Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1100 × 900 × 900 mm | |
|---|---|---|
| Overall per-seat dimensions | 1100 x 900 x 900 mm | |
| Seat height from floor | 450 mm | |
| Seat cushion usable depth | 580 mm | |
| Seat cushion usable width (between armrests) | 620 mm | |
| Backrest total height (from seat surface) | 550 mm | |
| Armrest top height from floor | 620 mm | |
| Armrest panel thickness | 40 mm | |
| Matching side table dimensions | 600 x 600 x 550 mm | |
| Side table lower shelf clearance | 350 mm | |
| Floor clearance under sofa base | 20 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-seat static load capacity | 200 kg | |
|---|---|---|
| Per-seat net weight (reference) | 45 kg | |
| Seat cushion foam density | 45 kg/m³ | |
| Backrest foam density | 35 kg/m³ | |
| Seam stitching pull strength | 100 N | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Recommended number of users per seat | 1 adult per single seat | |
| Recommended usable lifespan for commercial application | 8 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery material | 1.2mm thick dark brown top-grain match PU leather | |
|---|---|---|
| Frame and trim material | Polished reddish-brown solid hardwood (rubber wood reference) | |
| Seat cushion padding | 45kg/m³ high-resilience polyurethane foam, 120mm thick | |
| Backrest padding | 35kg/m³ polyurethane foam, 80mm thick | |
| Inner support frame | 30mm thick kiln-dried hardwood frame, corner blocked and screwed | |
| Side table top material | 25mm thick solid wood veneer over MDF core, high-gloss polished finish | |
| Side table apron details | 20mm thick solid wood with traditional Chinese geometric hollow cutout | |
| Feet material | Solid hardwood block feet, finished to match wood trim, with non-slip felt pads at base | |
| Upholstery stitching details | 8 stitches per inch (3.15 stitches per cm) reinforced nylon thread | |
| Inner back support board | 12mm thick multi-layer hardwood plywood, covered with 10mm soft polyester batting | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating function | Fixed upright seating position with no recline, tilt or swivel function | |
|---|---|---|
| Integrated armrest function | Wide solid wood armrests provide stable arm support and impact-resistant surface, preventing damage from bags or items placed on armrests | |
| Modular pairing function | Identical single seats can be arranged in pairs, rows or L-shaped layouts to fit different reception area sizes | |
| Matching side table function | Stable flat table surface for placing teacups, documents, potted plants or visitor personal items, with lower open storage for magazines or small objects | |
| Upholstery maintenance function | Smooth PU leather surface resists liquid spills, can be wiped clean with a damp cloth without staining, suitable for high-traffic public use | |
| Structural stability function | Low center of gravity, wide solid wood base and block feet prevent tipping even when users sit on armrests or shift weight, meeting commercial furniture stability requirements | |
| Floor protection function | Non-slip felt pads on base feet prevent scratches on marble, tile or wood flooring, reduce sliding noise when moving seats for layout adjustment | |
| Seating support function | Fixed upright 105-degree seated position with no recline, tilt or swivel function | |
| Modular layout function | Identical single seats can be arranged in pairs, linear rows or L-shaped layouts to fit reception areas from 6 to 30 square meters | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of packages per 2-seat + 1-table set | 3 packages total: 2 cartons for single sofas, 1 carton for side table | |
|---|---|---|
| Per-sofa carton dimensions | 1150 x 950 x 950 mm | |
| Per-sofa carton gross weight | 52 kg | |
| Side table carton dimensions | 650 x 650 x 200 mm | |
| Side table carton gross weight | 18 kg | |
| Total CBM per full set (2 chairs + 1 table) | 1.17 CBM | |
| On-site assembly time per full set | 20 minutes | |
| 40HQ container loading quantity (full set basis) | 58 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| VIP reception room application | Suitable for executive office VIP reception areas, government and corporate meeting rooms, formal visitor waiting spaces | |
|---|---|---|
| Lobby waiting area application | Can be arranged in rows or groups for hotel lobbies, bank service halls, hospital administrative waiting areas | |
| Small meeting space application | 2 seats with central table configuration creates a private 2-person conversation space for small negotiation, interview or consultation rooms | |
| Recommended matching configuration | Pairs with matching 3-seat sofa, additional side tables and wood-finish coffee table to create complete reception area sets | |
| Flooring compatibility | Suitable for installation on marble, polished tile, engineered wood and carpeted commercial flooring | |
| Target user profile | Designed for adult users in formal commercial and institutional settings, supporting professional posture during meetings and waiting periods | |
| Maintenance requirement note | Recommended for indoor climate-controlled environments, avoid prolonged direct sunlight to prevent leather fading and wood finish cracking, suitable for indoor commercial use only | |
| Full set matching configuration | Pairs with matching 3-seat sofa, additional side tables and matching wood-finish coffee table to create complete reception area sets |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| BS EN 1022 | 2018 Domestic furniture – Seating – Determination of stability |
|---|
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 1952.1-2012 Upholstered furniture | Sofas |
|---|
This product must meet the following technical requirements: 1. GB/T 1952.1-2012 Upholstered furniture: Sofas; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
