Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (single chair) | 900 x 850 x 900 mm | |
|---|---|---|
| Seat height (top of cushion to floor) | 450 mm | |
| Seat width (between armrests) | 580 mm | |
| Seat depth (front edge to back cushion face) | 550 mm | |
| Backrest total height (seat surface to top of back) | 480 mm | |
| Armrest top height (floor to arm cap) | 620 mm | |
| Wood arm cap dimensions per arm | 550 x 150 x 25 mm | |
| Decorative wood trim width (frame accent) | 30 mm | |
| Base foot height (floor to bottom of upholstered frame) | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Single chair net weight range | 45 kg | |
|---|---|---|
| Static seat load capacity | 150 kg | |
| Standard seating capacity per chair | 1 person | |
| Cushion indentation load deflection (ILD) | 40 | |
| Foam density (seat cushion) | 45 kg/m³ | |
| Seam tensile strength | 200 N | |
| Product warranty period (frame) | 36 months | |
| Product structural frame warranty | 36 months | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery cover material | 1.2mm thick matte off-white faux leather (PU) | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam | |
| Backrest fill material | Dense polyurethane foam with fibre topper | |
| Internal structural frame | 25mm thick kiln-dried solid hardwood frame | |
| Arm cap and accent trim | Stained dark walnut-finish solid wood with polished clear topcoat | |
| Base support feet | Solid dark-stained wood block feet | |
| Upholstery stitching | Polyester heavy-duty thread with 30mm stitch pitch | |
| Internal support webbing | 50mm wide elastic webbing under seat cushion | |
| Internal support system | 50mm wide elastic webbing spaced 80mm apart under seat cushion, supported by sinuous steel springs | |
| Frame padding layer | 10mm thick polyurethane foam wrap over internal wood frame to prevent hard edge contact through upholstery | |
| Underside dust cover | Black non-woven polypropylene fabric stapled to frame bottom to conceal internal components | |
| Wood finish coating | Matte clear polyurethane coating on all wood surfaces with 0.5mm dry film thickness for scratch resistance |
Adjustment / rotation / tilt / mobility / storage features
| Seating orientation and base type | Fixed non-swivel, non-reclining unit with four solid wood block feet | |
|---|---|---|
| Armrest functionality | Fixed wide solid wood arm caps providing flat resting surface for arms or small items | |
| Back support function | Split segmented upright backrest providing lumbar and mid-back support for formal upright sitting | |
| Cushion support performance | Fixed attached dense foam seat cushion maintaining uniform firmness for extended seated meetings | |
| Modular configuration capability | Alignable units can be placed adjacent to one another to create continuous linear reception rows | |
| Surface maintenance feature | Smooth faux leather upholstery and sealed wood surfaces enable spot cleaning with mild detergent for high-traffic public spaces | |
| Seating base functionality | Fixed non-swivel, non-reclining unit with four solid wood block feet, no moving adjustment mechanisms for stable formal stationary seating | |
| Cushion support function | Fixed attached dense foam seat cushion with 120mm thickness maintaining uniform firmness for 4+ hours of continuous seated use without permanent deformation | |
| Floor protection function | Felt pads on base feet prevent scratching of polished stone, tile or wood flooring when chairs are repositioned for layout adjustments | |
| Structural stability feature | 880mm wide base footprint with low center of gravity prevents tipping when users lean to side or apply weight to armrests | |
| Acoustic performance | Upholstered surfaces reduce reflected sound in large hard-surface reception lobbies compared to hard seating materials | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons per single chair | 1 carton | |
|---|---|---|
| Single chair shipping carton dimensions | 950 x 900 x 950 mm | |
| Single chair shipping gross weight | 52 kg | |
| Shipping volume (CBM) per single chair | 0.812 CBM | |
| Assembly time per chair (KD configuration) | 30 minutes | |
| 20ft GP container loading quantity (single chairs) | 32 units | |
| 40ft HQ container loading quantity (single chairs) | 80 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Government and corporate VIP reception rooms | Formal geometric wood-trim design and neutral off-white finish match official meeting space decor and project a professional, authoritative image | |
|---|---|---|
| Hospital and public institution waiting lobbies | Durable upholstery and firm supportive seating withstand high daily visitor traffic while maintaining a clean, respectable appearance | |
| Hotel lobby and executive lounge areas | Modular alignable design allows flexible linear or clustered seating configurations to match lobby layout requirements | |
| Corporate boardroom ancillary waiting zones | Consistent formal styling coordinates with executive office furniture to create a unified premium aesthetic for pre-meeting guest seating | |
| Funeral home and memorial service reception areas | Sober, understated formal design and stain-resistant surfaces provide appropriate dignified seating for high-volume visitor use | |
| Memorial service and public condolence reception areas | Sober understated formal design and stain-resistant light-color surfaces provide appropriate dignified seating for high-volume visitor use with easy maintenance | |
| Bank and financial institution customer waiting areas | Firm upright seating posture and durable surfaces support extended customer waiting times while projecting a trustworthy, professional institutional image | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 12520:2015 Furniture - Strength, durability and safety - Requirements for non-domestic seating | Serves as reference for 150kg static seat load, 100000 cycle durability and stability performance acceptance for commercial seating applications | |
|---|---|---|
| EN 1021-1:2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette | Serves as minimum fire safety reference requirement for upholstered components in public reception areas | |
| EN 1021-2:2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 2: Ignition source match flame equivalent | Serves as enhanced fire safety reference for high-traffic public lobby installations | |
| EN 13722:2004 Furniture - Assessment of surface resistance to cold liquids | Serves as reference for stain resistance performance of PU upholstery and wood finishes for easy cleaning in public spaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 Office Chairs - Tests | Provides reference static load, cyclic durability and stability test benchmarks for heavy-duty commercial seating use | |
|---|---|---|
| ANSI/BIFMA e3-2019 Furniture Sustainability Standard | Provides reference for low-emission material selection and sustainable procurement criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to structural safety of wood trim, frame joints and dimensional stability requirements for procurement acceptance | |
|---|---|---|
| GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission for wood-based panels | Applies to formaldehyde emission limits for any wood-based panel components used in internal frame, with required E1 grade minimum acceptance | |
| GB/T 16799-2008 Leather for furniture | Applies to abrasion resistance, color fastness and tear strength requirements for PU leather upholstery acceptance | |
| GB 28007-2011 General technical requirements for children's furniture (public area installation) | Applies to minimum 2mm edge radius requirement for all exposed wood trim to prevent impact injury in public reception spaces accessible to children | |
| GB 20286-2006 Flame retardant products and components in public places | Applies to flame retardant performance requirements for upholstered furniture installed in high-occupancy public reception lobbies |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to structural safety of wood trim, frame joints and dimensional stability requirements for procurement acceptance; 2. GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission for wood-based panels: Applies to formaldehyde emission limits for any wood-based panel components used in internal frame, with required E1 grade minimum acceptance; 3. GB/T 16799-2008 Leather for furniture: Applies to abrasion resistance, color fastness and tear strength requirements for PU leather upholstery acceptance; 4. GB 28007-2011 General technical requirements for children's furniture (public area installation): Applies to minimum 2mm edge radius requirement for all exposed wood trim to prevent impact injury in public reception spaces accessible to children; 5. GB 20286-2006 Flame retardant products and components in public places: Applies to flame retardant performance requirements for upholstered furniture installed in high-occupancy public reception lobbies; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
