Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 900 x 850 x 800 mm | |
|---|---|---|
| seat width (usable) | 600 mm | |
| seat depth (usable) | 550 mm | |
| seat height from floor | 420 mm | |
| armrest height from floor | 600 mm | |
| armrest width | 150 mm | |
| backrest height above seat | 380 mm | |
| red wood frame trim thickness | 30 mm | |
| seat cushion thickness | 120 mm | |
| back cushion thickness | 100 mm | |
| base clearance from floor | 20 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| net product weight | 55 kg | |
|---|---|---|
| static seat load capacity | 200 kg | |
| foam density (seat) | 45 kg/m³ | |
| foam density (backrest/armrest) | 35 kg/m³ | |
| upholstery abrasion resistance (Martindale) | 50000 cycles | |
| seating capacity | 1 adult | |
| foam rebound rate | 45% | |
| suggested warranty period for commercial use | 3 years | |
| seat foam density | 45 kg/m³ | |
| back/arm foam density | 35 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| seat/back/arm upholstery | White matte fabric or faux leather upholstery | |
|---|---|---|
| seat core padding | High-resilience polyurethane foam | |
| back/arm core padding | Medium-density polyurethane foam | |
| accent trim frame | Red painted solid wood or engineered wood frame | |
| internal structural frame | Solid wood + plywood internal frame | |
| upholstery attachment | Stapled and sewn upholstery with hidden seams | |
| frame finish (red trim) | Smooth matte red lacquer coating | |
| floor contact surface | Non-marking felt or fabric glide | |
| red accent trim frame | Matte red lacquered engineered wood frame, 30 mm member thickness | |
| upholstery construction | Sewn and stapled upholstery with 8 stitches per inch seam pitch, hidden edge seams | |
| floor contact components | 5 mm thick non-marking felt glides, full perimeter base mounting | |
| frame joint reinforcement | Metal corner brackets at all frame joints, 4 mm steel thickness |
Adjustment / rotation / tilt / mobility / storage features
| seating support | Fixed rigid seat and backrest with no recline adjustment | |
|---|---|---|
| arm support | Fully padded integrated wide armrests matching seat height | |
| structural stability | Low-profile full perimeter wood base frame for tip resistance | |
| assembly requirement | Fully assembled delivery or knock-down with simple panel attachment | |
| upholstery maintenance | Wipe-clean surface suitable for light commercial spill exposure | |
| usage position | Fixed upright sitting posture for reception or waiting area use | |
| delivery configuration | Fully assembled delivery or knock-down with 4 bolt-on panel sections | |
| lumbar support | Fixed integrated 100 mm thick lower lumbar cushion aligned to natural lower back curve | |
| floor protection | Full perimeter felt glides that prevent floor scratching on wood, tile and low-pile carpet | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
| number of shipping cartons | 1 carton | |
|---|---|---|
| shipping carton dimensions | 950 x 900 x 850 mm | |
| gross shipping weight | 60 kg | |
| shipping volume per unit | 0.73 CBM | |
| on-site assembly time | 15 minutes | |
| 20ft GP container loading quantity | 36 units | |
| 40ft HQ container loading quantity | 90 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| office reception areas | Suitable for executive reception rooms, lobby waiting areas, and visitor seating | |
|---|---|---|
| commercial lounge spaces | Suitable for hotel lobbies, business lounge waiting zones, and club seating | |
| private executive office use | Suitable for placement in private manager/executive offices for guest seating | |
| government and institutional spaces | Suitable for public service waiting areas and meeting room guest seating | |
| color matching configuration | Can be paired with matching 2-seat and 3-seat sofas in the same style to form complete reception sets | |
| office reception lobbies | Suitable for corporate reception areas and visitor waiting zones, configured as individual guest seats or paired with matching multi-seat sofas | |
| executive private offices | Suitable for placement in private manager/executive offices for guest seating opposite desks | |
| business lounge spaces | Suitable for hotel business lounges, airport VIP waiting areas and club seating zones |
EU Market Access Requirements* EN Standards
| upholstered furniture safety recommendation | EN 12520:2015 | |
|---|---|---|
| furniture formaldehyde emission recommendation | EN 13986:2004+A1:2015 | |
| upholstery flame retardant recommendation | EN 1021:2014 | |
| contract seating safety recommendation | EN 12520:2015 | |
| wood panel formaldehyde emission recommendation | EN 13986:2004+A1:2015 | |
| upholstery ignition resistance recommendation | EN 1021:2014 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| furniture formaldehyde emission recommendation | GB 18584 | |
|---|---|---|
| furniture flame retardant recommendation | GB 20286 | |
| wooden furniture formaldehyde emission recommendation | GB 18584 | |
| public place furniture flame retardant recommendation | GB 20286 | |
| furniture mechanical stability recommendation | GB/T 10357.2 |
This product must meet the following technical requirements: 1. furniture formaldehyde emission recommendation: GB 18584; 2. furniture flame retardant recommendation: GB 20286; 3. wooden furniture formaldehyde emission recommendation: GB 18584; 4. public place furniture flame retardant recommendation: GB 20286; 5. furniture mechanical stability recommendation: GB/T 10357.2; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
