Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2080 × 880 × 900 mm | |
|---|---|---|
| Seat height (floor to top of seat cushion) | 420 mm | |
| Seat depth (front edge to front of back cushion) | 580 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest total height (seat surface to top of backrest) | 480 mm | |
| Armrest height (floor to top of armrest) | 620 mm | |
| Armrest width (outer edge to seat side) | 180 mm | |
| Wood trim base plinth height (floor to bottom of upholstered seat) | 120 mm | |
| Per-seat usable width (between armrests for 3-seater) | 1720 mm | |
| Floor clearance under base plinth | 10 mm | |
| Per-seat usable width (between armrests for 2-seater) | 610 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight (complete two-piece set) | 125 kg | |
|---|---|---|
| Static load capacity per seat position | 150 kg | |
| Seat foam density (seat cushion) | 38 kg/m³ | |
| Backrest foam density | 28 kg/m³ | |
| Foam rebound rate (cushion core) | 42% | |
| Recommended total user capacity for full set | 5 adults | |
| Seat surface abrasion resistance (faux leather) | 50000 cycles (Martindale) | |
| Structural frame service life (daily commercial use) | 8 years | |
| Removable lace cover wash durability | 30 wash cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main upholstery covering | 1.0mm thick dark grey PVC faux leather | |
|---|---|---|
| Decorative trim and base frame | Dark walnut-stained solid pine wood framing | |
| Internal structural frame | 30mm thick solid pine + plywood jointed frame, corner-block reinforced | |
| Seat cushion core | High-density polyurethane foam, 120mm total thickness, 38kg/m³ density, no sag springs | |
| Back cushion core | Medium-density polyurethane foam, 100mm total thickness, 28kg/m³ density, segmented two-section design | |
| Decorative removable covers | White floral lace polyester fabric, scalloped edge finish, fitted for armrests and upper backrest | |
| Wood surface finish | Matte PU wood lacquer, wear-resistant coating for dark wood trim | |
| Frame joining hardware | Zinc-plated steel screws, corner wooden dowel reinforcements, metal corner brackets at base joints | |
| Bottom dust cover | Black non-woven polypropylene fabric, stapled to base frame underside | |
| Upholstery seam construction | Locked stitching with 8 stitches per 30mm seam pitch, matching dark grey thread for seamless finish | |
| Base foot pads | 10mm thick black non-slip plastic foot glides under base plinth | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating function | Fixed-position stationary reception seating, no recline, no swivel, no tilt mechanism, optimized for upright formal visitor seating | |
|---|---|---|
| Decorative cover function | 3 removable lace covers per sofa unit (1 triangular back headrest cover, 2 rectangular armrest covers), machine washable to protect main upholstery from wear and staining | |
| Wood trim function | Perimeter dark wood frame forms a raised protective bumper around upholstered panels, preventing edge scuff damage from luggage or visitor contact | |
| Cushion support function | Fixed attached seat and back cushions (non-removable main upholstery), high-resilience foam core maintains shape without indentation after 8 hours of continuous daily use | |
| Floor protection function | Low-profile integrated wood base with plastic glides, distributes weight evenly without requiring separate adjustable feet, suitable for tile, wood, or low-pile carpet office flooring | |
| Set configuration function | Matching 2-seater and 3-seater units share identical height, depth, trim, and upholstery finish, designed to be placed adjacent or separated to fit different reception room layouts | |
| Structural stability function | Low center of gravity from wide solid wood base, no rocking or tipping risk when users sit on front edge of seat per commercial furniture stability standards | |
| Maintenance function | Smooth faux leather surface can be wiped clean with mild detergent and damp cloth, resisting common office stains from coffee, ink, and dust without discoloration | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping packages per full set | 2 packages | |
|---|---|---|
| Shipping carton dimensions (3-seater unit) | 2150 x 950 x 950 mm | |
| Shipping carton dimensions (2-seater unit) | 1650 x 950 x 950 mm | |
| Total shipping gross weight (full set, packaging included) | 145 kg | |
| Total shipping volume (CBM, full set) | 3.43 CBM | |
| Required on-site assembly time | 15 minutes | |
| Standard 40ft HQ container loading capacity (full sets) | 22 sets | |
| Inner packaging material | 5mm thick EPE foam wrap, 25mm thick EPS corner protectors, plastic moisture barrier bag, procurement engineering , not supplier-measured data | |
| Outer packaging material | 5-ply corrugated shipping carton with printed handling markings, procurement engineering , not supplier-measured data | |
| Reference Package Count | 1 set / 2 cartons |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office reception areas and visitor waiting rooms | Formal dark grey and wood trim design projects a professional business appearance, sized to accommodate multiple waiting visitors without appearing bulky | |
|---|---|---|
| Executive office lounge and meeting break-out zones | Matching 2+3 seater configuration can be arranged in front of executive desks or in meeting breakout spaces for informal discussions and guest seating | |
| Public institution and government office waiting areas | Durable commercial-grade construction and stain-resistant easy-clean surface suits high-traffic public waiting areas with frequent visitor turnover | |
| Small business lobby and bank branch customer waiting spaces | Compact footprint and formal aesthetic works for small lobby spaces, with durable upholstery that withstands daily high-frequency use | |
| Recommended pairing furniture | Pair with matching dark wood finish coffee tables (1200x600mm height 450mm) placed between sofa units to create a complete coordinated reception seating area | |
| Floor type suitability | Suitable for installation on ceramic tile, polished concrete, engineered wood, and low-pile commercial carpet flooring without risk of floor damage from integrated base glides | |
| User suitability | Designed for adult users in commercial environments, with seat height and depth optimized for 185 cm height range for comfortable seated posture during 60 minute waiting periods |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 (Furniture - Strength, durability and safety - Requirements for domestic seating) | Applicable European standard for seating strength, durability, and safety performance, recommended for export or international project procurement specifications | |
|---|---|---|
| EN 1021-1:2014 (Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette) | Applicable European fire safety standard for upholstered furniture ignition resistance, recommended for high-occupancy public reception areas |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB 18584-2001 (Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture) | Applicable Chinese national standard for formaldehyde and heavy metal emission limits for wood trim components, recommended as acceptance criteria for indoor office use | |
|---|---|---|
| GB 20400-2006 (Leather and fur - Limit of harmful matter) | Applicable Chinese national standard for harmful substance limits in the faux leather upholstery, recommended for indoor air quality compliance in public office spaces |
This product must meet the following technical requirements: 1. GB 18584-2001 (Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture): Applicable Chinese national standard for formaldehyde and heavy metal emission limits for wood trim components, recommended as acceptance criteria for indoor office use; 2. GB 20400-2006 (Leather and fur - Limit of harmful matter): Applicable Chinese national standard for harmful substance limits in the faux leather upholstery, recommended for indoor air quality compliance in public office spaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
