Automatic mm / inch conversion · Core engineering specifications
| Three-seat sofa overall dimensions | 1900 x 850 x 900 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 850 x 900 mm | |
| Seat height from floor | 450 mm | |
| Seat depth (three-seat sofa, per position) | 550 mm | |
| Seat depth (single armchair) | 550 mm | |
| Backrest height above seat | 450 mm | |
| Armrest height from floor | 620 mm | |
| Armrest width | 120 mm | |
| Clearance under sofa base | 30 mm | |
| Wood accent trim dimensions | 80 x 50 mm cross-section | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set weight | 165 kg | |
|---|---|---|
| Seat static load capacity per position | 150 kg | |
| Recommended total seating capacity | 5 people | |
| Cushion compression set rating | 10% after 50,000 cycle tests | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Standard commercial warranty | 3 years | |
| Maximum rated seating occupancy | 5 people | |
| Cushion compression set performance | 10% after 50000 cyclic load tests | |
| Seam strength rating | 600 N tensile strength | |
| Frame fatigue resistance | 100000 simulated seating cycles without structural failure |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Cream matte faux leather (PU) | |
|---|---|---|
| Seat cushion core | 40 kg/m³ density high-resilience polyurethane foam | |
| Back cushion core | 30 kg/m³ density soft polyurethane foam | |
| Seat cushion thickness | 120 mm | |
| Back cushion thickness | 100 mm | |
| Arm accent trim | Dark walnut-stained solid hardwood | |
| Inner load-bearing frame | 30 mm x 50 mm kiln-dried solid hardwood | |
| Lower base trim | Black hard PVC edge banding | |
| Upholstery stitching | Polyester bonded thread with 8 stitches per inch | |
| Frame joint reinforcement | Metal corner brackets at all seat and back joints | |
| Contact surface upholstery | Cream matte PU faux leather, 0.8 mm thickness | |
| Seat cushion core material | 40 kg/m³ density high-resilience polyurethane foam, 120 mm thickness |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed stationary three-piece set, no recline or swivel mechanisms | |
|---|---|---|
| Cushion design | Tight attached seat and back cushions | |
| Arm support design | Rolled curved arms with wood structural accents | |
| Back support feature | Contoured lumbar support integrated into back cushion | |
| Floor protection | Integrated black non-marking base trim | |
| Layout flexibility | Individual standalone units allow flexible arrangement | |
| Cleaning accessibility | 30 mm base clearance allows standard vacuum and mop access under units | |
| Base seating configuration | Fixed stationary 3-piece set with no recline, swivel or rocking mechanisms | |
| Cushion attachment design | Tight, permanently attached seat and back cushions | |
| Armrest structural design | Fully padded rolled curved arms with exposed wood accent trim at front vertical supports | |
| Floor contact protection | Integrated black non-marking PVC base strip along full bottom perimeter | |
| Layout arrangement flexibility | 3 standalone units allow linear, conversational or L-shaped arrangement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 3 units | |
|---|---|---|
| Three-seat sofa shipping carton dimensions | 1950 x 900 x 750 mm | |
| Single armchair shipping carton dimensions (per unit) | 950 x 900 x 750 mm | |
| Total shipping gross weight | 195 kg | |
| Total shipping volume | 2.6 CBM | |
| On-site assembly time | 20 minutes | |
| 40ft HQ container loading quantity | 52 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate office reception areas | Formal styling and durable upholstery suitable for front-of-house guest waiting areas in professional office environments | |
|---|---|---|
| Government and institutional meeting spaces | Conservative cream and wood-trim design appropriate for official meeting rooms, visitor waiting rooms, and public service offices | |
| Small business lobby areas | Compact three-piece configuration fits lobbies of 15 sqm or larger, providing dedicated guest seating without excessive space use | |
| Executive office visitor seating | Matching formal styling complements traditional executive desks, suitable for placing opposite executive desks for guest meetings | |
| Hotel and hospitality waiting zones | Stain-resistant faux leather upholstery is suitable for low-to-medium traffic hotel business centers and lounge waiting areas | |
| Medical and clinic waiting areas | Smooth non-porous upholstery allows easy disinfection, suitable for private clinic or administrative hospital waiting spaces | |
| Corporate office front reception areas | Formal neutral styling and durable upholstery are suitable for front-of-house guest waiting areas in corporate office environments, projecting a professional image for visitors | |
| Government and institutional visitor spaces | Conservative cream and dark wood trim design is appropriate for official meeting room waiting areas, public service lobby spaces, and institutional reception zones |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 Office furniture - Office work chair - Part 2: Safety requirements | Reference safety standard for structural stability and load requirements applicable to non-task reception seating | |
|---|---|---|
| EN 1021-1:2014 Upholstered furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette | Recommended minimum flame resistance standard for public area upholstered seating | |
| EN 1021-2:2014 Upholstered furniture - Assessment of the ignitability of upholstered furniture - Part 2: Ignition source match flame equivalent | Recommended flame resistance standard for commercial office reception furniture | |
| EN 16139:2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating | Reference standard for structural stability, static load and fatigue performance requirements for commercial public area seating |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for wooden frame and wood trim structural strength, dimensional stability, and finish durability requirements | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde emission limits from wood components, required for indoor office use | |
| GB/T 27717-2011 Upholstered furniture for public places | Applicable for flame retardancy, structural strength, and durability requirements for high-traffic public reception seating | |
| GB 20400-2006 Leather and fur - Limit of harmful matter | Applicable for harmful substance limits if genuine leather is used, or PU leather coating compliance for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for wooden frame and wood trim structural strength, dimensional stability, and finish durability requirements; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde emission limits from wood components, required for indoor office use; 3. GB/T 27717-2011 Upholstered furniture for public places: Applicable for flame retardancy, structural strength, and durability requirements for high-traffic public reception seating; 4. GB 20400-2006 Leather and fur - Limit of harmful matter: Applicable for harmful substance limits if genuine leather is used, or PU leather coating compliance for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
