Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 400 x 650 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight | 65 kg | |
|---|---|---|
| Static load capacity of worktop | 50 kg | |
| Disinfection cabinet rated load | 10 kg | |
| Enclosed storage bay static load | 30 kg | |
| Caster rated dynamic load per unit | 100 kg | |
| Maximum recommended user weight for stationary placement | 200 kg | |
| Disinfection cycle duration | 30 min | |
| Product service life | 8 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop | 18mm sintered stone with black marble white-vein finish | |
|---|---|---|
| Left side panel | 18mm MDF core with vertical walnut wood veneer | |
| Right door panel | 18mm MDF core with embossed geometric walnut wood veneer | |
| Internal cabinet frame | 15mm high-density particleboard with laminated edge banding | |
| Built-in disinfection cabinet front panel | Tempered black glass with touch control interface | |
| Caster wheels | Nylon housing with polyurethane rolling surface | |
| Door hinge hardware | Cold-rolled steel soft-close concealed hinges | |
| Recessed tea tray area | Stainless steel drip tray base under sintered stone cutout | |
| Open compartment interior lining | Black matte melamine finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated sterilization function | High-temperature + ozone disinfection cycle for tea ware, controlled via 4 front touch buttons | |
|---|---|---|
| Mobile positioning function | 4 swivel casters with 2 locking brakes, allows repositioning between lounge and meeting areas | |
| Enclosed dry storage function | Single hinged right door covering a 2-shelf storage bay for tea canisters and spare utensils | |
| Open access storage function | Open recessed shelf below disinfection cabinet for frequently used cups and tea tools, no door required | |
| Heat-resistant worktop function | Sintered stone surface supports direct placement of boiling kettles and hot teapots without heat mats | |
| Integrated drip containment | Recessed stainless steel tray under boiling station contains spilled water to protect cabinet interior | |
| Level adjustment function | Caster stems include 10mm height adjustment to compensate for uneven floors | |
| Cable management function | Rear cutout for power cord routing to wall outlet, keeps appliance cords hidden | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 880 x 480 x 730 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Executive office lounge areas | Serves tea and hot beverages to meeting guests adjacent to seating groups | |
|---|---|---|
| Private tea room spaces | Provides dedicated tea preparation and sterilized cup storage for formal tea service | |
| Small conference room ancillary use | Placed against side wall to provide hot water and tea storage for meeting breaks | |
| Reception waiting areas | Offers self-service tea and water access for waiting visitors | |
| Boutique hotel lounge areas | Matches upscale wood and stone decor for high-end guest beverage service |
EU Market Access Requirements* EN Standards
| Formaldehyde emission from wood panels | EN 312:2010 | |
|---|---|---|
| Surface wear resistance | EN 14322:2017 | |
| Furniture stability for mobile storage units | EN 14073:2004 |
Standards applicable to China-market projects
| Wood-based panel formaldehyde emission | GB 18580 | |
|---|---|---|
| Sintered stone surface safety | GB 6566 | |
| Electrical component safety | GB 4706.1 | |
| Furniture structural safety for cabinets | GB/T 3324 |
This product must meet the following technical requirements: 1. Wood-based panel formaldehyde emission: GB 18580; 2. Sintered stone surface safety: GB 6566; 3. Electrical component safety: GB 4706.1; 4. Furniture structural safety for cabinets: GB/T 3324; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
