | |
| Seam construction | Reinforced stitched seams with 8 stitches per 30mm seam pitch | |
| Fabric color options | Off-white as shown, additional custom fabric colors available | |
| Back support webbing | 70mm wide elastic webbing spaced 100mm apart, secured with steel staples | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating use | Fixed static single-seat lounge seating with no recline or adjustability | |
|---|---|---|
| Arm rest function | Wide padded armrests support forearm rest and act as side containment for seat cushion | |
| Cushion configuration | Tight-upholstered fixed seat and back cushions attached to frame, no loose removable cushions visible | |
| Frame design function | Geometric dark wood trim creates a contrasting modern visual detail while reinforcing lower arm and base structure | |
| Floor clearance function | 50mm floor gap below base allows standard robot vacuum and mop access for cleaning under the chair | |
| Upholstery performance | Vertical corduroy fabric provides a soft textured surface with subtle light-shadow ribbing, suited for low-friction comfortable seating | |
| Structural stability | Wide rectangular base footprint with four integrated corner supports prevents tipping during normal use | |
| Felt glide function | 5mm thick felt glides on base feet prevent scratching of hard floor surfaces and reduce movement noise during repositioning | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 piece | |
|---|---|---|
| Shipping carton dimensions (L x W x H) | 1280 x 1030 x 930 mm | |
| Shipping gross weight | 65 kg | |
| Shipping volume per unit | 1.22 CBM | |
| Recommended on-site assembly time | 10 minutes | |
| 20ft GP container loading quantity | 18 units | |
| 40ft HQ container loading quantity | 45 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Residential living room application | Suitable as standalone accent chair or paired with matching multi-seat sofas in modern, minimalist, or contemporary living rooms | |
|---|---|---|
| Lounge and reception area application | Suitable for office reception zones, boutique hotel lobbies, and high-end residential lounge spaces | |
| Private study or home office seating | Appropriate as guest seating or relaxed reading chair in home studies and private offices | |
| Showroom and display space application | Suitable for furniture showrooms, interior design display sets, and residential staging projects | |
| Floor surface compatibility | Suitable for hard flooring including tile, hardwood, and luxury vinyl, with optional felt glides to prevent floor scratching | |
| Recommended surrounding clearance | Minimum 300mm clearance behind and to sides of chair for easy access and cleaning around the placed unit | |
| Hard floor surface application | Suitable for hard flooring including tile, hardwood, and luxury vinyl, with fitted felt glides to prevent floor scratching during repositioning | |
| Recommended surrounding placement clearance | Minimum 300mm clearance behind and to sides of chair for easy access and cleaning around the placed unit |
EU Market Access Requirements* EN Standards
| Applicable seating safety and strength standard | EN 12520:2015 Furniture - Strength, durability and safety - Requirements for domestic seating | |
|---|---|---|
| Applicable upholstered furniture flammability standard | EN 1021:2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette | |
| Applicable formaldehyde emission standard | EN 13986:2004+A1:2015 Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Applicable safety standard for general upholstered furniture | GB/T 3324 General technical requirements for wooden furniture | |
|---|---|---|
| Applicable upholstered furniture safety standard | GB 20400 Limit of harmful substances of leather and fur for furniture | |
| Applicable furniture mechanical performance standard | GB/T 10357.1 Test of mechanical properties of furniture - Strength and durability of seating | |
| Applicable fabric flammability standard for residential furniture | GB 20286 Flame retardant performance requirements and labeling of public place furniture and components | Applies if product is specified for public space projects | |
| Applicable safety standard for general wooden furniture | GB/T 3324 General technical requirements for wooden furniture | |
| Applicable harmful substance limit standard for upholstered furniture | GB 18584 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture |
This product must meet the following technical requirements: 1. Applicable safety standard for general upholstered furniture: GB/T 3324 General technical requirements for wooden furniture; 2. Applicable upholstered furniture safety standard: GB 20400 Limit of harmful substances of leather and fur for furniture; 3. Applicable furniture mechanical performance standard: GB/T 10357.1 Test of mechanical properties of furniture - Strength and durability of seating; 4. Applicable fabric flammability standard for residential furniture: GB 20286 Flame retardant performance requirements and labeling of public place furniture and components | Applies if product is specified for public space projects; 5. Applicable safety standard for general wooden furniture: GB/T 3324 General technical requirements for wooden furniture; 6. Applicable harmful substance limit standard for upholstered furniture: GB 18584 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
