| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 820 x 840 x 890 mm | |
|---|---|---|
| Seat height from floor | 460 mm | |
| Seat width | 680 mm | |
| Seat depth | 580 mm | |
| Backrest height above seat | 430 mm | |
| Integrated armrest height above seat | 180 mm | |
| Leg height from floor to seat frame | 280 mm | |
| Seat cushion thickness | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 150 kg | |
|---|---|---|
| Net product weight | 22 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Frame static load rating | 300 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Inner seating surfaces | Light grey woven polyester-linen blend fabric | |
|---|---|---|
| Outer back shell | Dark matte engineered wood panel with smooth finish | |
| Support legs | Dark stained solid rubber wood, tapered splayed design | |
| Internal frame | 18mm thick plywood and solid wood joinery | |
| Seat and back padding | High-density polyurethane foam wrapped in 20g polyester wadding | |
| Fabric thickness | 0.8mm woven upholstery fabric | |
| Leg finish | Matte dark lacquer, scratch-resistant coating | |
| Seam construction | 8 stitches per inch reinforced stitching | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Fixed static seating with 105 degree relaxed back angle | |
|---|---|---|
| Support design | Integrated wraparound back and armrest for enclosed arm and back support | |
| Assembly requirement | Knock-down delivery, legs attach to pre-installed seat frame with included hardware | |
| Floor protection | Plastic glides fitted to leg bases to prevent floor scratching | |
| Adjustment features | No swivel, tilt, lift or height adjustment mechanisms | |
| Maintenance requirement | Spot clean upholstery with mild detergent, wipe shell surface with damp cloth | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Suitable as standalone accent seating beside sofas for relaxed casual seating | |
|---|---|---|
| Lounge and waiting areas | Appropriate for hotel lobbies, office reception zones and breakout areas | |
| Bedroom placement | Fits as a reading chair in master or guest bedrooms | |
| Pair configuration | Can be deployed in pairs flanking a coffee table for conversation seating | |
| Recommended pairing | Matches with round or oval side tables of 600 mm height for drink placement | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Seating strength recommendation | EN 12520:2015 |
|---|
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Wood furniture formaldehyde limit recommendation | GB 18584 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Wood furniture formaldehyde limit recommendation: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
